1 - HOUSING SECTION
BSD-1615104005.A7
1615104005
|
-
|
|
|
|
3 - DC MOTOR 230V
BSD-1617220011.A7
1617220011
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200269.A4
2607200269
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110543.A2
1611110543
|
-
|
|
|
|
11 - MANUFACTURER'S NAMEPLATE
BSD-1611110544.A2
1611110544
|
-
|
|
|
|
15 - DRIVE PINION Z=8
BSD-1616333024.A4
1616333024
|
-
|
|
|
|
16 - REFERENCE PLATE
BSD-1611110539.A3
1611110539
|
-
|
|
|
|
17 - GUIDE SLEEVE
BSD-1615819013.A43
1615819013
|
£6.94
|
£8.33
|
|
|
18 - FLANGED BEARING
BSD-1615700027.A37
1615700027
|
-
|
|
|
|
20 - DRIVE BEARING
BSD-1615819012.A5
1615819012
|
-
|
|
|
|
24 - PROTECTIVE GRILLE
BSD-1612388019.A34
1612388019
|
-
|
|
|
|
25 - TOOTHED SHAFT Z=9
BSD-1613160008.A6
1613160008
|
-
|
|
|
|
26 - CYLINDRICAL GEAR Z=31
BSD-1616317600.A29
1616317600
|
£2.64
|
£3.17
|
|
|
27 - CYLINDRICAL GEAR Z=48
BSD-1616317034.A10
1616317034
|
-
|
|
|
|
28 - SEAL RING
BSD-1611015034.A49
1611015034
|
-
|
|
|
|
29 - SEAL RING
BSD-1611015035.A4
1611015035
|
-
|
|
|
|
31 - PRESSURE LEVER
BSD-1611329009.A4
1611329009
|
-
|
|
|
|
33 - PISTON PIN
BSD-1613103006.A37
1613103006
|
-
|
|
|
|
34 - SHIM WASHER 1.2 MM
BSD-1610100608.A19
1610100608
|
£1.84
|
£2.21
|
|
|
36 - SUPPORTING DISC
BSD-1610102024.A40
1610102024
|
-
|
|
|
|
39 - PROTECTIVE CAP L=17 MM. SDS-PLUS
BSD-1610508008.A166
1610508008
|
£2.27
|
£2.72
|
|
|
40 - SEALING FRAME
BSD-1611015033.A8
1611015033
|
-
|
|
|
|
43 - HOLDING PLATE
BSD-1611031005.A35
1611031005
|
-
|
|
|
|
44 - COMPRESSION SPRING
BSD-1614634002.A23
1614634002
|
-
|
|
|
|
45 - COMPRESSION SPRING
BSD-1614610005.A44
1614610005
|
-
|
|
|
|
46 - RETAINING SNAP RING
BSD-1610200014.A34
1610200014
|
-
|
|
|
|
47 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913008.A8
1610913008
|
-
|
|
|
|
48 - NEEDLE BEARING
BSD-1610910071.A36
1610910071
|
£6.85
|
£8.22
|
|
|
49 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A132
2600917003
|
£2.94
|
£3.53
|
|
|
50 - ROLLER-CAGE ASSEMBLY
BSD-1610920002.A22
1610920002
|
£3.91
|
£4.69
|
|
|
51 - SUPPORT DISC 1.0 MM
BSD-1610102617.A9
1610102617
|
£2.27
|
£2.72
|
|
|
52 - THRUST NEEDLE RIM
BSD-1610920005.A47
1610920005
|
-
|
|
|
|
53 - SUPPORT DISC
BSD-1610100602.A34
1610100602
|
-
|
|
|
|
54 - SHIM 0.6 MM
BSD-1610100604.A19
1610100604
|
-
|
|
|
|
54 - SHIM 0.8 MM
BSD-1610100605.A40
1610100605
|
-
|
|
|
|
54 - SHIM 1.0 MM
BSD-1610100606.A19
1610100606
|
-
|
|
|
|
54 - SHIM 1.2 MM
BSD-1610100607.A34
