1 - MOTOR HOUSING
BSD-1615102142.A31
1615102142
|
£22.60
|
£27.12
|
|
|
2 - FIELD 100V
BSD-1614220132.A6
1614220132
|
£35.42
|
£42.51
|
|
|
4 - SWITCH
BSD-1617200048.A45
1617200048
|
£18.96
|
£22.75
|
|
|
4/10 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x12-5.8
BSD-2910011088.A87
2910011088
|
£1.84
|
£2.21
|
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.0mm H07RN-F
BSD-1614460060.A12
1614460060
|
-
|
|
|
|
6 - GROMMET dia9.7-dia12x89 MM
BSD-1610703053.A132
1610703053
|
£2.74
|
£3.29
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A662
3600703011
|
£2.94
|
£3.53
|
|
|
7 - FASTENING CLAMP
BSD-1601302018.A636
1601302018
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110672.A2
1611110672
|
-
|
|
|
|
13 - GROOVE BALL BEARING 7x22x7
BSD-1610900025.A123
1610900025
|
£16.41
|
£19.69
|
|
|
15 - FAN
BSD-1616610071.A27
1616610071
|
£9.49
|
£11.39
|
|
|
19 - GUIDE TUBE
BSD-1615806121.A1
1615806121
|
-
|
|
|
|
20 - TOOLHOLDER
BSD-1618597071.A18
1618597071
|
-
|
|
|
|
21 - PROTECTIVE CAP
BSD-1610508017.A23
1610508017
|
£3.91
|
£4.69
|
|
|
22 - PROTECTION SLEEVE
BSD-1610591009.A29
1610591009
|
-
|
|
|
|
23 - STOP SLEEVE
BSD-1610520001.A91
1610520001
|
£12.64
|
£15.17
|
|
|
25 - STOPPING DEVICE
BSD-1612300027.A107
1612300027
|
£11.87
|
£14.24
|
|
|
26 - INDEXING DISK
BSD-1610290025.A47
1610290025
|
£6.85
|
£8.22
|
|
|
27 - RETAINING SNAP RING
BSD-1610222008.A20
1610222008
|
-
|
|
|
|
28 - COMPRESSION SPRING
BSD-1614621000.A17
1614621000
|
£2.94
|
£3.53
|
|
|
29 - COMPRESSION SPRING
BSD-1614616008.A19
1614616008
|
£2.74
|
£3.29
|
|
|
30 - BALL RACE
BSD-1610250007.A20
1610250007
|
-
|
|
|
|
31 - SPACER TUBE
BSD-1610390015.A60
1610390015
|
-
|
|
|
|
32 - CYLINDER SLEEVE
BSD-1610202016.A7
1610202016
|
-
|
|
|
|
34 - SUPPORTING DISC 1.5 MM
BSD-1610102622.A16
1610102622
|
£1.95
|
£2.34
|
|
|
35 - HAMMER PIPE
BSD-1615806089.A31
1615806089
|
-
|
|
|
|
38 - COVERING HOOD
BSD-1615190064.A6
1615190064
|
-
|
|
|
|
39 - CLUTCH RING
BSD-1610290024.A20
1610290024
|
-
|
|
|
|
41 - STRIKER PIN
BSD-1613124036.A28
1613124036
|
-
|
|
|
|
46 - SEALING FRAME
BSD-1611015036.A22
1611015036
|
-
|
|
|
|
47 - COVER
BSD-1610591012.A14
1610591012
|
£1.84
|
£2.21
|
|
|
51 - CROWN GEAR Z=37
BSD-1616333023.A13
1616333023
|
-
|
|
|
|
53 - STOP DISC
BSD-1610190023.A21
1610190023
|
£5.30
|
£6.36
|
|
|
54 - STOP DISC
BSD-1610101014.A46
1610101014
|
-
|
|
|
|
57 - STRIKER
BSD-1618710053.A13
1618710053
|
-
|
|
|
|
72 - ECCENTRIC COG WHEEL Z=35
BSD-1616337004.A5
1616337004
|
-
|
|
|
|
75 - HANDLE
BSD-1615132059.A5
1615132059
|
-
|
|
|
|
80 - SPEED GOVERNOR 100-120V
BSD-1617233025.A3
1617233025
|
-
|
|
|
|
81 - SWITCH-PAWL
BSD-1612026055.A10
1612026055
|
