6 - DRIVE BUSHING
BSD-2606445005.A1
2606445005
|
-
|
|
|
|
12 - RETAINING RING 16 DIN 9045
BSD-2916600009.A18
2916600009
|
£1.75
|
£2.10
|
|
|
13 - GUIDE SLEEVE
BSD-2600460016.A5
2600460016
|
-
|
|
|
|
14 - CAPSULE
BSD-2600516009.A15
2600516009
|
-
|
|
|
|
15 - DEPTH-GAUGE
BSD-2600460901.A10
2600460901
|
-
|
|
|
|
17 - NEEDLE BEARING
BSD-2600914015.A10
2600914015
|
-
|
|
|
|
19 - SUPPORTING DISC
BSD-2600103015.A7
2600103015
|
£7.36
|
£8.83
|
|
|
20 - RETAINING SNAP RING
BSD-2600501031.A3
2600501031
|
£15.65
|
£18.78
|
|
|
21 - PRESSURE SPINDLE
BSD-2603132002.A28
2603132002
|
-
|
|
|
|
23 - SPRING RETAINING RING
BSD-2604601013.A10
2604601013
|
-
|
|
|
|
24 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A536
1903230003
|
£2.74
|
£3.29
|
|
|
25 - O-RING 21.0x2.0 MM
BSD-2600210028.A78
2600210028
|
£1.38
|
£1.66
|
|
|
26 - COMPRESSION SPRING
BSD-2604611040.A20
2604611040
|
-
|
|
|
|
27 - COMPRESSION SPRING
BSD-2604619009.A1
2604619009
|
£2.80
|
£3.36
|
|
|
28 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A559
1903230006
|
£2.27
|
£2.72
|
|
|
29 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A1
1903230004
|
£2.27
|
£2.72
|
|
|
32 - BALL DIN 5401-5 G28
BSD-1903230009.A99
1903230009
|
£1.84
|
£2.21
|
|
|
33 - LEAF SPRING
BSD-2601250001.A52
2601250001
|
£3.72
|
£4.47
|
|
|
35 - DISC SPRING
BSD-2600550018.A11
2600550018
|
£2.80
|
£3.36
|
|
|
37 - NEEDLE BEARING dia 12 MM
BSD-2600914016.A3
2600914016
|
£3.72
|
£4.47
|
|
|
38 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A399
2600914010
|
£2.94
|
£3.53
|
|
|
39 - SHIM 0.3 MM
BSD-2600100607.A919
2600100607
|
£1.75
|
£2.10
|
|
|
40 - FELT DISC
BSD-2600108000.A265
2600108000
|
-
|
|
|
|
41 - SEAL BUSHING
BSD-2600300049.A1
2600300049
|
-
|
|
|
|
42 - CUPPED WASHER
BSD-2600500030.A6
2600500030
|
-
|
|
|
|
44 - BALL BEARING 8x22x7
BSD-1900905029.A182
1900905029
|
£22.60
|
£27.12
|
|
|
47 - HOUSING COVER
BSD-2605132017.A87
2605132017
|
-
|
|
|
|
48 - CHANGE-OVER SWITCH
BSD-2607200114.A6
2607200114
|
-
|
|
|
|
49 - FIELD 220V
BSD-2604222302.A30
2604222302
|
-
|
|
|
|
50 - ARMATURE 220V
BSD-2604010533.A29
2604010533
|
-
|
|
|
|
51 - SCREW AND WASHER ASSEMBLY DIN 84-BM 4x35-Z4-8.8
BSD-2914501027.A37
2914501027
|
-
|
|
|
|
52 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A397
2916690003
|
£1.75
|
£2.10
|
|
|
53 - SPRING RETAINING RING
BSD-2600119000.A89
2600119000
|
£1.84
|
£2.21
|
|
|
54 - COVER DISC
BSD-2601328041.A45
2601328041
|
-
|
|
|
|
55 - CABLE CLIP
BSD-2601035001.A1078
2601035001
|
£1.75
|
£2.10
|
|
|
56 - ELEC. CABLE W/CONNECTION CH 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460053.A92
2604460053
|
-
|
|
|
|
57 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1632
2600703012
|
£2.94
|
£3.53
|
|
|
58 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2471
2910211019
