1 - MOTOR HOUSING
BSD-3605125003.A2
3605125003
|
£229.32
|
£275.19
|
|
|
2 - STATOR 550W
BSD-3604090008.A8
3604090008
|
£102.57
|
£123.08
|
|
|
3 - ROTOR
BSD-3604220005.A15
3604220005
|
£75.79
|
£90.95
|
|
|
5 - BEARING FLANGE
BSD-3605700014.A47
3605700014
|
£62.51
|
£75.01
|
|
|
6 - GROOVE BALL BEARING 10x26x8
BSD-1900905127.A17
1900905127
|
£27.23
|
£32.68
|
|
|
7 - BEARING FLANGE
BSD-3605700011.A5
3605700011
|
£71.84
|
£86.21
|
|
|
8 - BALL BEARING 8x22x7
BSD-1900905029.A158
1900905029
|
£22.60
|
£27.12
|
|
|
9 - SPACER RING
BSD-2600200007.A66
2600200007
|
£10.61
|
£12.73
|
|
|
10 - SPACER RING
BSD-3600202004.A30
3600202004
|
£11.30
|
£13.56
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A39
2916011012
|
£1.84
|
£2.21
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A147
2911061150
|
£2.74
|
£3.29
|
|
|
26 - PINION
BSD-3606300155.A3
3606300155
|
£31.64
|
£37.97
|
|
|
27 - STOP DISC
BSD-3600101004.A71
3600101004
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=46
BSD-3606334002.A28
3606334002
|
£142.02
|
£170.42
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337011.A7
3606337011
|
£81.81
|
£98.17
|
|
|
30 - CYLINDRICAL GEAR
BSD-3606316109.A17
3606316109
|
£21.68
|
£26.01
|
|
|
31 - NEEDLE-ROLLER ASSEMBLY
BSD-3600910000.A58
3600910000
|
£4.48
|
£5.37
|
|
|
32 - NEEDLE ROLLER
BSD-3603201005.A56
3603201005
|
£2.94
|
£3.53
|
|
|
35 - GROOVE BALL BEARING 25x37x7
BSD-3600905001.A43
3600905001
|
£31.64
|
£37.97
|
|
|
36 - PLANETARY-GEAR CARRIER
BSD-3606337012.A2
3606337012
|
£107.69
|
£129.23
|
|
|
37 - CYLINDRICAL GEAR Z=16
BSD-3606316091.A8
3606316091
|
£2.94
|
£3.53
|
|
|
38 - STOP DISC
BSD-3600101005.A3
3600101005
|
£6.52
|
£7.83
|
|
|
39 - GROOVE BALL BEARING
BSD-3600905025.A39
3600905025
|
£16.41
|
£19.69
|
|
|
40 - THREADED RING
BSD-3603344001.A14
3603344001
|
£17.22
|
£20.67
|
|
|
42 - THREADED SLEEVE
BSD-3600390004.A12
3600390004
|
£31.64
|
£37.97
|
|
|
43 - O-RING 41.0x1.78 MM
BSD-3600210006.A1
3600210006
|
£2.27
|
£2.72
|
|
|
55 - O-RING 8x2.5 MM
BSD-1900210105.A2
1900210105
|
£1.75
|
£2.10
|
|
|
60 - STRAINER
BSD-3600002000.A280
3600002000
|
£3.72
|
£4.47
|
|
|
66 - STRAIGHT PIN
BSD-3604710000.A46
3604710000
|
£5.87
|
£7.04
|
|
|
95 - NAMEPLATE
BSD-3601100430.A8
3601100430
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110331.A59
3601110331
|
£3.72
|
£4.47
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A23
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1904
3601119236
|
£3.91
|
£4.69
|
|
|
651 - HOSE FITTING
BSD-2603386002.A142
2603386002
|
£5.30
|
£6.36
|
|
|
652 - SILENCER
BSD-3607000073.A244
3607000073
|
£19.91
|
£23.89
|
|
|
701 - FASTENING FLANGE
BSD-3605700046.A4
3605700046
|
£120.11
|
£144.13
|
|
|
801 - MOTOR
BSD-3607031034.A0
3607031034
|
£375.13
|
£450.16
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030260.A45
3607030260
|
£21.68
|
£26.01
|
|
