1 - HOUSING SECTION
BSD-3609202A34.A4
3609202A34
|
£66.68
|
£80.01
|
|
|
4 - ELECTRONIC ASSEMBLY
BSD-3607200114.A4
3607200114
|
£525.48
|
£630.58
|
|
|
8 - RETAINING RING dia36.6xdia1.5
BSD-1614601016.A26
1614601016
|
£2.80
|
£3.36
|
|
|
10 - SWITCH SLIDE
BSD-3601099003.A47
3601099003
|
£2.80
|
£3.36
|
|
|
11/1 - ANGLE FLANGE
BSD-3609202A33.A6
3609202A33
|
£102.57
|
£123.08
|
|
|
11/2 - BALL BEARING 8x22x7
BSD-1900905029.A199
1900905029
|
£22.60
|
£27.12
|
|
|
11/3 - SPRING RETAINING RING
BSD-2600119000.A82
2600119000
|
£1.84
|
£2.21
|
|
|
11/4 - O-RING 20.0x1.0 MM
BSD-3600210012.A56
3600210012
|
£2.94
|
£3.53
|
|
|
14 - SLEEVE
BSD-3600423004.A34
3600423004
|
£5.58
|
£6.70
|
|
|
15 - COMPRESSION SPRING
BSD-3604611037.A44
3604611037
|
£5.57
|
£6.68
|
|
|
16 - LED-HOLDER
BSD-3605105019.A28
3605105019
|
£11.30
|
£13.56
|
|
|
17 - LED-HOLDER
BSD-3605105020.A15
3605105020
|
£11.30
|
£13.56
|
|
|
19 - O-RING 25x2.5 MM
BSD-1900210125.A27
1900210125
|
£7.36
|
£8.83
|
|
|
20 - PINION
BSD-3606309061.A7
3606309061
|
£50.80
|
£60.96
|
|
|
29 - INTERMEDIATE FLANGE
BSD-2605719011.A68
2605719011
|
£3.72
|
£4.47
|
|
|
30 - PLANETARY GEAR TRAIN
BSD-3607030472.A15
3607030472
|
£66.68
|
£80.01
|
|
|
31 - PLANETARY GEAR TRAIN
BSD-3607030483.A2
3607030483
|
£229.32
|
£275.19
|
|
|
40 - ASSEMBLY KIT
BSD-3607031567.A18
3607031567
|
£218.41
|
£262.09
|
|
|
40/101 - CLUTCH ELEMENT
BSD-3606445043.A80
3606445043
|
£102.57
|
£123.08
|
|
|
40/102 - OUTPUT SHAFT
BSD-3603124034.A0
3603124034
|
£53.78
|
£64.54
|
|
|
40/109 - COMPRESSION SPRING
BSD-3604619020.A81
3604619020
|
£5.58
|
£6.70
|
|
|
40/110 - RETAINING RING
BSD-3600224053.A164
3600224053
|
£1.84
|
£2.21
|
|
|
40/115 - SEALING PLATE
BSD-3601023011.A56
3601023011
|
£2.61
|
£3.13
|
|
|
40/116 - SETTING RING
BSD-3600134016.A7
3600134016
|
£59.53
|
£71.44
|
|
|
40/117 - PLAIN WASHER 0.5 MM
BSD-1600101023.A113
1600101023
|
£1.75
|
£2.10
|
|
|
40/119 - SUPPORT DISC
BSD-3600190036.A117
3600190036
|
£9.11
|
£10.93
|
|
|
40/120 - CATCH DISK
BSD-3603344046.A7
3603344046
|
£33.74
|
£40.49
|
|
|
40/122 - SHIM WASHER
BSD-3600101052.A30
3600101052
|
£8.67
|
£10.41
|
|
|
40/127 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A469
1903230006
|
£2.27
|
£2.72
|
|
|
40/128 - BALL 4.5 MM III DIN 5401-ST
BSD-1903230008.A198
1903230008
|
£1.75
|
£2.10
|
|
|
40/140 - LOCKING WASHER DIN 6799-9-FSt
BSD-2916080012.A217
2916080012
|
£1.84
|
£2.21
|
|
|
60 - SWITCHING ELEMENT
BSD-3601923022.A118
3601923022
|
£5.30
|
£6.36
|
|
|
61 - COMPRESSION SPRING
BSD-3604611022.A141
3604611022
|
£3.72
|
£4.47
|
|
|
62 - PUSHER