1610100607
|
-
|
|
|
|
58 - CONTACT SPRING 2.5 MM
BSD-1614449007.A9
1614449007
|
-
|
|
|
|
59 - CONTACT SPRING 2.5 MM
BSD-1614449009.A4
1614449009
|
-
|
|
|
|
59/10 - CONTACT SPRING
BSD-1611290002.A5
1611290002
|
-
|
|
|
|
60 - O-RING 13.0x2.5 MM
BSD-1610210086.A56
1610210086
|
-
|
|
|
|
61 - O-RING 10.5x2.7 MM
BSD-1610210046.A21
1610210046
|
£2.16
|
£2.59
|
|
|
63 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A748
1903230013
|
£2.27
|
£2.72
|
|
|
64 - RETAINING RING
BSD-1614601007.A9
1614601007
|
-
|
|
|
|
66 - RUBBER RING
BSD-1610206025.A9
1610206025
|
-
|
|
|
|
68 - STRAIGHT PIN DIN 6325-5M6x45
BSD-2917550133.A13
2917550133
|
£2.33
|
£2.80
|
|
|
69 - TAPPING SCREW DIN7981-ST2.9x9.5C-Z
BSD-2912401005.A217
2912401005
|
£1.84
|
£2.21
|
|
|
70 - TAPPING SCREW DIN 7981-ST3.9x25-C-Z
BSD-2912401022.A0
2912401022
|
£1.84
|
£2.21
|
|
|
72 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A256
2912401019
|
£1.84
|
£2.21
|
|
|
73 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2842
2603410001
|
£1.84
|
£2.21
|
|
|
74 - OVAL-HEAD SCREW DIN 7985 M 3x8-5.8-Z
BSD-2912451050.A5
2912451050
|
-
|
|
|
|
75 - ROTARY SHAFT LIP SEAL
BSD-1610283021.A9
1610283021
|
-
|
|
|
|
76 - EXPANSION BUSHING
BSD-1610390020.A0
1610390020
|
-
|
|
|
|
78 - ROLLER-CAGE ASSEMBLY
BSD-1610920006.A6
1610920006
|
£2.52
|
£3.02
|
|
|
79 - SUPPORT DISC
BSD-1610100609.A34
1610100609
|
-
|
|
|
|
80 - ADDITIONAL HOUSING
BSD-1615190031.A10
1615190031
|
-
|
|
|
|
81 - LOCATING RING
BSD-1610290017.A9
1610290017
|
-
|
|
|
|
82 - COVER DISC
BSD-1610516011.A0
1610516011
|
-
|
|
|
|
83 - HOLDING SPRING
BSD-1611290003.A9
1611290003
|
-
|
|
|
|
84 - PUSH-BUTTON
BSD-1612026034.A8
1612026034
|
-
|
|
|
|
85 - GUIDING PLATE
BSD-1611098003.A0
1611098003
|
-
|
|
|
|
86 - COOLING SHEET
BSD-1611329013.A3
1611329013
|
-
|
|
|
|
87 - CONNECTING CABLE
BSD-1614430028.A3
1614430028
|
-
|
|
|
|
88 - HOLDING BELT
BSD-2601398007.A5
2601398007
|
-
|
|
|
|
90 - SHRINKABLE TUBE
BSD-2600409018.A3
2600409018
|
-
|
|
|
|
91 - RETAINING RING DIN 7993-A22
BSD-2916540012.A215
2916540012
|
-
|
|
|
|
120 - AUXILIARY HANDLE
BSD-160202507H.A225
160202507H
|
£11.87
|
£14.24
|
|
|
121 - SUPPORT CLAMP dia43 MM
BSD-1618040048.A125
1618040048
|
£8.67
|
£10.41
|
|
|
122 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A462
1613490002
|
£4.48
|
£5.37
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316006.A123
1611316006
|
£2.61
|
£3.13
|
|
|
126 - STICKER
BSD-2601110461.A55