|
£1.84
|
£2.21
|
|
|
59 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A1073
2910211021
|
£1.75
|
£2.10
|
|
|
60 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A8
2910211020
|
£2.16
|
£2.59
|
|
|
61 - ON-OFF SWITCH
BSD-2607200073.A23
2607200073
|
-
|
|
|
|
62 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A482
2603410023
|
-
|
|
|
|
63 - SUPPRESSION CAPACITOR
BSD-2607329002.A7
2607329002
|
-
|
|
|
|
64 - SHIM
BSD-2600150004.A341
2600150004
|
£2.27
|
£2.72
|
|
|
65 - SHIM 0.3 MM
BSD-2600101023.A276
2600101023
|
£1.84
|
£2.21
|
|
|
65 - SHIM 0.2 MM
BSD-2600101022.A287
2600101022
|
£1.84
|
£2.21
|
|
|
65 - SHIM 0.5 MM
BSD-2600101020.A345
2600101020
|
£1.84
|
£2.21
|
|
|
66 - BALL BEARING 7x22x7
BSD-1900905018.A1274
1900905018
|
£19.91
|
£23.89
|
|
|
70 - TAPPING SCREW 2.2x6.5
BSD-2603435016.A46
2603435016
|
-
|
|
|
|
71 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A109
2914501011
|
£1.75
|
£2.10
|
|
|
72 - SPIRAL SPRING
BSD-2604652003.A49
2604652003
|
-
|
|
|
|
73 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A707
2916011005
|
£1.84
|
£2.21
|
|
|
75 - SUPPRESSOR BOX
BSD-2604465026.A0
2604465026
|
-
|
|
|
|
77 - SUPPRESSOR BOX
BSD-2604465027.A65
2604465027
|
-
|
|
|
|
78 - COMPRESSION SPRING
BSD-2604611026.A180
2604611026
|
-
|
|
|
|
79 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A453
1903201042
|
£2.27
|
£2.72
|
|
|
80 - STICKER
BSD-2601110176.A4
2601110176
|
-
|
|
|
|
81 - MANUFACTURER'S NAMEPLATE
BSD-2601110099.A7
2601110099
|
-
|
|
|
|
82 - CABLE
BSD-2604411524.A60
2604411524
|
-
|
|
|
|
83 - GROOVED NAIL
BSD-3603133000.A218
3603133000
|
£2.61
|
£3.13
|
|
|
85 - STICKER
BSD-2601110230.A18
2601110230
|
-
|
|
|
|
87 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A551
1900452012
|
£1.75
|
£2.10
|
|
|
88 - FAN
BSD-2606610021.A51
2606610021
|
-
|
|
|
|
89 - CENTERING SLEEVE
BSD-2600409013.A69
2600409013
|
-
|
|
|
|
653 - GUIDE SLEEVE
BSD-2600326006.A7
2600326006
|
-
|
|
|
|
654 - GUIDE SLEEVE
BSD-2600326007.A21
2600326007
|
-
|
|
|
|
655 - GUIDE SLEEVE
BSD-2600326008.A7
2600326008
|
-
|
|
|
|
800 - MOTOR HOUSING
BSD-2605104954.A2
2605104954
|
-
|
|
|
|
802 - GEAR HOUSING
BSD-2605806964.A10
2605806964
|
-
|
|
|
|
803 - TOOTHED SHAFT Z=21/41
BSD-2606311904.A1
2606311904
|
-
|
|
|
|
804 - COUPLING HALF
BSD-2606490908.A9
2606490908
|
-
|
|
|
|
805 - COUPLING HALF
BSD-2606455902.A1
2606455902
|
-
|
|
|
|
806 - THREADED SLEEVE
BSD-2600390900.A1
2600390900
|
-
|
|
|
|
807 - ADJUSTING SLEEVE
BSD-2600499900.A1
2600499900
|
-
|
|
|
|
808 - DRIVE SHAFT Z= 29
BSD-2603124901.A1
2603124901
|
-
|
|
|
|
809 - BEARING FLANGE
BSD-2605700925.A40
2605700925
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604320902.A276
2604320902
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1933
160111A3H3
|
£2.74
|
£3.29
|
|
