1 - MOTOR HOUSING
BSD-1615102161.A6
1615102161
|
£27.23
|
£32.68
|
|
|
2 - FIELD 115V
BSD-1614220200.A1
1614220200
|
£35.42
|
£42.51
|
|
|
4 - SWITCH
BSD-1617200120.A5
1617200120
|
£19.45
|
£23.34
|
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.5mm H07 RN-F
BSD-1604460201.A12
1604460201
|
£37.27
|
£44.72
|
|
|
6 - GROMMET dia8.7-dia9.6x66 MM
BSD-1600703035.A22
1600703035
|
£2.94
|
£3.53
|
|
|
7 - FASTENING CLAMP
BSD-1601302019.A56
1601302019
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-160111C0U6.A5
160111C0U6
|
£2.74
|
£3.29
|
|
|
13 - GROOVE BALL BEARING 8x24x8
BSD-1610900026.A73
1610900026
|
£12.64
|
£15.17
|
|
|
14 - GROOVE BALL BEARING 12x32x10
BSD-1610905028.A46
1610905028
|
£16.41
|
£19.69
|
|
|
15 - FAN
BSD-1616610090.A14
1616610090
|
£12.04
|
£14.45
|
|
|
21 - PROTECTIVE CAP
BSD-1610508038.A60
1610508038
|
£8.54
|
£10.25
|
|
|
22 - PROTECTION SLEEVE
BSD-1610591027.A8
1610591027
|
£6.85
|
£8.22
|
|
|
23 - STOP SLEEVE
BSD-1610520001.A7
1610520001
|
£12.64
|
£15.17
|
|
|
25 - STOPPING DEVICE
BSD-1612300036.A1
1612300036
|
£13.78
|
£16.54
|
|
|
26 - INDEXING DISK
BSD-1610290076.A21
1610290076
|
£6.85
|
£8.22
|
|
|
27 - AIR-DEFLECTOR RING
BSD-1610591028.A8
1610591028
|
£2.61
|
£3.13
|
|
|
28 - COMPRESSION SPRING
BSD-1614621000.A127
1614621000
|
£2.94
|
£3.53
|
|
|
31 - DAMPING RING
BSD-1610290049.A45
1610290049
|
£2.94
|
£3.53
|
|
|
34 - FLANGE
BSD-1610516013.A53
1610516013
|
£1.84
|
£2.21
|
|
|
35/2 - SPRING RETAINING RING
BSD-160015001F.A2
160015001F
|
£2.27
|
£2.72
|
|
|
37 - BEARING PEDESTAL
BSD-1615500393.A2
1615500393
|
£9.11
|
£10.93
|
|
|
38 - COVERING HOOD
BSD-1615190159.A7
1615190159
|
£16.41
|
£19.69
|
|
|
42 - BRUSH HOLDER
BSD-1614336085.A8
1614336085
|
£39.13
|
£46.96
|
|
|
43 - FAN COVER
BSD-1615500410.A14
1615500410
|
£13.78
|
£16.54
|
|
|
44 - COMPRESSION SPRING
BSD-1614617004.A1
1614617004
|
£2.80
|
£3.36
|
|
|
45 - CONTROL BUSHING
BSD-1610499070.A4
1610499070
|
£19.91
|
£23.89
|
|
|
47 - GEAR SLEEVE
BSD-1610300064.A24
1610300064
|
£6.52
|
£7.83
|
|
|
48 - CLUTCH SLEEVE
BSD-1616334012.A20
1616334012
|
£5.57
|
£6.68
|
|
|
51 - CROWN GEAR
BSD-1616333041.A23
1616333041
|
£36.63
|
£43.96
|
|
|
53 - SUPPORT DISC
BSD-1610290068.A13
1610290068
|
£3.91
|
£4.69
|
|
|
57 - STRIKER
BSD-1618710091.A9
1618710091
|
£27.23
|
£32.68
|
|
|
72 - ECCENTRIC COG WHEEL
BSD-1600A00ZZ3.A10
1600A00ZZ3
|
£70.24
|
£84.29
|
|
|
74 - GUIDE PLATE
BSD-1611921001.A27
1611921001
|
£2.61
|
£3.13
|
|
|
75 - HANDLE
BSD-1615132118.A7
1615132118
|
£50.80
|
£60.96
|
|
|
79 - TORX OVAL-HEAD SCREW M5x12-TORX.T25
BSD-1613435015.A8
1613435015
|
£2.74
|
£3.29
|
|
|
80 - SPEED GOVERNOR
BSD-1617233048.A0
1617233048
|
£72.18
|
£86.62
|
|
|
81 - HANDLE COVER
