2/10 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A276
1901350003
|
£1.84
|
£2.21
|
|
|
2/20 - BLADE TERMINAL
BSD-2601355007.A152
2601355007
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200371.A40
2607200371
|
-
|
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1477
3600703011
|
£2.94
|
£3.53
|
|
|
6 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A444
1600703009
|
£5.87
|
£7.04
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A629
1601302014
|
£2.74
|
£3.29
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110218.A0
1611110218
|
-
|
|
|
|
12 - HOUSING COVER
BSD-1615500208.A1
1615500208
|
-
|
|
|
|
13 - GEAR HOUSING
BSD-1615806055.A16
1615806055
|
-
|
|
|
|
14 - HANDLE COVER
BSD-1615132024.A1
1615132024
|
-
|
|
|
|
15 - FAN
BSD-1616610052.A3
1616610052
|
-
|
|
|
|
17 - RUBBER RING
BSD-1610206017.A2
1610206017
|
-
|
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522005.A43
1610522005
|
-
|
|
|
|
20 - BEARING PEDESTAL
BSD-1615820087.A45
1615820087
|
-
|
|
|
|
21 - BEVEL GEAR Z=33
BSD-1616333005.A2
1616333005
|
-
|
|
|
|
24 - CRANKSHAFT
BSD-1613124019.A42
1613124019
|
-
|
|
|
|
25 - ECCENTRIC BOLT
BSD-1613180002.A44
1613180002
|
-
|
|
|
|
26 - PRESSURE SPINDLE
BSD-1613105010.A43
1613105010
|
-
|
|
|
|
27 - COMPRESSION SPRING
BSD-1604612002.A49
1604612002
|
-
|
|
|
|
28 - SUPPRESSION FILTER
BSD-1607328028.A510
1607328028
|
£5.57
|
£6.68
|
|
|
29 - SHIM WASHER 1.8 MM
BSD-1610101610.A43
1610101610
|
-
|
|
|
|
30 - SHIM 0.2 MM
BSD-1610132004.A45
1610132004
|
-
|
|
|
|
31 - CONNECTING ROD
BSD-1612001030.A42
1612001030
|
-
|
|
|
|
33 - CYLINDRICAL GEAR Z=53/6
BSD-1616317025.A17
1616317025
|
-
|
|
|
|
34 - HAMMER PISTON
BSD-1618700051.A44
1618700051
|
-
|
|
|
|
35 - HOLLOW SHAFT Z=6
BSD-1616130005.A2
1616130005
|
-
|
|
|
|
36 - STRIKER
BSD-1618710046.A43
1618710046
|
-
|
|
|
|
37 - COMPRESSION SPRING
BSD-1614618001.A0
1614618001
|
-
|
|
|
|
38 - BACKUP RING
BSD-1610328010.A42
1610328010
|
-
|
|
|
|
39 - SPRING RETAINING RING DIN 471 25x1.2
BSD-2916650014.A165
2916650014
|
£1.84
|
£2.21
|
|
|
40 - BEARING SLEEVE
BSD-1616334010.A28
1616334010
|
-
|
|
|
|
41 - CARRIER 15 MM
BSD-1616490012.A0
1616490012
|
-
|
|
|
|
42 - STRIKER PIN 15 MM
BSD-1613124027.A3
1613124027
|
-
|
|
|
|
43 - TOOLHOLDER
BSD-1618597031.A24
1618597031
|
-
|
|
|
|
46 - STRAIGHT PIN
BSD-1613101004.A44
1613101004
|
-
|
|
|
|
47 - SUPPORTING DISC 3.0 MM
BSD-1610102016.A1
1610102016
|
-
|
|
|
|
50 - BRUSH HOLDER
BSD-1604336017.A174
1604336017
|
£7.36
|
£8.83
|
|
|
51 - SPIRAL SPRING
BSD-1604652006.A122
1604652006
|
£1.84
|
£2.21
|
|
|
52 - HOUSING COVER
BSD-1615500206.A3
1615500206
|
-
|
|
|
|
55 - HOLDING SPRING
BSD-1614680000.A44
1614680000
|
-
|
|
|
|
56 - CONTROL LEVER
BSD-1612026026.A1
1612026026
|
-
|
|
|
|
57 - CONTROL LEVER
BSD-1612026015.A34
1612026015
|
-
|
|
|
|
58 - SEALING FRAME
BSD-1611015025.A46
1611015025
|
-
|
|
|
|
63 - O-RING 62.0x4.0 MM
BSD-1610210089.A1
1610210089
|
-
|
|
|
|
64 - O-RING 45x2.5MM
BSD-1900210145.A71
1900210145
|
£1.75
|
£2.10
|
|
|
65 - INTERMEDIATE RING
BSD-1610300051.A5
1610300051
|
-
|
|
|
|
66 - BALL DIN 5401-5 G28
BSD-1903230009.A206
1903230009
|
£1.84
|
£2.21
|
|
|
67 - BALL DIN 5401-6 G28
BSD-1903230011.A102
1903230011
|
£2.74
|
£3.29
|
|
|
68 - DAMPING RING
BSD-1610210034.A27
1610210034
|
£1.84
|
£2.21
|
|
|
69 - O-RING 18.0x3.0 MM
BSD-1610210058.A215
1610210058
|
£2.74
|
£3.29
|
|
|
70 - O-RING 14.0x2.3 MM
BSD-1610210026.A44
1610210026
|
£1.75
|
£2.10
|
|
|
71 - SEAL RING dia 31.5x42x7 MM
BSD-1610283012.A30
1610283012
|
£8.49
|
£10.19
|
|
|
72 - ROTARY SHAFT LIP SEAL dia13.8xdia26x7.5 MM
BSD-1610283014.A61
1610283014
|
-
|
|
|
|
74 - NEEDLE BEARING dia35xdia42x12 MM
