1 - HOUSING SECTION
BSD-1615104050.A0
1615104050
|
-
|
|
|
|
2 - POLE HOUSING 14;4-24V
BSD-2610942109.A18
2610942109
|
£22.76
|
£27.31
|
|
|
4 - ON-OFF SWITCH
BSD-2607200488.A0
2607200488
|
£57.02
|
£68.42
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110D37.A0
1611110D37
|
-
|
|
|
|
11 - REFERENCE PLATE
BSD-1611110D38.A0
1611110D38
|
-
|
|
|
|
13 - GROOVE BALL BEARING 8x22x7
BSD-1600905033.A36
1600905033
|
£7.72
|
£9.27
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A331
2600905052
|
£7.72
|
£9.27
|
|
|
15 - FAN
BSD-1616610092.A18
1616610092
|
£6.94
|
£8.33
|
|
|
17 - SPIRAL SPRING
BSD-1614652008.A27
1614652008
|
£2.27
|
£2.72
|
|
|
18 - DAMPING RUBBER
BSD-2603100056.A129
2603100056
|
£1.84
|
£2.21
|
|
|
20 - CATCH DISK
BSD-1616409012.A20
1616409012
|
£5.87
|
£7.04
|
|
|
22 - CYLINDRICAL GEAR Z=53
BSD-1616317613.A39
1616317613
|
-
|
|
|
|
27 - STRIKER
BSD-1618710068.A37
1618710068
|
£7.78
|
£9.33
|
|
|
30 - DRIVE LEVER
BSD-1611911000.A31
1611911000
|
-
|
|
|
|
33 - COMPRESSION SPRING
BSD-1614634008.A47
1614634008
|
£2.05
|
£2.46
|
|
|
34 - BEARING PIN
BSD-1613100021.A34
1613100021
|
£2.45
|
£2.94
|
|
|
36 - SUPPORTING DISC
BSD-1610190021.A86
1610190021
|
£2.27
|
£2.72
|
|
|
39 - PROTECTIVE CAP
BSD-1610508021.A22
1610508021
|
£2.05
|
£2.46
|
|
|
43 - SUPPORTING DISC
BSD-1610190020.A0
1610190020
|
£2.05
|
£2.46
|
|
|
44 - CLAMP HANDLE
BSD-1617000590.A0
1617000590
|
£3.51
|
£4.21
|
|
|
45 - DRIVE PINION Z=9
BSD-1616316602.A35
1616316602
|
£14.75
|
£17.70
|
|
|
46 - STRAIGHT PIN
BSD-1613160022.A66
1613160022
|
£1.84
|
£2.21
|
|
|
47 - INSULATING PLATE
BSD-1601010010.A2
1601010010
|
£5.01
|
£6.01
|
|
|
53 - NEEDLE BEARING
BSD-1610910077.A64
1610910077
|
£4.48
|
£5.37
|
|
|
55 - ROLLER THRUST BEARING
BSD-1610920012.A57
1610920012
|
£3.34
|
£4.01
|
|
|
56 - SUPPORT DISC 1.0 MM
BSD-1610102030.A3
1610102030
|
£2.61
|
£3.13
|
|
|
57 - ROLLER THRUST BEARING
BSD-1610920009.A36
1610920009
|
£3.51
|
£4.21
|
|
|
60 - SEAL RING
BSD-1610280006.A26
1610280006
|
£3.51
|
£4.21
|
|
|
62 - O-RING 18.0x2.5 MM
BSD-1610210125.A29
1610210125
|
£2.05
|
£2.46
|
|
|
63 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A779
1903230013
|
£2.27
|
£2.72
|
|
|
64 - STRAIGHT PIN DIN6325-2.5x12-RIKO
BSD-1613100019.A61
1613100019
|
£1.84
|
£2.21
|
|
|
65 - RETAINING RING
BSD-1614601018.A39
1614601018
|
£1.66
|
£1.99
|
|
|
67 - SPRING RETAINING RING
BSD-3600224038.A28
3600224038
|
£1.38
|
£1.66
|
|
|
72 - SHIM WASHER 1.0 MM
BSD-1610100007.A85
1610100007
|
£1.84
|
£2.21
|
|
|
74 - SEALING FRAME
BSD-1611015045.A51
1611015045
|
£5.57
|
£6.68
|
|
|
75 - SEALING FRAME
BSD-1611015041.A83
1611015041
