1 - MOTOR HOUSING
BSD-2605104332.A38
2605104332
|
£15.49
|
£18.59
|
|
|
2 - FIELD 220-230V
BSD-2604220429.A152
2604220429
|
£23.86
|
£28.63
|
|
|
3 - ARMATURE 220-240V
BSD-2604010575.A27
2604010575
|
£54.42
|
£65.30
|
|
|
3/60 - FAN
BSD-2606610027.A215
2606610027
|
£2.80
|
£3.36
|
|
|
4 - ON-OFF SWITCH
BSD-2607200365.A34
2607200365
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 230V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460140.A1
2604460140
|
£22.76
|
£27.31
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A704
2600707059
|
£3.91
|
£4.69
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1211
2601035001
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601116663.A3
2601116663
|
£2.16
|
£2.59
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329138.A74
2607329138
|
-
|
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A1177
1900905018
|
£19.91
|
£23.89
|
|
|
14 - BALL BEARING 9x24x7
BSD-2600905095.A40
2600905095
|
£12.04
|
£14.45
|
|
|
16 - BRUSH HOLDER
BSD-2604337003.A193
2604337003
|
£2.16
|
£2.59
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1087
2603410001
|
£1.84
|
£2.21
|
|
|
19 - SCREW 4x16
BSD-2603490022.A329
2603490022
|
£1.84
|
£2.21
|
|
|
26 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A209
2603490025
|
£1.84
|
£2.21
|
|
|
29 - COVER DISC
BSD-2601328046.A43
2601328046
|
£2.80
|
£3.36
|
|
|
30 - RUBBER BUFFER
BSD-3602391503.A83
3602391503
|
-
|
|
|
|
35 - COUNTERSUNK-HEAD SCREW M6x38/12(dia11)
BSD-2603421208.A37
2603421208
|
-
|
|
|
|
36 - KEY CHUCK dia1.5-13 MM
BSD-1608571080.A47
1608571080
|
£28.59
|
£34.31
|
|
|
36/700 - CHUCK WRENCH SG2
BSD-2607950007.A977
2607950007
|
£6.85
|
£8.22
|
|
|
37 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A376
2603410048
|
£1.84
|
£2.21
|
|
|
38 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1542
2603490023
|
£1.84
|
£2.21
|
|
|
39 - HOUSING COVER
BSD-2605132050.A38
2605132050
|
£10.61
|
£12.73
|
|
|
41 - FLAT SEAL RING
BSD-2601015012.A15
2601015012
|
£1.84
|
£2.21
|
|
|
42 - DRILLING SPINDLE 1/2. SW 17
BSD-2606135011.A31
2606135011
|
£28.68
|
£34.41
|
|
|
43 - BALL BEARING dia15 MM
BSD-1900905110.A51
1900905110
|
£10.10
|
£12.12
|
|
|
44 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A339
2916650006
|
£1.75
|
£2.10
|
|
|
45 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A207
2916660013
|
£2.16
|
£2.59
|
|
|
46 - SHIM 0.5 MM
BSD-2600100695.A189
2600100695
|
£1.84
|
£2.21
|
|
|
47 - CYLINDRICAL GEAR
BSD-2606316316.A51
2606316316
|
£27.23
|
£32.68
|
|
|
48 - CYLINDRICAL GEAR
BSD-2606316317.A8
2606316317
|
£25.05
|
£30.06
|
|
|
49 - FLAT KEY
BSD-2602300033.A50
2602300033
|
£5.87
|
£7.04
|
|
|
50 - SHIM 1.5 MM
BSD-2600101668.A30
2600101668
|
£2.94
|
£3.53
|
|
|
54 - SHIM 0.3 MM
BSD-2600100607.A994
2600100607
|
£1.75
|
£2.10
|
|
|
55 - ADJUSTING SLIDE
BSD-2602033007.A24
2602033007
|
-
|
|
|
|
56 - ROTARY KNOB
BSD-2602026006.A27
2602026006
|
£4.26
|
£5.11
|
|
|
57 - RATCHET CAP
BSD-2600590006.A1156
2600590006
|
£1.84
|
£2.21
|
|
|
58 - SHIM WASHER
BSD-2600100618.A201
2600100618
|
£1.84
|
£2.21
|
|
|
60 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A482
2600914010
|
£2.94
|
£3.53
|
|
|
61 - HOLDING PIN
BSD-2603105043.A24
2603105043
|
-
|
|
|
|
63 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1556
2603490017
|
£2.27
|
£2.72
|
|
|
70 - CABLE L=130 MM
BSD-2604448005.A438
2604448005
|
£1.84
|
£2.21
|
|
|
71 - CONNECTING CABLE L=68 MM
BSD-2604448100.A79
2604448100
|
£1.75
|
£2.10
|
|
|
71 - CONNECTING CABLE L=96MM
BSD-2604448133.A6
2604448133
|
£2.80
|
£3.36
|
|
|
753 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A242
1619P10682
|
£12.49
|
£14.99
|
|
|
753/20 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A898
2915011007
|
-
|
|
|
|
753/30 - WING SCREW M6x(15)55
BSD-1613480007.A326
1613480007
|
£1.75
|
£2.10
|
|
|
753/50 - CLAMPING PLATE M6
BSD-2608040014.A386
2608040014
|
-
|
|
|
|
753/60 - WING SCREW M6x20 MM
BSD-1613480008.A96
1613480008
|
£1.84
|
£2.21
|
|
|
754 - DEPTH-GAUGE
BSD-2603001019.A176
2603001019
|
£2.63
|
£3.16
|
|
|
808 - REFERENCE PLATE
BSD-9920490116.A4
9920490116
|
£4.48
|
£5.37
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A412
2604321905
|
£11.87
|
£14.24
|
|
|
810 - CARBON-BRUSH SET 10 x 2 604 321 905
BSD-1607000484.A18
1607000484
|
£75.79
|
£90.95
|
|
|
825 - GEAR HOUSING
BSD-2605806997.A27
2605806997
|
£43.71
|
£52.45
|
|
|
828 - INTERMEDIATE FLANGE
BSD-2605700940.A18
2605700940
|
£25.68
|
£30.81
|
|
|
851 - TOOTHED SHAFT Z=29/18/11
BSD-2606308915.A17
2606308915
|
£36.63
|
£43.96
|
|
|
859 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A39
2916080007
|
£2.74
|
£3.29
|
|