2601110461
|
-
|
|
|
|
700 - DRILL CHUCK SHANK
BSD-1617000132.A14
1617000132
|
£17.68
|
£21.22
|
|
|
700/20 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A281
2603421226
|
£1.84
|
£2.21
|
|
|
701 - KEY CHUCK R/L dia13 MM. 1/2-20 UNF
BSD-1608571062.A43
1608571062
|
£18.37
|
£22.04
|
|
|
701/7 - CHUCK WRENCH SG2
BSD-2607950007.A585
2607950007
|
£6.85
|
£8.22
|
|
|
702 - PARTS SET
BSD-1617000133.A248
1617000133
|
-
|
|
|
|
702/10/2 - RETAINING RING
BSD-2604601004.A276
2604601004
|
£1.75
|
£2.10
|
|
|
703 - DUST TRAY
BSD-1615439003.A66
1615439003
|
-
|
|
|
|
703/30 - RUBBER BUSHING dia5-7 MM
BSD-1610312001.A9
1610312001
|
-
|
|
|
|
703/651 - RUBBER BUSHING dia8-10 MM
BSD-1610312002.A130
1610312002
|
-
|
|
|
|
720 - AUXILIARY HANDLE dia43 MM
BSD-1612025032.A10
1612025032
|
£10.18
|
£12.22
|
|
|
720/800 - PARTS SET
BSD-1617000925.A112
1617000925
|
£16.41
|
£19.69
|
|
|
750 - CARRYING CASE
BSD-1615438188.A8
1615438188
|
-
|
|
|
|
752 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A181
1613001009
|
£3.91
|
£4.69
|
|
|
753 - ROTARY HAMMER BIT dia6x50 MM
BSD-1618596166.A8
1618596166
|
-
|
|
|
|
760 - FAST CHARGER J 100/7.2-14.4V. 30 MIN.
BSD-2607224711.A19
2607224711
|
-
|
|
|
|
760 - FAST CHARGER USA 120/7.2-24V. 1h
BSD-2607224431.A67
2607224431
|
£135.25
|
£162.30
|
|
|
760 - FAST CHARGER EU 230/7.2-24V. 1h
BSD-2607224425.A10
2607224425
|
£88.07
|
£105.68
|
|
|
760 - FAST CHARGER GB 230/7.2-24V. 1h
BSD-2607224427.A251
2607224427
|
£103.14
|
£123.77
|
|
|
760 - FAST CHARGER AUS 240/7.2-14.4V. 1h
BSD-2607224443.A68
2607224443
|
-
|
|
|
|
760 - FAST CHARGER 12-24V. 12 MIN
BSD-2607224170.A0
2607224170
|
-
|
|
|
|
777 - CHISEL ATTACHMENT
BSD-2607018296.A15
2607018296
|
£52.49
|
£62.99
|
|
|
778 - ANGLE DRILL HEAD
BSD-1618580000.A50
1618580000
|
£239.08
|
£286.90
|
|
|
789 - ACCUMULATOR BATTERY 12V. 1.2Ah. NiCd
BSD-2607335010.A8
2607335010
|
-
|
|
|
|
819 - RATCHET SLEEVE
BSD-1617000940.A8
1617000940
|
-
|
|
|
|
821 - PARTS SET
BSD-1617000230.A8
1617000230
|
-
|
|
|
|
830 - CLAMP HANDLE
BSD-1617000177.A9
1617000177
|
-
|
|
|
|
841 - PROTECTION SLEEVE
BSD-1617000163.A136
1617000163
|
£7.72
|
£9.27
|
|
|
877 - CHANGE-OVER SWITCH
BSD-2607200231.A146
2607200231
|
£17.22
|
£20.67
|
|
|
897 - THERMAL CONDUCTION COMPOU
BSD-3609391500.A5
3609391500
|
£57.02
|
£68.42
|
|
|
898 - GREASE TUBE 225 ML
BSD-3605430009.A46
3605430009
|
£47.95
|
£57.54
|
|
|
899 - CORDLESS ROTARY HAMMER
BSD-0611217720.A3
0611217720
|
-
|
|
|