£8.67
|
£10.41
|
|
|
84 - AUXILIARY HANDLE
BSD-160202507H.A237
160202507H
|
£11.87
|
£14.24
|
|
|
85 - SUPPORT CLAMP dia 70 MM
BSD-1618040056.A0
1618040056
|
-
|
|
|
|
86 - T-HEAD BOLT M8x80 MM
BSD-1613490001.A29
1613490001
|
£9.11
|
£10.93
|
|
|
87 - CLAMPING BAND dia70 MM
BSD-1611316008.A8
1611316008
|
-
|
|
|
|
94 - SPRING RETAINING RING
BSD-1610119007.A21
1610119007
|
-
|
|
|
|
96 - SPRING RETAINING RING 55x2MM. DIN 472
BSD-2916660024.A50
2916660024
|
£5.57
|
£6.68
|
|
|
97 - SHIM RING DIN 988-45x55
BSD-2916190284.A34
2916190284
|
-
|
|
|
|
98 - FRICTION WASHER 0.5 MM
BSD-1610101622.A20
1610101622
|
-
|
|
|
|
99 - HOLDING PLATE
BSD-1610190030.A16
1610190030
|
£3.91
|
£4.69
|
|
|
101 - O-RING 20.0x3.0 MM
BSD-1610210094.A30
1610210094
|
£2.80
|
£3.36
|
|
|
102 - O-RING 55.0x2.0 MM
BSD-1610210095.A7
1610210095
|
£2.74
|
£3.29
|
|
|
103 - O-RING 27.0x1.5 MM
BSD-1610210100.A28
1610210100
|
£3.91
|
£4.69
|
|
|
104 - O-RING 17.0x8.0 MM
BSD-1610210093.A39
1610210093
|
£1.75
|
£2.10
|
|
|
105 - O-RING 21.0x3.5 MM
BSD-1610210096.A39
1610210096
|
£2.94
|
£3.53
|
|
|
107 - O-RING 14.0x2.0 MM
BSD-1610210116.A43
1610210116
|
£2.80
|
£3.36
|
|
|
108 - O-RING 8.0x1.5 MM
BSD-1900210103.A72
1900210103
|
£2.94
|
£3.53
|
|
|
109 - ROTARY SHAFT LIP SEAL DIN 3760-BS. dia40x55x7 MM
BSD-1610283028.A16
1610283028
|
£5.58
|
£6.70
|
|
|
110 - SPRING RETAINING RING
BSD-1610116003.A21
1610116003
|
-
|
|
|
|
111 - O-RING 10.0x1.0 MM
BSD-1610210081.A20
1610210081
|
£3.72
|
£4.47
|
|
|
112 - THREADED RING M24x1.5MM. SW10
BSD-1613461001.A16
1613461001
|
-
|
|
|
|
113 - BUSHING
BSD-1610501036.A18
1610501036
|
£9.11
|
£10.93
|
|
|
116 - SPRING RETAINING RING
BSD-1610116004.A24
1610116004
|
£1.75
|
£2.10
|
|
|
117 - SPRING RETAINING RING
BSD-1610119008.A15
1610119008
|
£2.45
|
£2.94
|
|
|
118 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913009.A16
1610913009
|
-
|
|
|
|
119 - NEEDLE-ROLLER ASSEMBLY dia10 MM
BSD-1610913011.A26
1610913011
|
£6.52
|
£7.83
|
|
|
121 - GROOVE BALL BEARING
BSD-1610905014.A34
1610905014
|
-
|
|
|
|
122 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913029.A93
1610913029
|
£4.48
|
£5.37
|
|
|
124 - THRUST BEARING DISC 1.0 MM
BSD-1610101008.A57
1610101008
|
-
|
|
|
|
125 - TAPPING SCREW DIN7981-ST4.8x25-C-Z
BSD-2912401036.A16
2912401036
|
£1.32
|
£1.58
|
|
|
126 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A528
2910211019
|
£1.84
|
£2.21
|
|
|
127 - OVAL-HEAD SCREW DIN 7985-M5x30-8.8
BSD-2912311166.A16
2912311166
|
£1.84
|
£2.21
|
|
|
128 - TAPPING SCREW DIN 7971-BZ4.8x32
BSD-2910211037.A75
2910211037
|
£1.84
|
£2.21
|
|
|
129 - TAPPING SCREW DIN 7981-ST4.8x32C-Z
BSD-2912401037.A21
2912401037
|
£1.84
|
£2.21
|
|