BSD-1615132088.A25
1615132088
|
£21.68
|
£26.01
|
|
|
84 - AUXILIARY HANDLE
BSD-160202507H.A397
160202507H
|
£11.87
|
£14.24
|
|
|
85 - SUPPORT CLAMP
BSD-1618040074.A25
1618040074
|
£5.30
|
£6.36
|
|
|
86 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A141
1613490002
|
£4.48
|
£5.37
|
|
|
87 - CLAMPING BAND dia62 MM
BSD-1611316019.A29
1611316019
|
£4.26
|
£5.11
|
|
|
94 - FRICTION WASHER
BSD-1610102056.A15
1610102056
|
£2.80
|
£3.36
|
|
|
95 - O-RING 32.0x1.5 MM
BSD-1610210173.A23
1610210173
|
£2.16
|
£2.59
|
|
|
97 - LOCKING WASHER
BSD-1610031005.A19
1610031005
|
£3.91
|
£4.69
|
|
|
99 - SUPPORT DISC
BSD-1610102059.A18
1610102059
|
£2.61
|
£3.13
|
|
|
102 - SHIM 0.3 MM
BSD-1610102057.A18
1610102057
|
£1.84
|
£2.21
|
|
|
102 - SHIM 0.2 MM
BSD-1610102058.A15
1610102058
|
£1.84
|
£2.21
|
|
|
104 - O-RING 52.0x2.0 MM
BSD-1610210160.A6
1610210160
|
£3.91
|
£4.69
|
|
|
106 - RETAINING SNAP RING
BSD-1610499073.A12
1610499073
|
£6.85
|
£8.22
|
|
|
111 - BUSHING
BSD-1610290064.A47
1610290064
|
£1.84
|
£2.21
|
|
|
112 - HEX NUT DIN 936-M8x1-8
BSD-1613300008.A50
1613300008
|
£2.74
|
£3.29
|
|
|
113 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A268
1613435009
|
£1.75
|
£2.10
|
|
|
117 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913029.A25
1610913029
|
£4.48
|
£5.37
|
|
|
120 - STOP SLEEVE
BSD-1610590019.A10
1610590019
|
£18.96
|
£22.75
|
|
|
126 - SCREW 4x16
BSD-2603490022.A874
2603490022
|
£1.84
|
£2.21
|
|
|
138 - SEALING FRAME
BSD-1611015053.A3
1611015053
|
£12.04
|
£14.45
|
|
|
141 - ROTARY SHAFT LIP SEAL
BSD-1610290066.A51
1610290066
|
£10.61
|
£12.73
|
|
|
142 - ROTARY SHAFT LIP SEAL
BSD-1610290069.A24
1610290069
|
£5.87
|
£7.04
|
|
|
143 - RETAINING RING DIN 7993-28x2
BSD-1614601021.A88
1614601021
|
£7.72
|
£9.27
|
|
|
144 - SUPPORTING DISC
BSD-1610251006.A34
1610251006
|
£5.58
|
£6.70
|
|
|
145 - SPRING RETAINING RING
BSD-1610119012.A39
1610119012
|
£2.74
|
£3.29
|
|
|
154 - SPRING RETAINING RING DIN 472 52x2MM
BSD-2916660023.A11
2916660023
|
£5.30
|
£6.36
|
|
|
160 - DAMPING RING
BSD-1610290095.A9
1610290095
|
£11.30
|
£13.56
|
|
|
161 - DAMPING RING
BSD-1610290094.A8
1610290094
|
£4.48
|
£5.37
|
|
|
162 - O-RING 22.5x3.5 MM
BSD-1610210204.A4
1610210204
|
£5.87
|
£7.04
|
|
|
163 - SEAL RING
BSD-1610290065.A10
1610290065
|
£8.54
|
£10.25
|
|
|
165 - O-RING 22.0x4.0 MM
BSD-1610210079.A36
1610210079
|
£5.87
|
£7.04
|
|
|
167 - ROTARY SHAFT LIP SEAL
BSD-1610283033.A25
1610283033
|
£6.85
|
£8.22
|
|
|
168 - O-RING 22.0x3.0 MM
BSD-1610210144.A46
1610210144
|
£5.30
|
£6.36
|
|
|
171 - TORX OVAL-HEAD SCREW M5x20-TORX.T25
BSD-1613435016.A21
1613435016
|
£2.16
|
£2.59
|
|
|
172 - TORX OVAL-HEAD SCREW M6x30-TORX.T30
BSD-1613435013.A9
1613435013
|
£2.16
|