BSD-3601923029.A120
3601923029
|
£5.30
|
£6.36
|
|
|
71 - LIGHT CONDUCTOR
BSD-3604460132.A10
3604460132
|
£2.80
|
£3.36
|
|
|
80 - TORX OVAL-HEAD SCREW 3x18
BSD-2603490018.A158
2603490018
|
£1.75
|
£2.10
|
|
|
82 - LENS HEAD SCREW
BSD-3603386064.A0
3603386064
|
£1.75
|
£2.10
|
|
|
90 - RING
BSD-3600106025.A2
3600106025
|
£3.72
|
£4.47
|
|
|
138 - THREADED RING
BSD-3603344057.A4
3603344057
|
£37.27
|
£44.72
|
|
|
657 - SCREWDRIVER
BSD-3607950027.A93
3607950027
|
£14.91
|
£17.89
|
|
|
658 - SINGLE-HEAD ENG. WRENCH
BSD-3601376007.A0
3601376007
|
£10.61
|
£12.73
|
|
|
659 - SUSPENSION LOOP
BSD-3601923024.A11
3601923024
|
£11.30
|
£13.56
|
|
|
702 - SLIDE-IN ACCU PACKAGE
BSD-2607335881.A20
2607335881
|
£161.73
|
£194.08
|
|
|
703 - SLIDE-IN ACCU PACKAGE 14.4V.2.4Ah
BSD-2607335655.A12
2607335655
|
£167.68
|
£201.22
|
|
|
751 - PROTECTIVE CAP
BSD-3609202A29.A5
3609202A29
|
£13.78
|
£16.54
|
|
|
802 - DC MOTOR 14.4V
BSD-3607031632.A2
3607031632
|
£251.67
|
£302.00
|
|
|
803 - WIRING HARNESS
BSD-3609202B02.A18
3609202B02
|
£72.18
|
£86.62
|
|
|
804 - WIRING HARNESS
BSD-3609202B03.A0
3609202B03
|
£19.91
|
£23.89
|
|
|
806 - CONTACT RETAINER
BSD-1609280416.A31
1609280416
|
£10.10
|
£12.12
|
|
|
820 - CATCH DISK
BSD-3603344047.A163
3603344047
|
£23.86
|
£28.63
|
|
|
854 - FAST CHARGER EU 230/7.2-24V. 30 MIN.
BSD-2607225027.A65
2607225027
|
£126.12
|
£151.34
|
|
|
854 - FAST CHARGER GB 230/7.2-24V. 30 MIN.
BSD-2607225029.A98
2607225029
|
£92.47
|
£110.96
|
|
|
854 - FAST CHARGER AUS 240/7.2-24V. 30 MIN.
BSD-2607225031.A55
2607225031
|
£98.11
|
£117.73
|
|
|
854 - FAST CHARGER USA 120/7.2-24V. 30 MIN.
BSD-2607225033.A83
2607225033
|
-
|
|
|
|
854 - FAST CHARGER ROK 220/7.2-24V. 30 MIN.
BSD-2607225039.A83
2607225039
|
£84.64
|
£101.57
|
|
|
854 - FAST CHARGER SAM 115/7.2-24V. 15 MIN.
BSD-2607225035.A45
2607225035
|
-
|
|
|
|
854 - FAST CHARGER J 100/7.2-24V. 1h
BSD-2607224435.A16
2607224435
|
£120.11
|
£144.13
|
|
|
855 - MANUFACTURER'S NAMEPLATE
BSD-3601110540.A0
3601110540
|
£3.72
|
£4.47
|
|
|
866 - NAMEPLATE
BSD-3601119497.A0
3601119497
|
£3.91
|
£4.69
|
|
|
890 - PARTS SET
BSD-3600106027.A12
3600106027
|
£21.68
|
£26.01
|
|
|
890 - PARTS SET
BSD-3600106028.A56
3600106028
|
£21.52
|
£25.83
|
|
|
890 - PARTS SET
BSD-3600106029.A12
3600106029
|
£21.68
|
£26.01
|
|
|
890 - PARTS SET
BSD-3600106030.A56
3600106030
|
£21.68
|
£26.01
|
|
|
890 - PARTS SET
BSD-3600106031.A12
3600106031
|
£23.86
|
£28.63
|
|
|
890 - PARTS SET
BSD-3600106032.A56
3600106032
|
£21.68
|
£26.01
|
|
|
890 - PARTS SET
BSD-3600106033.A12
3600106033
|
£21.52
|
£25.83
|
|