BSD-1610910051.A12
1610910051
|
-
|
|
|
|
75 - NEEDLE BEARING dia14xdia22x13 MM
BSD-1610910056.A3
1610910056
|
-
|
|
|
|
76 - NEEDLE BEARING
BSD-1610910069.A58
1610910069
|
-
|
|
|
|
77 - NEEDLE BEARING dia8xdia12x10 MM
BSD-1610910057.A133
1610910057
|
£2.80
|
£3.36
|
|
|
78 - GROOVE BALL BEARING 25x47x12
BSD-1900900275.A4
1900900275
|
-
|
|
|
|
79 - GROOVE BALL BEARING DIN 625 6000J C5
BSD-1900900278.A28
1900900278
|
-
|
|
|
|
80 - GROOVE BALL BEARING 10x26x8
BSD-1610905002.A42
1610905002
|
-
|
|
|
|
81 - LUBRICATING FELT
BSD-1610205003.A2
1610205003
|
-
|
|
|
|
83 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1349
2603410001
|
£1.84
|
£2.21
|
|
|
84 - TAPPING SCREW B 4.8x68 MM
BSD-1613412001.A165
1613412001
|
£1.75
|
£2.10
|
|
|
85 - SCREW B 4.8x45 MM
BSD-3603415560.A54
3603415560
|
£1.84
|
£2.21
|
|
|
86 - TAPPING SCREW DIN 7971-BZ4.8x32
BSD-2910211037.A12
2910211037
|
£1.84
|
£2.21
|
|
|
87 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A872
2910211021
|
£1.75
|
£2.10
|
|
|
88 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A1
2910211018
|
£1.75
|
£2.10
|
|
|
89 - TAPPING SCREW DIN 7971-BZ3.9x9.5
BSD-2910211017.A335
2910211017
|
-
|
|
|
|
90 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A131
2910141166
|
£1.84
|
£2.21
|
|
|
92 - COUNTERSUNK-HEAD SCREW
BSD-1613421000.A29
1613421000
|
-
|
|
|
|
94 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1490
2910021118
|
£1.84
|
£2.21
|
|
|
95 - SOCKET HEAD CAP SCREW DIN 84-BM4x30-8.8
BSD-2910021134.A61
2910021134
|
£1.75
|
£2.10
|
|
|
99 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x40-8.8
BSD-2910141170.A135
2910141170
|
£2.61
|
£3.13
|
|
|
100 - TAPPING SCREW BZ 3.9x19 DIN 7972
BSD-2910601120.A49
2910601120
|
-
|
|
|
|
102 - STRAIGHT PIN RIKO 6325-8m6x40
BSD-2917550184.A29
2917550184
|
-
|
|
|
|
103 - COMPRESSION SPRING
BSD-1614616004.A3
1614616004
|
-
|
|
|
|
104 - PROTECTION SLEEVE
BSD-1610499004.A5
1610499004
|
-
|
|
|
|
105 - RUBBER RING dia42xdia4.5x10 MM
BSD-1610206016.A29
1610206016
|
£1.75
|
£2.10
|
|
|
112 - PROTECTIVE CAP
BSD-1610590000.A30
1610590000
|
-
|
|
|
|
113 - RETAINING RING 26 DIN 9045
BSD-2916601014.A24
2916601014
|
-
|
|
|
|
115 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001003.A105
1613001003
|
£4.25
|
£5.10
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025019.A34
1612025019
|
£6.85
|
£8.22
|
|
|
121 - SUPPORT CLAMP
BSD-1618040077.A130
1618040077
|
-
|
|
|
|
122 - STUD BOLT M8
BSD-1613521001.A183
1613521001
|
£5.58
|
£6.70
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316006.A377
1611316006
|
£2.61
|
£3.13
|
|
|
124 - STRAIGHT PIN
BSD-1613100012.A166
1613100012
|
£2.61
|
£3.13
|
|
|
125 - WING SCREW M6x25 MM
BSD-1613480009.A118
1613480009
|
£1.88
|
£2.25
|
|
|
126 - HEX NUT M6
BSD-1613300006.A126
1613300006
|
£1.38
|
£1.66
|
|
|
127 - CLAMPING PLATE
BSD-1611030009.A76
1611030009
|
-
|
|
|
|
655 - PROTECTIVE CAP dia11xdia20.5x25 MM
BSD-1610508005.A21
1610508005
|
-
|
|
|
|
802 - CARBON-BRUSH SET
BSD-1617014106.A36
1617014106
|
£22.60
|
£27.12
|
|
|
803 - ARMATURE 220-230V
BSD-1614010027.A3
1614010027
|
-
|
|
|
|
805 - PARTS SET
BSD-1617000064.A30
1617000064
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3HC.A80
160111A3HC
|
£2.74
|
£3.29
|
|
|
810 - PARTS SET
BSD-1617000061.A1
1617000061
|
-
|
|
|
|
813 - AUXILIARY HANDLE
BSD-1612025020.A87
1612025020
|
£26.12
|
£31.35
|
|
|
820 - PARTS SET 220-230V
BSD-1617000140.A17
1617000140
|
-
|
|
|
|
822 - PARTS SET Z=9/48
BSD-1617000929.A18
1617000929
|
-
|
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A383
1607000227
|
£23.86
|
£28.63
|
|
|
876 - NEEDLE BEARING dia14xdia22x13 MM
BSD-1610910056.A4
1610910056
|
-
|
|
|
