1 - MOTOR HOUSING
BSD-3600760001.A20
3600760001
|
£57.14
|
£68.57
|
|
|
2 - STATOR 370W
BSD-3604090043.A0
3604090043
|
£85.90
|
£103.08
|
|
|
3 - ROTOR
BSD-3604220025.A33
3604220025
|
£107.69
|
£129.23
|
|
|
5 - BEARING FLANGE
BSD-3605700005.A142
3605700005
|
£57.14
|
£68.57
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A158
3600905039
|
£12.04
|
£14.45
|
|
|
7 - BEARING FLANGE
BSD-3605700079.A0
3605700079
|
-
|
|
|
|
8 - GROOVE BALL BEARING DIN 625-7x19x6
BSD-3600905148.A89
3600905148
|
£8.92
|
£10.70
|
|
|
9 - SPACER RING
BSD-2600202013.A117
2600202013
|
£8.67
|
£10.41
|
|
|
10 - SPACER RING
BSD-3600202011.A0
3600202011
|
£17.22
|
£20.67
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A295
2916011012
|
£1.84
|
£2.21
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A101
2911061150
|
£2.74
|
£3.29
|
|
|
13 - INTERMEDIATE PIECE
BSD-3602305000.A56
3602305000
|
£37.27
|
£44.72
|
|
|
14 - CYLINDRICAL GEAR
BSD-3606316101.A42
3606316101
|
£22.76
|
£27.31
|
|
|
15 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A32
3600913000
|
£4.26
|
£5.11
|
|
|
16 - CYLINDRICAL GEAR
BSD-3606316100.A66
3606316100
|
£21.52
|
£25.83
|
|
|
26 - PINION
BSD-3606300005.A15
3606300005
|
£31.64
|
£37.97
|
|
|
27 - STOP DISC
BSD-3600101001.A155
3600101001
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=49
BSD-3606334000.A72
3606334000
|
£107.69
|
£129.23
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337004.A8
3606337004
|
£98.57
|
£118.28
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A370
3603201000
|
£1.84
|
£2.21
|
|
|
34 - SHIM WASHER
BSD-3600103002.A38
3600103002
|
£3.72
|
£4.47
|
|
|
35 - RETAINING RING
BSD-3600224000.A41
3600224000
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A138
1900900287
|
£21.68
|
£26.01
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337006.A9
3606337006
|
£85.90
|
£103.08
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905069.A93
3600905069
|
£17.22
|
£20.67
|
|
|
44 - THREADED BUSHING
BSD-3600390003.A55
3600390003
|
£12.64
|
£15.17
|
|
|
46 - THREADED RING
BSD-3603344000.A40
3603344000
|
£16.41
|
£19.69
|
|
|
56 - CONNECTION HOUSING
BSD-3605190121.A0
3605190121
|
-
|
|
|
|
60 - STRAINER
BSD-3600002001.A111
3600002001
|
£2.61
|
£3.13
|
|
|
66 - STRAIGHT PIN
BSD-3604710000.A35
3604710000
|
£5.87
|
£7.04
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A496
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110331.A49
3601110331
|
£3.72
|
£4.47
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A482
3601119236
|
£3.91
|
£4.69
|
|
|
650 - SILENCER
BSD-3607000074.A55
3607000074
|
£25.05
|
£30.06
|
|
|
651 - HOSE FITTING
BSD-3603386067.A20
3603386067
|
£22.60
|
£27.12
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031171.A0
3607031171
|
-
|
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030249.A35
3607030249
|
£35.42
|
£42.50
|
|
|
840 - PARTS SET
BSD-3607010007.A73
3607010007
|
£19.91
|
£23.89
|
|
|
855 - PARTS SET
BSD-3607010020.A74
3607010020
|
£9.11
|
£10.93
|
|