|
£1.95
|
£2.34
|
|
|
76 - SEAL RING
BSD-1610210138.A19
1610210138
|
£1.84
|
£2.21
|
|
|
80 - SEALING DISK
BSD-1610100008.A0
1610100008
|
£1.75
|
£2.10
|
|
|
81 - LOCATING RING
BSD-1610290043.A37
1610290043
|
£2.27
|
£2.72
|
|
|
83 - LOCATING RING
BSD-1610290078.A16
1610290078
|
£2.33
|
£2.80
|
|
|
84 - INSERTED PART
BSD-1601016013.A1
1601016013
|
£1.95
|
£2.34
|
|
|
85 - SWITCH SLIDE
BSD-1613231006.A37
1613231006
|
£1.95
|
£2.34
|
|
|
86 - CONTACT RETAINER
BSD-1609280157.A0
1609280157
|
-
|
|
|
|
92 - TAPPING SCREW DIN7981-ST3.9x22-C-Z
BSD-2912401021.A226
2912401021
|
£1.84
|
£2.21
|
|
|
93 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A248
2912401019
|
£1.84
|
£2.21
|
|
|
94 - TAPPING SCREW DIN 7981-ST2.9x16.0-C-Z
BSD-2912401007.A2
2912401007
|
£1.84
|
£2.21
|
|
|
98 - CONNECTING CABLE L=260 MM
BSD-1614416012.A51
1614416012
|
£1.84
|
£2.21
|
|
|
99 - CONNECTING CABLE L=270 MM
BSD-1614416011.A2
1614416011
|
£1.84
|
£2.21
|
|
|
120 - AUXILIARY HANDLE
BSD-2602025131.A10
2602025131
|
£14.72
|
£17.67
|
|
|
120/120 - AUXILIARY HANDLE M8
BSD-1612025019.A154
1612025019
|
£6.85
|
£8.22
|
|
|
120/124 - CLAMPING BAND dia43 MM
BSD-1611316006.A2
1611316006
|
£2.61
|
£3.13
|
|
|
120/125 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A609
1613490002
|
£4.48
|
£5.37
|
|
|
120/802 - SUPPORT CLAMP
BSD-2608040207.A1
2608040207
|
£6.61
|
£7.93
|
|
|
652 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A362
1613001009
|
£3.91
|
£4.69
|
|
|
653 - ACCUMULATOR BATTERY 24V. 1.7Ah. NiCd
BSD-2607335163.A16
2607335163
|
£243.45
|
£292.14
|
|
|
653 - ACCUMULATOR BATTERY 24V. 3.0Ah. NiCd
BSD-2607335223.A3
2607335223
|
£352.76
|
£423.31
|
|
|
655 - PROTECTIVE CAP
BSD-1610508032.A52
1610508032
|
£2.27
|
£2.72
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A187
1615430010
|
£6.85
|
£8.22
|
|
|
803 - ARMATURE WITH FAN 24V
BSD-1617000511.A0
1617000511
|
£93.88
|
£112.65
|
|
|
808 - NAMEPLATE
BSD-160111A3HD.A26
160111A3HD
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-1617014131.A35
1617014131
|
-
|
|
|
|
816 - BRUSH HOLDER L=145 MM
BSD-1617000379.A0
1617000379
|
-
|
|
|
|
817 - BRUSH HOLDER L=45 MM
BSD-1617000380.A53
1617000380
|
-
|
|
|
|
821 - HAMMER PIPE
BSD-1617000320.A26
1617000320
|
-
|
|
|
|
821/01 - HAMMER PIPE
BSD-1617000375.A40
1617000375
|
-
|
|
|
|
824 - JACK SHAFT Z=31/12
BSD-1617000314.A52
1617000314
|
£49.16
|
£58.99
|
|
|
841 - PROTECTION SLEEVE
BSD-1617000303.A38
1617000303
|
£15.65
|
£18.78
|
|
|
850 - BUSHING
BSD-1617000975.A5
1617000975
|
£6.61
|
£7.93
|
|
|
854 - FAST CHARGER EU 230/7.2-24V.1h
BSD-2607225021.A6
2607225021
|
£126.12
|
£151.34
|
|
