1 - MOTOR HOUSING
BSD-3605108091.A25
3605108091
|
£35.42
|
£42.51
|
|
|
3/50 - FAN
BSD-1606610122.A151
1606610122
|
£2.94
|
£3.53
|
|
|
4 - SWITCH
BSD-1607200079.A10
1607200079
|
£35.42
|
£42.51
|
|
|
4/10 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x6-5.8
BSD-2910011082.A18
2910011082
|
£1.75
|
£2.10
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A483
3600703011
|
£2.94
|
£3.53
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A240
1601302014
|
£2.74
|
£3.29
|
|
|
9 - STICKER
BSD-3601110611.A0
3601110611
|
£2.74
|
£3.29
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329096.A183
2607329096
|
£7.72
|
£9.27
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1415
2600905032
|
£5.57
|
£6.68
|
|
|
14 - GROOVE BALL BEARING 9x26x8
BSD-3600905131.A65
3600905131
|
£11.87
|
£14.24
|
|
|
20 - STRAIGHT PIN DIN 7-5H8x14
BSD-2917500119.A5
2917500119
|
£1.75
|
£2.10
|
|
|
21 - SPINDLE BEARING
BSD-3605806220.A0
3605806220
|
£50.80
|
£60.96
|
|
|
27 - COUPLING HALF 3/4
BSD-1606455031.A5
1606455031
|
£164.02
|
£196.83
|
|
|
28 - SHIM WASHER
BSD-3600114013.A5
3600114013
|
£21.68
|
£26.01
|
|
|
29 - STRIKER
BSD-1608710018.A0
1608710018
|
£251.67
|
£302.00
|
|
|
30 - DRIVE SHAFT
BSD-1603124077.A0
1603124077
|
£164.02
|
£196.83
|
|
|
31 - BACKUP RING
BSD-1600220015.A0
1600220015
|
£102.57
|
£123.08
|
|
|
32 - AIR-DEFLECTOR RING
BSD-1600502019.A11
1600502019
|
£3.72
|
£4.47
|
|
|
33 - INTERMEDIATE RING
BSD-3600300042.A11
3600300042
|
£10.61
|
£12.73
|
|
|
35 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A22
1600910018
|
£5.57
|
£6.68
|
|
|
36 - GROOVE BALL BEARING 15x35x11
BSD-1900905279.A13
1900905279
|
£11.87
|
£14.24
|
|
|
37 - BALL DIN 5401-8 MM III-ST
BSD-1903230014.A5
1903230014
|
£1.75
|
£2.10
|
|
|
38 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A556
1903230007
|
£1.84
|
£2.21
|
|
|
39 - SPRING RETAINING RING DIN 472 38X1.5MM
BSD-2916660017.A0
2916660017
|
£4.26
|
£5.11
|
|
|
40 - SPRING WASHER dia27.5x38.4 MM
BSD-1600150007.A5
1600150007
|
£1.84
|
£2.21
|
|
|
41 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A84
2916650006
|
£1.75
|
£2.10
|
|
|
42 - PARALLEL KEY DIN 6885-A6X4X14
BSD-1902300083.A12
1902300083
|
£1.84
|
£2.21
|
|
|
43 - CYLINDRICAL GEAR Z=25
BSD-3606301006.A9
3606301006
|
£63.50
|
£76.20
|
|
|
45 - SHIM 0.5 MM
BSD-1600100617.A26
1600100617
|
£1.75
|
£2.10
|
|
|
46 - O-RING 28x3 MM
BSD-1900210129.A91
1900210129
|
£2.74
|
£3.29
|
|
|
47 - O-RING 66.0x3.0 MM
BSD-1600210005.A7
1600210005
|
£2.80
|
£3.36
|
|
|
48 - RUBBER RING 7 MM
BSD-1600206020.A715
1600206020
|
£1.84
|
£2.21
|
|
|
49 - BEARING COVER
BSD-3605500043.A16
3605500043
|
£4.48
|
£5.37
|
|
|
50 - INTERMEDIATE RING
BSD-1600502011.A555
1600502011
|
£2.74
|
£3.29
|
|
|
51 - COMPRESSION SPRING
BSD-1604613006.A2
1604613006
|
£1.75
|
£2.10
|
|
|
52 - COMPRESSION SPRING
BSD-3604610034.A5
3604610034
|
£14.91
|
£17.89
|
|
|
53 - SPIRAL SPRING
BSD-160465202C.A10
160465202C
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A201
2910021118
|
£1.84
|
£2.21
|
|
|
55 - INSULATING STRIP
BSD-3602317025.A5
3602317025
|
£2.61
|
£3.13
|
|
|
56 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A328
2910211019
|
£1.84
|
£2.21
|
|
|
59 - LENS HEAD SCREW
BSD-3603435040.A13
3603435040
|
£1.75
|
£2.10
|
|
|
60 - HEX SOCKET HEAD CAP SCREW DIN 912-BM 5x40-10.9
BSD-2910151170.A9
2910151170
|
£1.84
|
£2.21
|
|
|
61 - LENS HEAD SCREW
BSD-3603435041.A7
3603435041