|
131 - MANUFACTURER'S NAMEPLATE
BSD-1611110673.A8
1611110673
|
£2.80
|
£3.36
|
|
|
132 - MICROENCAPSULATED SCREW DIN 912-M 5x12-8.8
BSD-2914551117.A78
2914551117
|
£1.84
|
£2.21
|
|
|
136 - TAPPING SCREW DIN 7971-ST4.8x25-C
BSD-2910211236.A90
2910211236
|
£1.75
|
£2.10
|
|
|
139 - FELT DISC dia39x15 MM
BSD-1610005002.A31
1610005002
|
-
|
|
|
|
139 - RETAINING BRACKET
BSD-1617000291.A56
1617000291
|
-
|
|
|
|
148 - SHIM 0.3 MM
BSD-1610102633.A16
1610102633
|
-
|
|
|
|
148 - SHIM 0.2 MM
BSD-1610102627.A20
1610102627
|
-
|
|
|
|
149 - ADAPTING PIECE
BSD-1612388021.A21
1612388021
|
-
|
|
|
|
150 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A162
1900452012
|
£1.75
|
£2.10
|
|
|
151 - O-RING 21.0x2.0 MM
BSD-2600210028.A19
2600210028
|
£1.38
|
£1.66
|
|
|
152 - COVER
BSD-1610508030.A33
1610508030
|
-
|
|
|
|
154 - RETAINING SNAP RING
BSD-1610222010.A13
1610222010
|
£9.49
|
£11.39
|
|
|
750 - CARRYING CASE
BSD-2605438314.A8
2605438314
|
-
|
|
|
|
784 - AUXILIARY HANDLE dia 70 MM. M8
BSD-2602025062.A3
2602025062
|
£44.12
|
£52.94
|
|
|
800 - CLAMP HANDLE
BSD-1617000945.A9
1617000945
|
-
|
|
|
|
803 - ARMATURE 100-110V
BSD-1614010187.A6
1614010187
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3207
160111A3H3
|
£2.74
|
£3.29
|
|
|
814 - GROOVE BALL BEARING
BSD-1617000822.A2
1617000822
|
-
|
|
|
|
824 - CYLINDRICAL ROLLER
BSD-1617000271.A36
1617000271
|
£4.48
|
£5.37
|
|
|
833 - CONTROL FORK
BSD-1617000949.A21
1617000949
|
-
|
|
|
|
837 - RETAINING BRACKET
BSD-1617000291.A55
1617000291
|
-
|
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1617000811.A28
1617000811
|
-
|
|
|
|
842 - BRUSH HOLDER
BSD-1614336009.A20
1614336009
|
-
|
|
|
|
842/020 - BRUSH GUIDE
BSD-1614336043.A31
1614336043
|
-
|
|
|
|
842/040 - CARBON-BRUSH SET
BSD-1617014122.A29
1617014122
|
£18.96
|
£22.75
|
|
|
842/40 - CARBON-BRUSH SET 10 x 1 617 014 122
BSD-1607000497.A10
1607000497
|
£120.11
|
£144.13
|
|
|
842/050 - RUBBER BUFFER
BSD-1613212004.A39
1613212004
|
£3.72
|
£4.47
|
|
|
842/080 - TAPPING SCREW DIN7981-ST2.9x9.5C-Z
BSD-2912401005.A228
2912401005
|
£1.84
|
£2.21
|
|
|
843 - BEARING COVER
BSD-1615808078.A4
1615808078
|
-
|
|
|
|
845 - GEAR HOUSING
BSD-1617000823.A15
1617000823
|
-
|
|
|
|
845 - GEAR HOUSING
BSD-1617000962.A28
1617000962
|
-
|
|
|
|
848 - CLUTCH SLEEVE
BSD-1617000415.A16
1617000415
|
-
|
|
|
|
856 - HAMMER PISTON
BSD-1617000999.A21
1617000999
|
-
|
|
|
|
860 - SPUR WHEEL CLUTCH
BSD-1617000817.A2
1617000817
|
-
|
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000272.A3
1617000272
|
-
|
|
|
|
898 - WEAR AND TEAR PART SET
BSD-1617000273.A17
1617000273
|
-
|
|
|
|
899 - HOLDING PLATE
BSD-1617000293.A3
1617000293
|
-
|
|
|
