4 - COVERING HOOD
BSD-1609202692.A5
1609202692
|
-
|
|
|
|
5 - SOCKET
BSD-1609201707.A2
1609201707
|
-
|
|
|
|
6 - TAPPING SCREW DIN 7982-ST3.5x16-F-H
BSD-2910601412.A21
2910601412
|
£2.74
|
£3.29
|
|
|
8 - ON-OFF SWITCH
BSD-1609201706.A9
1609201706
|
£45.67
|
£54.80
|
|
|
10 - CABLE CLIP
BSD-1609202693.A13
1609202693
|
£1.38
|
£1.66
|
|
|
11 - NAMEPLATE
BSD-1601118264.A0
1601118264
|
-
|
|
|
|
16 - CONNECTOR CABLE
BSD-1609201708.A9
1609201708
|
£36.63
|
£43.96
|
|
|
17 - AIR-DEFLECTOR RING
BSD-1609201666.A27
1609201666
|
-
|
|
|
|
20 - SEAL RING
BSD-1609201669.A26
1609201669
|
£5.87
|
£7.04
|
|
|
23 - DAMPING PLATE
BSD-1609203478.A1
1609203478
|
-
|
|
|
|
24 - DAMPING PLATE
BSD-1609202764.A44
1609202764
|
-
|
|
|
|
25 - DAMPING PLATE
BSD-1609203423.A41
1609203423
|
-
|
|
|
|
26 - INTERMEDIATE FLANGE
BSD-1609203475.A7
1609203475
|
£35.12
|
£42.15
|
|
|
28 - AIR FILTER
BSD-1609201677.A24
1609201677
|
£2.05
|
£2.46
|
|
|
30 - SEAL
BSD-1609203499.A31
1609203499
|
-
|
|
|
|
30 - SEAL RING
BSD-1609202765.A5
1609202765
|
£10.61
|
£12.73
|
|
|
31 - TAPPING SCREW DIN 7981-B3.5x25
BSD-2910611015.A47
2910611015
|
£1.84
|
£2.21
|
|
|
32 - MANUFACTURER'S NAMEPLATE
BSD-1601118191.A5
1601118191
|
£5.58
|
£6.70
|
|
|
35 - TAPPING SCREW DIN 7981-B3.5x25
BSD-2910611015.A46
2910611015
|
£1.84
|
£2.21
|
|
|
35 - TAPPING SCREW 3.5x32 MM
BSD-1609201681.A10
1609201681
|
-
|
|
|
|
36 - AUTOMATIC SWITCHING UNIT
BSD-1609203C05.A7
1609203C05
|
-
|
|
|
|
37 - INTERMEDIATE HOUSING
BSD-1609202698.A26
1609202698
|
-
|
|
|
|
38 - FLOAT
BSD-1609200952.A45
1609200952
|
-
|
|
|
|
39 - SUCTION BASKET
BSD-1609201684.A92
1609201684
|
-
|
|
|
|
43/20 - STAR KNOB
BSD-1609202200.A12
1609202200
|
-
|
|
|
|
43/30 - REFERENCE PLATE
BSD-1601110830.A38
1601110830
|
£2.74
|
£3.29
|
|
|
58 - DAMPING DISC
BSD-1609203714.A21
1609203714
|
-
|
|
|
|
217 - AIR-DEFLECTOR RING
BSD-1609203B12.A18
1609203B12
|
-
|
|
|
|
220 - SEAL RING
BSD-1609203B13.A26
1609203B13
|
£6.85
|
£8.22
|
|
|
222 - SUCTION BLOWER
BSD-1609203Z37.A35
1609203Z37
|
£264.25
|
£317.10
|
|
|
237 - INTERMEDIATE HOUSING
BSD-1609203B15.A15
1609203B15
|
-
|
|
|
|
650/20 - FITTING
BSD-1609203V36.A68
1609203V36
|
£25.05
|
£30.06
|
|
|
650/30 - FITTING dia 49 MM
BSD-1609390580.A1
1609390580
|
£5.58
|
£6.70
|
|
|
690 - DUST CONTAINER
BSD-1609203931.A0
1609203931
|
-
|
|
|
|
690/10 - IMPELLER dia 50 MM
BSD-1609202703.A13
1609202703
|
£6.85
|
£8.22
|
|
|
690/20 - IMPELLER dia 100 MM
BSD-1609202707.A5
1609202707
|
-
|
|
|
|
690/20 - IMPELLER dia 125 MM
BSD-1609202721.A1
1609202721
|
-
|
|
|
|
690/30 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A903
2603490024
|
£1.84
|
£2.21
|
|
|
690/40 - BENT-LEVER CLOSURE
BSD-1609202650.A13
1609202650
|
-
|
|
|
|
690/40 - BENT-LEVER CLOSURE