|
£1.75
|
£2.10
|
|
|
62 - TAPPING SCREW 5x30
BSD-3603435027.A40
3603435027
|
£1.84
|
£2.21
|
|
|
64 - PLAIN WASHER DIN 7603-A4x8
BSD-3600120013.A0
3600120013
|
£1.84
|
£2.21
|
|
|
65 - SHIM WASHER 0.4 MM
BSD-1600101600.A52
1600101600
|
£1.84
|
£2.21
|
|
|
66 - STICKER
BSD-3601110369.A5
3601110369
|
£3.91
|
£4.69
|
|
|
67 - SHRINKABLE TUBE
BSD-1600712027.A7
1600712027
|
£1.75
|
£2.10
|
|
|
68 - ELEC. CABLE W/CONNECTION L=250 MM
BSD-3604448044.A4
3604448044
|
£3.72
|
£4.47
|
|
|
69 - CONNECTING CABLE L=470 MM
BSD-3604438025.A33
3604438025
|
£7.36
|
£8.83
|
|
|
70 - CONNECTING CABLE L=330 MM
BSD-1604438012.A60
1604438012
|
£7.36
|
£8.83
|
|
|
71 - CONNECTING CABLE L=330 MM
BSD-3604460135.A7
3604460135
|
£8.67
|
£10.41
|
|
|
72 - CONNECTING CABLE L=160 MM
BSD-3604438008.A8
3604438008
|
£9.11
|
£10.93
|
|
|
73 - SUPPRESSION FILTER L=300 MM
BSD-3604503036.A8
3604503036
|
£5.57
|
£6.68
|
|
|
74 - SUPPRESSION FILTER L=150 MM
BSD-3604503037.A5
3604503037
|
£5.30
|
£6.36
|
|
|
75 - WIRE GUIDE
BSD-3601025003.A57
3601025003
|
£1.75
|
£2.10
|
|
|
76 - TORX OVAL-HEAD SCREW
BSD-2914201527.A71
2914201527
|
£2.27
|
£2.72
|
|
|
77 - SEALING CAP
BSD-3605500062.A4
3605500062
|
£13.12
|
£15.75
|
|
|
78 - SUSPENSION LOOP
BSD-3601310013.A7
3601310013
|
£21.68
|
£26.01
|
|
|
79 - HEX SOCKET HEAD CAP SCREW
BSD-2910131193.A11
2910131193
|
£1.75
|
£2.10
|
|
|
80 - TORX OVAL-HEAD SCREW
BSD-2914201508.A43
2914201508
|
£1.84
|
£2.21
|
|
|
81 - SHRINKABLE TUBE
BSD-3600707022.A110
3600707022
|
£3.72
|
£4.47
|
|
|
88 - SOCKET HEAD CAP SCREW
BSD-3603435045.A7
3603435045
|
£1.75
|
£2.10
|
|
|
89 - SEAL
BSD-3601023009.A1
3601023009
|
£6.85
|
£8.22
|
|
|
90 - TAB WASHER
BSD-1601030022.A383
1601030022
|
£1.84
|
£2.21
|
|
|
181 - STICKER
BSD-1611110G37.A0
1611110G37
|
-
|
|
|
|
301/63 - CONNECTING CABLE L=60 MM
BSD-3604412002.A12
3604412002
|
£7.36
|
£8.83
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A1434
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1347
1602025030
|
£19.91
|
£23.89
|
|
|
700 - SPRING PULL 6-8 KG
BSD-0607950925.A5
0607950925
|
-
|
|
|
|
711 - O-RING 26.0x16.0 MM
BSD-1600210018.A5
1600210018
|
-
|
|
|
|
711 - SEAL RING dia 8x14 MM
BSD-1600280000.A1
1600280000
|
-
|
|
|
|
712 - BALL JOINT 3/4. 90 MM
BSD-1608500008.A0
1608500008
|
-
|
|
|
|
751 - THREADED FITTING M14. L=70 MM
BSD-1603527017.A8
1603527017
|
-
|
|
|
|
802 - FIELD 220-230V
BSD-3604220138.A1
3604220138
|
£75.79
|
£90.95
|
|
|
803 - ARMATURE 220-230V
BSD-3604010071.A5
3604010071
|
£156.22
|
£187.46
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A225
1607000228
|
£23.86
|
£28.63
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3991
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-3607014012.A79
3607014012
|
£25.05
|
£30.06
|
|
|
816 - BRUSH HOLDER
BSD-3604336012.A107
3604336012
|
£5.58
|
£6.70
|
|
|
822 - GEAR HOUSING
BSD-3605806167.A5
3605806167
|
£126.12
|
£151.34
|
|
|
823 - INTERMEDIATE FLANGE
BSD-3605806168.A0
3605806168
|
£72.18
|
£86.62
|
|
|
824 - HANDLE
BSD-3605132064.A3
3605132064
|
£23.86
|
£28.63
|
|
|
825 - SEALING CAP
BSD-3605500063.A175
3605500063
|
£4.48
|
£5.37
|
|
|
826 - SWITCH
BSD-3607200000.A4
3607200000
|
£21.52
|
£25.83
|
|
|
834 - ROTARY SHAFT LIP SEAL
BSD-3600290070.A32
3600290070
|
£12.64
|
£15.17
|
|
|
844 - GEAR SHAFT
BSD-1607000C6N.A1
1607000C6N
|
£81.81
|
£98.17
|
|
|
855 - RETAINING SPRING
BSD-3607000094.A1
3607000094
|
£15.65
|
£18.78
|
|
