1 - MOTOR HOUSING
BSD-3605108026.A11
3605108026
|
£218.41
|
£262.09
|
|
|
2 - STATOR 740W
BSD-3604090023.A3
3604090023
|
£156.22
|
£187.46
|
|
|
3 - ROTOR
BSD-3604220021.A1
3604220021
|
£102.57
|
£123.08
|
|
|
5 - BEARING FLANGE
BSD-3605700014.A1
3605700014
|
£62.51
|
£75.01
|
|
|
6 - GROOVE BALL BEARING 10x26x8
BSD-1900905127.A91
1900905127
|
£27.23
|
£32.68
|
|
|
7 - BEARING FLANGE
BSD-3605700013.A11
3605700013
|
£48.38
|
£58.06
|
|
|
8 - BALL BEARING 8x22x7
BSD-1900905029.A44
1900905029
|
£22.60
|
£27.12
|
|
|
9 - SPACER RING
BSD-2600200007.A10
2600200007
|
£10.61
|
£12.73
|
|
|
10 - SPACER RING
BSD-3600202004.A14
3600202004
|
£11.30
|
£13.56
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A184
2916011012
|
£1.84
|
£2.21
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A6
2911061150
|
£2.61
|
£3.13
|
|
|
13 - ADJUSTING DISC
BSD-3600136000.A1
3600136000
|
£21.68
|
£26.01
|
|
|
14 - SEALING PLATE
BSD-3600031000.A18
3600031000
|
£2.16
|
£2.59
|
|
|
26 - PINION Z=14
BSD-3606300048.A6
3606300048
|
£50.80
|
£60.96
|
|
|
27 - STOP DISC
BSD-3600101004.A14
3600101004
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=46/35
BSD-3606334013.A9
3606334013
|
£431.32
|
£517.59
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337048.A8
3606337048
|
£126.12
|
£151.34
|
|
|
30 - CYLINDRICAL GEAR Z=16
BSD-3606316091.A4
3606316091
|
£2.94
|
£3.53
|
|
|
31 - NEEDLE-ROLLER ASSEMBLY
BSD-3600910000.A94
3600910000
|
£4.48
|
£5.37
|
|
|
32 - NEEDLE ROLLER
BSD-3603201005.A68
3603201005
|
£2.94
|
£3.53
|
|
|
34 - NEEDLE ROLLER
BSD-3603201031.A47
3603201031
|
£2.61
|
£3.13
|
|
|
35 - GROOVE BALL BEARING 25x37x7
BSD-3600905001.A78
3600905001
|
£31.64
|
£37.97
|
|
|
36 - PLANETARY-GEAR CARRIER
BSD-3606337044.A2
3606337044
|
£306.65
|
£367.98
|
|
|
37 - CYLINDRICAL GEAR
BSD-3606316105.A0
3606316105
|
£39.13
|
£46.96
|
|
|
38 - SPACER RING
BSD-3600101012.A8
3600101012
|
£18.96
|
£22.75
|
|
|
39 - GROOVE BALL BEARING 17x47x14
BSD-1900900382.A13
1900900382
|
£33.74
|
£40.49
|
|
|
40 - THREADED RING
BSD-3603344060.A10
3603344060
|
£23.86
|
£28.63
|
|
|
41 - RADIAL SEAL
BSD-3600283010.A10
3600283010
|
£19.91
|
£23.89
|
|
|
42 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A74
2916650008
|
£1.84
|
£2.21
|
|
|
43 - O-RING 45x2.5 MM
BSD-1900210345.A7
1900210345
|
-
|
|
|
|
44 - CYLINDRICAL GEAR Z=16
BSD-3606316091.A5
3606316091
|
£2.94
|
£3.53
|
|
|
45 - PLANETARY-GEAR CARRIER
BSD-3606337043.A7
3606337043
|
£156.22
|
£187.46
|
|
|
47 - THRUST BEARING DISC
BSD-1610101608.A15
1610101608
|
£2.27
|
£2.72
|
|
|
48 - STOP DISC
BSD-3600100006.A9
3600100006
|
£5.58
|
£6.70
|
|
|
49 - NEEDLE ROLLER
BSD-3603201030.A1
3603201030
|
£2.94
|
£3.53
|
|
|
50 - GROOVE BALL BEARING
BSD-3600905103.A9
3600905103
|
£25.05
|
£30.06
|
|
|
54 - FITTING
BSD-3603458008.A93
3603458008
|
£9.11
|
£10.93
|
|
|
55 - O-RING 10x2 MM
BSD-1900210306.A57
1900210306
|
£1.84
|
£2.21
|
|
|
56 - VALVE INSERT
BSD-3605190015.A6
3605190015
|
£179.37
|
£215.24
|
|
|
60 - STRAINER
BSD-3600002000.A77
3600002000
|
£3.72
|
£4.47
|
|
|
65 - O-RING 15.6x1.8 MM
BSD-3600210003.A41
3600210003
|
£1.84
|
£2.21
|
|
|
66 - STRAIGHT PIN
BSD-3604710007.A17
3604710007
|
£10.10
|
£12.12
|
|
|
67 - CONTROL LEVER
BSD-3602053005.A1
3602053005
|
£15.65
|
£18.78
|
|
|
68 - BALL dia9 MM
BSD-3603230004.A35
3603230004
|
£3.91
|
£4.69
|
|
|
69 - COMPRESSION SPRING
BSD-3604616002.A76
3604616002
|
£2.27
|
£2.72
|
|
|
72 - STRAIGHT PIN 3M6x24 DIN 7-C35K
BSD-2917610083.A57
2917610083
|
£1.75
|
£2.10
|
|
|
73 - STRAIGHT PIN
BSD-3604710003.A51
3604710003
|
£6.85
|
£8.22
|
|
|
77 - HOLDING PIN
BSD-3603203006.A1
3603203006
|
£5.58
|
£6.70
|
|
|
78 - VALVE CONE
BSD-3603231000.A22
3603231000
|
£2.80
|
£3.36
|
|
|
79 - O-RING 1.8x1.0 MM
BSD-3600210002.A51
3600210002
|
£2.74
|
£3.29
|
|
|
91 - SILENCER
BSD-3601010001.A75
3601010001
|
£2.16
|
£2.59
|
|
|
92 - SILENCER
BSD-3603462000.A167
3603462000
|
£17.22
|
£20.67
|
|
|
93 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x30-8.8
BSD-2910141246.A3
2910141246
|
-
|
|
|
|
94 - HOLDING SPRING
BSD-3601250003.A13
3601250003
|
£2.94
|
£3.53
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A413
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119055.A103
3601119055
|
£3.72
|
£4.47
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A615
3603133000
|
£2.61
|
£3.13
|
|
|
98 - O-RING 54.0x3.0 MM
BSD-1600210004.A248
1600210004
|
£2.80
|
£3.36
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A824
3601119236
|
£3.91
|
£4.69
|
|
|
100 - HOUSING
BSD-3605109001.A0
3605109001
|
-
|
|
|
|
652 - HOSE FITTING
BSD-2603386002.A77
2603386002
|
£5.30
|
£6.36
|
|
|
804 - PARTS SET
BSD-3607030254.A15
3607030254
|
£27.23
|
£32.68
|
|
