2 - DRILLING SPINDLE 1/2
BSD-2606135026.A28
2606135026
|
-
|
|
|
|
2 - DRILLING SPINDLE 1/2
BSD-2606135010.A30
2606135010
|
-
|
|
|
|
3 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A316
1900905163
|
£11.30
|
£13.56
|
|
|
5 - SHIM 0.5 MM
BSD-2600101616.A174
2600101616
|
-
|
|
|
|
5 - SHIM 0.3 MM
BSD-2600101617.A156
2600101617
|
£1.84
|
£2.21
|
|
|
6 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A266
2600917003
|
£2.94
|
£3.53
|
|
|
7 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A186
2916660014
|
£1.75
|
£2.10
|
|
|
8 - COMPRESSION SPRING
BSD-2604616002.A126
2604616002
|
£1.84
|
£2.21
|
|
|
9 - SPACER BUSHING
BSD-2600300016.A6
2600300016
|
-
|
|
|
|
10 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A166
2916650008
|
£1.84
|
£2.21
|
|
|
11 - RETAINING WASHER
BSD-2600101671.A169
2600101671
|
£1.84
|
£2.21
|
|
|
12 - FLAT KEY
BSD-2602300027.A14
2602300027
|
-
|
|
|
|
14 - CYLINDRICAL GEAR Z=48
BSD-2606317036.A39
2606317036
|
-
|
|
|
|
15 - CYLINDRICAL GEAR Z=36
BSD-2606317037.A75
2606317037
|
-
|
|
|
|
16 - CATCH DISK
BSD-2600190052.A39
2600190052
|
£8.17
|
£9.80
|
|
|
16 - LOCATING WASHER
BSD-2600190031.A11
2600190031
|
-
|
|
|
|
20 - SHIM WASHER 0.2 MM
BSD-2600000012.A206
2600000012
|
£1.75
|
£2.10
|
|
|
20 - SHIM WASHER 0.5 MM
BSD-2600000014.A206
2600000014
|
£1.84
|
£2.21
|
|
|
21 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A99
1903230010
|
£1.84
|
£2.21
|
|
|
22 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A57
2600914010
|
£2.94
|
£3.53
|
|
|
24 - SHIM 0.3 MM
BSD-2600100607.A246
2600100607
|
£1.75
|
£2.10
|
|
|
27 - SHIM 0.5 MM
BSD-2600100682.A52
2600100682
|
-
|
|
|
|
27 - SHIM 0.3 MM
BSD-2600100683.A12
2600100683
|
-
|
|
|
|
27 - SHIM 0.2 MM
BSD-2600100684.A49
2600100684
|
-
|
|
|
|
28 - DISC SPRING
BSD-2600550008.A110
2600550008
|
£1.84
|
£2.21
|
|
|
29 - COVER DISC
BSD-2600114001.A43
2600114001
|
-
|
|
|
|
30 - LOCKING WASHER
BSD-2600116001.A48
2600116001
|
-
|
|
|
|
31 - TOOTHED RACK
BSD-2603070012.A7
2603070012
|
-
|
|
|
|
32 - FORK LEVER
BSD-2602033003.A47
2602033003
|
-
|
|
|
|
33 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A11
2914501011
|
£1.75
|
£2.10
|
|
|
35 - ROTARY KNOB
BSD-2602026034.A29
2602026034
|
-
|
|
|
|
36 - LOCKING WASHER DIN 6799-7-FSt
BSD-2916080910.A258
2916080910
|
£2.16
|
£2.59
|
|
|
37 - SHIM 0.5 MM
BSD-2600101612.A261
2600101612
|
£1.84
|
£2.21
|
|
|
38 - HEADLESS SCREW 74 MM
BSD-2603435019.A35
2603435019
|
-
|
|
|
|
39 - TAPPING SCREW 79 MM
BSD-2603435012.A14
2603435012
|
-
|
|
|
|
43 - LOCATING WASHER
BSD-2600190029.A26
2600190029
|
-
|
|
|
|
44 - ROTARY KNOB
BSD-2602026017.A111
2602026017
|
£7.72
|
£9.27
|
|
|
45 - RATCHET CAP
BSD-2600590006.A6
2600590006
|
£1.84
|
£2.21
|
|
|
47 - SLOTTED SPRING PIN 4x30 MM DIN 7346
BSD-2917780105.A51
2917780105
|
£1.75
|
£2.10
|
|
|
48 - FELT WASHER
BSD-2600108077.A423
2600108077
|
£1.84
|
£2.21
|
|
|
49 - CUPPED WASHER
BSD-2600500002.A621
2600500002
|
£1.75
|
£2.10
|
|
|
50 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A322
2600905021
|
£8.67
|
£10.41
|
|
|
51 - ARMATURE 220-240V
BSD-2604010524.A32
2604010524
|
-
|
|
|
|
52 - FAN
BSD-2606610049.A46
2606610049
|
£2.27
|
£2.72
|
|
|
53 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A368
2916660008
|