BSD-1609202708.A0
1609202708
|
-
|
|
|
|
690/50 - TAPPING SCREW DIN 7981-ST3.5x16-C-H
BSD-2910611012.A15
2910611012
|
-
|
|
|
|
690/60 - PLAIN WASHER dia4.2xdia11x1.2MM
BSD-1609202726.A48
1609202726
|
£1.75
|
£2.10
|
|
|
690/70 - LOCKING PIECE
BSD-1609203179.A17
1609203179
|
-
|
|
|
|
743 - AIR FILTER
BSD-2607432001.A5
2607432001
|
-
|
|
|
|
750 - AIR HOSE dia35MM.3M.1
BSD-2607000837.A16
2607000837
|
£62.47
|
£74.96
|
|
|
750/1 - AIR HOSE dia 35 MM. L=5 M
BSD-1609202230.A107
1609202230
|
£85.74
|
£102.89
|
|
|
751 - SETTING TUBE dia 35 MM
BSD-2607000164.A30
2607000164
|
£23.68
|
£28.42
|
|
|
752 - SUCTION PIPE dia 35 MM. 0.5 M
BSD-2607000162.A31
2607000162
|
£29.38
|
£35.25
|
|
|
753 - SUCTION NOZZLE dia 35 MM
BSD-2607000170.A37
2607000170
|
£13.78
|
£16.53
|
|
|
754 - SUCTION NOZZLE dia 35 MM
BSD-1609390478.A16
1609390478
|
£34.99
|
£41.99
|
|
|
754/10 - FLAT BRUSH
BSD-1609390493.A11
1609390493
|
£21.68
|
£26.01
|
|
|
754/20 - FLAT BRUSH
BSD-1609390494.A90
1609390494
|
-
|
|
|
|
754/30 - STRIP BRUSH
BSD-1609390495.A11
1609390495
|
£16.41
|
£19.69
|
|
|
755 - CREVICE NOZZLE dia 35 MM. L= 250 MM
BSD-2607000165.A86
2607000165
|
£5.24
|
£6.29
|
|
|
756 - SUCTION NOZZLE dia 35 MM
BSD-1609201229.A52
1609201229
|
£18.37
|
£22.04
|
|
|
757 - SUCTION NOZZLE dia 35 MM
BSD-1609201230.A86
1609201230
|
£41.99
|
£50.39
|
|
|
759 - SUCTION NOZZLE dia 35 MM
BSD-2607000166.A37
2607000166
|
£9.18
|
£11.01
|
|
|
759/20 - BRUSH INSERT
BSD-1609202534.A49
1609202534
|
£2.80
|
£3.36
|
|
|
761 - SUCTION BRUSH dia 35 MM
BSD-1609390481.A64
1609390481
|
£8.74
|
£10.49
|
|
|
762 - SUCTION NOZZLE dia 35 MM
BSD-2607000168.A37
2607000168
|
-
|
|
|
|
764 - FITTING dia 25x35 MM
BSD-1600499005.A40
1600499005
|
£6.99
|
£8.39
|
|
|
765 - REDUCTION SLEEVE dia 49/35 MM+3/4
BSD-1609200933.A79
1609200933
|
£7.57
|
£9.08
|
|
|
773 - DUST BAG
BSD-2605411061.A2
2605411061
|
£18.37
|
£22.04
|
|
|
777 - DEFLECTOR
BSD-2607001248.A16
2607001248
|
-
|
|
|
|
780 - AIR HOSE dia 49 MM. 3 M.1
BSD-2607000167.A71
2607000167
|
£67.98
|
£81.57
|
|
|
780/20 - FITTING dia 49 MM
BSD-1609390577.A28
1609390577
|
£5.58
|
£6.70
|
|
|
782 - SUCTION PIPE dia 49 MM. L=0.5 M
BSD-1609200968.A60
1609200968
|
£12.24
|
£14.69
|
|
|
783 - SUCTION NOZZLE dia 49 MM
BSD-2607000169.A28
2607000169
|
-
|
|
|
|
784 - SUCTION NOZZLE dia 49 MM. 350 MM
BSD-1609200970.A53
1609200970
|
£27.55
|
£33.06
|
|
|
784/10 - FLAT BRUSH
BSD-1609201109.A47
1609201109
|
-
|
|
|
|
784/20 - FLAT BRUSH
BSD-1609201110.A80
1609201110
|
-
|
|
|
|
786 - CREVICE NOZZLE dia 49 MM
BSD-1609200971.A69
1609200971
|
£7.87
|
£9.44
|
|
|
787 - SUCTION PIPE dia 49/35 MM
BSD-1609200976.A75
1609200976
|
£3.79
|
£4.55
|
|
|
822 - MODIFICATION SET 230V
BSD-1609203G98.A11
1609203G98
|
-
|
|
|
