1 - HOUSING SECTION
BSD-2605104316.A21
2605104316
|
-
|
|
|
|
2 - FIELD 220-240V
BSD-2604220423.A41
2604220423
|
£25.68
|
£30.81
|
|
|
3 - ARMATURE 230-240V
BSD-2604010776.A1
2604010776
|
£41.62
|
£49.95
|
|
|
3/60 - FAN
BSD-1606610116.A83
1606610116
|
£2.52
|
£3.02
|
|
|
4 - SWITCH
BSD-1617200089.A48
1617200089
|
-
|
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A622
2600707059
|
£3.91
|
£4.69
|
|
|
6 - GROMMET dia8.8 MM
BSD-2600707061.A319
2600707061
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1310
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118575.A2
2601118575
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A130
2607329114
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A805
2600905032
|
£5.57
|
£6.68
|
|
|
14 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A417
2600917003
|
£2.94
|
£3.53
|
|
|
16 - BRUSH PLATE
BSD-2605807060.A98
2605807060
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A873
2603410001
|
£1.84
|
£2.21
|
|
|
19 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A114
2910611019
|
£2.94
|
£3.53
|
|
|
20 - REFERENCE PLATE
BSD-2601118573.A4
2601118573
|
-
|
|
|
|
29 - O-RING 5.0x1.5 MM
BSD-1900210000.A601
1900210000
|
£1.84
|
£2.21
|
|
|
30 - SPACER RING
BSD-2600209004.A69
2600209004
|
-
|
|
|
|
32 - TAPPING SCREW DIN 7983 ST4.2x32-C-H
BSD-2910611096.A22
2910611096
|
£1.32
|
£1.58
|
|
|
33 - SEALING CAP
BSD-2605500111.A11
2605500111
|
-
|
|
|
|
43 - CYLINDRICAL GEAR Z=46
BSD-2606320021.A6
2606320021
|
£18.96
|
£22.75
|
|
|
44 - GROOVE BALL BEARING 6200-2Z DIN 625
BSD-1900905232.A48
1900905232
|
£21.68
|
£26.01
|
|
|
45 - SPRING RETAINING RING DIN 471-10x1MM-FSt
BSD-2916650001.A441
2916650001
|
£2.74
|
£3.29
|
|
|
46/800 - CHUCK WRENCH SG2
BSD-2607950007.A1097
2607950007
|
£6.85
|
£8.22
|
|
|
47 - FELT SHEET
BSD-2600005005.A24
2600005005
|
-
|
|
|
|
50 - EARTH CONDUCTOR
BSD-2604448103.A86
2604448103
|
-
|
|
|
|
51 - CABLE L=98 MM
BSD-2604448045.A55
2604448045
|
-
|
|
|
|
52 - CABLE L=173 MM
BSD-2604448060.A90
2604448060
|
-
|
|
|
|
53 - CONNECTING CABLE L=88 MM
BSD-2604448130.A20
2604448130
|
£1.75
|
£2.10
|
|
|
54 - CONNECTING CABLE L=73 MM
BSD-2604448123.A108
2604448123
|
-
|
|
|
|
60 - SQUARE NUT DIN 562-M4-04
BSD-2915121004.A51
2915121004
|
-
|
|
|
|
61 - PAN HEAD SCREW DIN 85-M4x10-4.8
BSD-2910091120.A25
2910091120
|
£1.75
|
£2.10
|
|
|
199 - STICKER
BSD-1601110265.A74
1601110265
|
-
|
|
|
|
746 - KEY CHUCK dia1-8 MM. 1/2
BSD-1608571077.A0
1608571077
|
-
|
|
|
|
750 - CHANNEL END-PLATE
BSD-2608040050.A37
2608040050
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 2.6m 2 x 1.0 mm
BSD-1607000385.A235
1607000385
|
£15.65
|
£18.78
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2604321905.A481
2604321905
|
£11.87
|
£14.24
|
|
|
816/06 - RATCHET CAP
BSD-2601329051.A171
2601329051
|
£2.33
|
£2.80
|
|
|
816/06 - RATCHET CAP
BSD-2601322013.A116
2601322013
|
£1.84
|
£2.21
|
|
|
825 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A200
2910611006
|
£1.75
|
£2.10
|
|
|
828 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A696
2912401020
|
£2.16
|
£2.59
|
|
|
831 - BUSHING
BSD-2605807921.A1
2605807921
|
-
|
|
|
|
841 - DRILLING SPINDLE 1/2.1/4
BSD-2606135913.A0
2606135913
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2099
160111A3H3
|
£2.74
|
£3.29
|
|