£2.59
|
|
|
174 - TORX OVAL-HEAD SCREW M4.8x25-TORX.T25
BSD-1613435012.A98
1613435012
|
£2.27
|
£2.72
|
|
|
175 - TAPPING SCREW DIN7981-ST3.9x13-C-Z
BSD-2912401018.A459
2912401018
|
£1.75
|
£2.10
|
|
|
176 - TORX OVAL-HEAD SCREW M4.8x25-TORX.T25
BSD-1613435012.A99
1613435012
|
£2.27
|
£2.72
|
|
|
177 - TAPPING SCREW ST3.9x32
BSD-1603435051.A4
1603435051
|
£2.05
|
£2.46
|
|
|
192 - COMPRESSION SPRING
BSD-1614611019.A3
1614611019
|
£2.61
|
£3.13
|
|
|
195 - TORX OVAL-HEAD SCREW
BSD-1613490015.A13
1613490015
|
£2.61
|
£3.13
|
|
|
196 - SCREW AND WASHER ASSEMBLY
BSD-1613435019.A5
1613435019
|
£1.75
|
£2.10
|
|
|
198 - CONTROL LEVER
BSD-1618900001.A5
1618900001
|
£5.87
|
£7.04
|
|
|
200 - BELLOWS
BSD-1610284000.A9
1610284000
|
£10.61
|
£12.73
|
|
|
202 - SWITCH HOOK
BSD-1611010006.A15
1611010006
|
£5.57
|
£6.68
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A257
1615430010
|
£6.85
|
£8.22
|
|
|
691 - CARRYING CASE
BSD-1615438461.A3
1615438461
|
£45.67
|
£54.80
|
|
|
803 - ARMATURE 120V
BSD-1614011128.A1
1614011128
|
£142.02
|
£170.42
|
|
|
808 - NAMEPLATE
BSD-160111A3H5.A394
160111A3H5
|
£2.74
|
£3.29
|
|
|
811 - CARBON-BRUSH SET
BSD-1617014144.A14
1617014144
|
£22.60
|
£27.12
|
|
|
816 - SOCKET HEAD CAP SCREW
BSD-1609271281.A22
1609271281
|
£1.84
|
£2.21
|
|
|
817 - SPIRAL SPRING
BSD-1614652004.A76
1614652004
|
£7.72
|
£9.27
|
|
|
818 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x6-5.8
BSD-2910011082.A73
2910011082
|
£1.75
|
£2.10
|
|
|
821 - BUSHING
BSD-1617000A02.A7
1617000A02
|
£25.05
|
£30.06
|
|
|
825 - BEARING SHAFT
BSD-1617000706.A11
1617000706
|
£12.64
|
£15.17
|
|
|
830 - SUPPORTING DISC
BSD-1617000478.A10
1617000478
|
£7.72
|
£9.27
|
|
|
835 - HAMMER PIPE
BSD-1617000A4J.A3
1617000A4J
|
£156.22
|
£187.46
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1617000A03.A2
1617000A03
|
£121.96
|
£146.35
|
|
|
841 - STRIKER PIN
BSD-1617000899.A9
1617000899
|
£42.84
|
£51.41
|
|
|
849 - CONTROL FORK
BSD-1617000839.A26
1617000839
|
£23.86
|
£28.63
|
|
|
854 - GUIDE BUSHING
BSD-1617000718.A4
1617000718
|
£31.64
|
£37.97
|
|
|
856 - HAMMER PISTON
BSD-1617000A04.A7
1617000A04
|
£25.05
|
£30.06
|
|
|
860 - SPUR WHEEL CLUTCH
BSD-1617000A37.A2
1617000A37
|
£108.30
|
£129.96
|
|
|
873 - HOUSING COVER
BSD-1617000A05.A2
1617000A05
|
£63.50
|
£76.20
|
|
|
884 - AUXILIARY HANDLE dia62 MM
BSD-1612025055.A27
1612025055
|
£42.84
|
£51.41
|
|
|
886 - AUXILIARY HANDLE M8
BSD-1617000459.A29
1617000459
|
£13.78
|
£16.54
|
|
|
890 - GREASE TUBE 225 ML
BSD-1615430015.A12
1615430015
|
£39.13
|
£46.96
|
|
|
891 - SPRING PACK
BSD-1617000A26.A12
1617000A26
|
£25.05
|
£30.06
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000A4L.A1
1617000A4L
|
£59.53
|
£71.44
|
|
