1 - MOTOR HOUSING
BSD-3600760001.A24
3600760001
|
£54.42
|
£65.30
|
|
|
2 - STATOR 370W
BSD-3604090002.A44
3604090002
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220025.A41
3604220025
|
£102.57
|
£123.08
|
|
|
5 - BEARING FLANGE
BSD-3605700005.A144
3605700005
|
£54.42
|
£65.30
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A159
3600905039
|
£12.04
|
£14.45
|
|
|
7 - BEARING FLANGE
BSD-3605700006.A2
3605700006
|
£72.18
|
£86.62
|
|
|
8 - GROOVE BALL BEARING DIN 625-7x19x6
BSD-3600905148.A83
3600905148
|
£8.49
|
£10.19
|
|
|
9 - SPACER RING
BSD-2600202013.A112
2600202013
|
£8.67
|
£10.41
|
|
|
10 - SPACER RING
BSD-2600202014.A79
2600202014
|
£11.30
|
£13.56
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A284
2916011012
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A112
2911061150
|
£2.61
|
£3.13
|
|
|
13 - INTERMEDIATE PIECE
BSD-3602305000.A49
3602305000
|
£37.27
|
£44.72
|
|
|
14 - CYLINDRICAL GEAR Z=12
BSD-3606316098.A36
3606316098
|
£27.23
|
£32.68
|
|
|
15 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A28
3600913000
|
£4.26
|
£5.11
|
|
|
16 - CYLINDRICAL GEAR Z=16
BSD-3606316099.A64
3606316099
|
£21.68
|
£26.01
|
|
|
26 - PINION Z=23
BSD-3606300002.A37
3606300002
|
£23.86
|
£28.63
|
|
|
27 - STOP DISC
BSD-3600101001.A146
3600101001
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=49
BSD-3606334000.A66
3606334000
|
£102.57
|
£123.08
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337002.A9
3606337002
|
£93.88
|
£112.65
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A366
3603201000
|
£1.75
|
£2.10
|
|
|
34 - SHIM WASHER
BSD-3600103002.A47
3600103002
|
£3.72
|
£4.47
|
|
|
35 - RETAINING RING
BSD-3600224000.A34
3600224000
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A134
1900900287
|
£21.68
|
£26.01
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337140.A2
3606337140
|
£195.26
|
£234.31
|
|
|
39 - PARALLEL KEY DIN 6885 A4x4x25-ST50K
BSD-1902300048.A1
1902300048
|
£2.61
|
£3.13
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905027.A21
3600905027
|
£16.41
|
£19.69
|
|
|
46 - THREADED RING
BSD-3603344000.A43
3603344000
|
£16.41
|
£19.69
|
|
|
47 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A246
2916650006
|
£1.75
|
£2.10
|
|
|
56 - CONNECTION HOUSING
BSD-3605190193.A9
3605190193
|
£59.53
|
£71.44
|
|
|
57 - PROTECTION SLEEVE
BSD-3600400004.A9
3600400004
|
£33.74
|
£40.49
|
|
|
60 - STRAINER
BSD-3600002001.A107
3600002001
|
£2.61
|
£3.13
|
|
|
66 - STRAIGHT PIN
BSD-3604710000.A31
3604710000
|
£5.58
|
£6.70
|
|
|
77 - HOLDING PIN
BSD-3603203004.A17
3603203004
|
£2.80
|
£3.36
|
|
|
78 - VALVE CONE
BSD-3603231000.A14
3603231000
|
£2.80
|
£3.36
|
|
|
86 - ADJUSTING SCREW
BSD-3603435048.A21
3603435048
|
£16.41
|
£19.69
|
|
|
87 - O-RING 4.0x1.0 MM
BSD-3600210015.A73
3600210015
|
£3.72
|
£4.47
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A491
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110331.A42
3601110331
|
£3.72
|
£4.47
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A489
3601119236
|
£3.72
|
£4.47
|
|
|
651 - HOSE FITTING
BSD-3603386067.A17
3603386067
|
£21.52
|
£25.83
|
|
|
701 - FASTENING FLANGE
BSD-3605700045.A21
3605700045
|
£120.11
|
£144.13
|
|
|
750 - SILENCER
BSD-3607000074.A51
3607000074
|
£23.86
|
£28.63
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031016.A29
3607031016
|
-
|
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030249.A29
3607030249
|
£33.73
|
£40.48
|
|
|
818 - PARTS SET
BSD-3607010007.A59
3607010007
|
£18.96
|
£22.75
|
|
|
840 - PARTS SET
BSD-3607010007.A60
3607010007
|
£18.96
|
£22.75
|
|
|
855 - PARTS SET
BSD-3607010020.A81
3607010020
|
£8.67
|
£10.41
|
|