£2.16
|
£2.59
|
|
|
54 - RECEPTACLE
BSD-2600400008.A569
2600400008
|
£1.75
|
£2.10
|
|
|
55 - MOTOR HOUSING
BSD-2605108014.A20
2605108014
|
-
|
|
|
|
56 - COVER DISC
BSD-2601328033.A254
2601328033
|
-
|
|
|
|
57 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A752
2603490017
|
£2.27
|
£2.72
|
|
|
58 - FIELD 220-230V
BSD-2604220491.A52
2604220491
|
£22.76
|
£27.31
|
|
|
59 - CONNECTING CABLE
BSD-2604448036.A15
2604448036
|
-
|
|
|
|
60 - SUPPRESSOR BOX
BSD-2604465062.A4
2604465062
|
-
|
|
|
|
61 - CONNECTING CABLE L=193 MM
BSD-2604448043.A15
2604448043
|
£1.75
|
£2.10
|
|
|
62 - BALL BEARING 7x22x7
BSD-1900905018.A334
1900905018
|
£19.91
|
£23.89
|
|
|
65 - BRUSH PLATE
BSD-2601015047.A4
2601015047
|
-
|
|
|
|
66 - ON-OFF SWITCH
BSD-2607200137.A24
2607200137
|
-
|
|
|
|
67 - CABLE CLIP
BSD-2601035001.A1594
2601035001
|
£1.84
|
£2.21
|
|
|
68 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A723
2910211019
|
£1.84
|
£2.21
|
|
|
69 - SUPPRESSION CAPACITOR
BSD-2607329103.A18
2607329103
|
-
|
|
|
|
70 - HANDLE
BSD-2605133000.A8
2605133000
|
-
|
|
|
|
72 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A845
2600703011
|
£2.94
|
£3.53
|
|
|
72 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A278
2600703012
|
£2.94
|
£3.53
|
|
|
72 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A813
2600703013
|
£2.74
|
£3.29
|
|
|
74 - CABLE
BSD-2604448003.A30
2604448003
|
-
|
|
|
|
78 - STICKER
BSD-2601110093.A14
2601110093
|
-
|
|
|
|
79 - STICKER
BSD-2601110250.A4
2601110250
|
-
|
|
|
|
80 - STICKER
BSD-2601110076.A141
2601110076
|
-
|
|
|
|
81 - STICKER
BSD-2601110041.A97
2601110041
|
-
|
|
|
|
82 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1891
2603410001
|
£1.84
|
£2.21
|
|
|
83 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A673
2603435015
|
£2.27
|
£2.72
|
|
|
85 - SHIM 0.3 MM
BSD-2600101023.A394
2600101023
|
£1.84
|
£2.21
|
|
|
85 - SHIM 0.2 MM
BSD-2600101022.A153
2600101022
|
£1.84
|
£2.21
|
|
|
85 - SHIM 0.5 MM
BSD-2600101020.A479
2600101020
|
£1.84
|
£2.21
|
|
|
87 - SHIM
BSD-2600150004.A623
2600150004
|
£2.27
|
£2.72
|
|
|
90 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A476
2912401020
|
£2.16
|
£2.59
|
|
|
94 - O-RING 12.0x1.0 MM
BSD-1600210024.A60
1600210024
|
-
|
|
|
|
97 - DAMPING PLATE
BSD-2601022000.A207
2601022000
|
£1.75
|
£2.10
|
|
|
98 - SOCKET HEAD CAP SCREW DIN 84-AM4x25-8.8
BSD-2910021132.A40
2910021132
|
£1.84
|
£2.21
|
|
|
99 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A1078
2916690003
|
£1.75
|
£2.10
|
|
|
651 - AUXILIARY HANDLE
BSD-2602025031.A41
2602025031
|
-
|
|
|
|
652 - WING NUT M6 DIN 315-G-GTW-40
BSD-2915191006.A32
2915191006
|
-
|
|
|
|
653 - HEX SCREW DIN 931-M6x75-8.8
BSD-2911011220.A59
2911011220
|
-
|
|
|
|
654 - CONICAL SPRING WASHER
BSD-2601098001.A19
2601098001
|
-
|
|
|
|
655 - DEPTH-GAUGE
BSD-2607010026.A47
2607010026
|
-
|
|
|
|
656 - CHUCK dia1.5-13 MM. 1/2
BSD-1608571069.A335
1608571069
|
£25.05
|
£30.06
|
|
|
656 - CHUCK WRENCH SG2
BSD-2607950007.A68
2607950007
|
£6.85
|
£8.22
|
|
|
800 - GEAR HOUSING
BSD-2605806973.A10
2605806973
|
-
|
|
|
|
810/04 - CARBON-BRUSH SET
BSD-2604321905.A51
2604321905
|
£11.87
|
£14.24
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A5011
160111A3H3
|
£2.74
|
£3.29
|
|
