2/10 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A79
1901350003
|
£1.84
|
£2.21
|
|
|
2/20 - BLADE TERMINAL
BSD-2601355007.A133
2601355007
|
-
|
|
|
|
4 - SWITCH
BSD-1617200052.A1
1617200052
|
£39.61
|
£47.53
|
|
|
5 - POWER SUPPLY CORD GB 110V 2.65m 2 x 2.5mm H07RN-F
BSD-1604460219.A5
1604460219
|
£21.68
|
£26.01
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A294
3600703011
|
£2.94
|
£3.53
|
|
|
6 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A262
1600703009
|
£5.87
|
£7.04
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A411
1601302014
|
£2.74
|
£3.29
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110205.A0
1611110205
|
-
|
|
|
|
12 - HOUSING COVER
BSD-1615500208.A3
1615500208
|
-
|
|
|
|
13 - GEAR HOUSING
BSD-1615806055.A18
1615806055
|
-
|
|
|
|
14 - HANDLE COVER
BSD-1615132024.A4
1615132024
|
-
|
|
|
|
15 - FAN
BSD-1616610052.A1
1616610052
|
-
|
|
|
|
17 - RUBBER RING
BSD-1610206017.A5
1610206017
|
-
|
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522005.A46
1610522005
|
-
|
|
|
|
20 - BEARING PEDESTAL
BSD-1615820087.A43
1615820087
|
-
|
|
|
|
21 - BEVEL GEAR Z=33
BSD-1616333005.A0
1616333005
|
-
|
|
|
|
24 - CRANKSHAFT
BSD-1613124019.A40
1613124019
|
-
|
|
|
|
25 - ECCENTRIC BOLT
BSD-1613180002.A43
1613180002
|
-
|
|
|
|
26 - PRESSURE SPINDLE
BSD-1613105010.A45
1613105010
|
-
|
|
|
|
27 - COMPRESSION SPRING
BSD-1604612002.A46
1604612002
|
-
|
|
|
|
28 - SUPPRESSION FILTER
BSD-1607328028.A512
1607328028
|
£5.57
|
£6.68
|
|
|
29 - SHIM WASHER 1.8 MM
BSD-1610101610.A41
1610101610
|
-
|
|
|
|
30 - SHIM 0.2 MM
BSD-1610132004.A43
1610132004
|
-
|
|
|
|
31 - CONNECTING ROD
BSD-1612001030.A45
1612001030
|
-
|
|
|
|
33 - CYLINDRICAL GEAR Z=53/6
BSD-1616317025.A19
1616317025
|
-
|
|
|
|
34 - HAMMER PISTON
BSD-1618700051.A46
1618700051
|
-
|
|
|
|
35 - HOLLOW SHAFT Z=6
BSD-1616130005.A4
1616130005
|
-
|
|
|
|
36 - STRIKER
BSD-1618710046.A41
1618710046
|
-
|
|
|
|
37 - COMPRESSION SPRING
BSD-1614618001.A3
1614618001
|
-
|
|
|
|
38 - BACKUP RING
BSD-1610328010.A44
1610328010
|
-
|
|
|
|
39 - SPRING RETAINING RING DIN 471 25x1.2
BSD-2916650014.A162
2916650014
|
£1.84
|
£2.21
|
|
|
40 - BEARING SLEEVE
BSD-1616334010.A30
1616334010
|
-
|
|
|
|
41 - CARRIER 15 MM
BSD-1616490012.A2
1616490012
|
-
|
|
|
|
42 - STRIKER PIN 15 MM
BSD-1613124027.A5
1613124027
|
-
|
|
|
|
43 - TOOLHOLDER
BSD-1618597031.A23
1618597031
|
-
|
|
|
|
46 - STRAIGHT PIN
BSD-1613101004.A41
1613101004
|
-
|
|
|
|
47 - SUPPORTING DISC 3.0 MM
BSD-1610102016.A4
1610102016
|
-
|
|
|
|
50 - BRUSH HOLDER
BSD-1604336017.A176
1604336017
|
£7.36
|
£8.83
|
|
|
51 - SPIRAL SPRING
BSD-1604652006.A125
1604652006
|
£1.84
|
£2.21
|
|
|
52 - HOUSING COVER
BSD-1615500206.A2
1615500206
|
-
|
|
|
|
55 - HOLDING SPRING
BSD-1614680000.A42
1614680000
|
-
|
|
|
|
56 - CONTROL LEVER
BSD-1612026026.A4
1612026026
|
-
|
|
|
|
57 - CONTROL LEVER
BSD-1612026015.A31
1612026015
|
-
|
|
|
|
58 - SEALING FRAME
BSD-1611015025.A43
1611015025
|
-
|
|
|
|
63 - O-RING 62.0x4.0 MM
BSD-1610210089.A4
1610210089
|
-
|
|
|
|
64 - O-RING 45x2.5MM
BSD-1900210145.A74
1900210145
|
£1.75
|
£2.10
|
|
|
65 - INTERMEDIATE RING
BSD-1610300051.A2
1610300051
|
-
|
|
|
|
66 - BALL DIN 5401-5 G28
BSD-1903230009.A209
1903230009
|
£1.84
|
£2.21
|
|
|
67 - BALL DIN 5401-6 G28
BSD-1903230011.A99
1903230011
|
£2.74
|
£3.29
|
|
|
68 - DAMPING RING
BSD-1610210034.A30
1610210034
|
£1.84
|
£2.21
|
|
|
69 - O-RING 18.0x3.0 MM
BSD-1610210058.A212
1610210058
|
£2.61
|
£3.13
|
|
|
70 - O-RING 14.0x2.3 MM
BSD-1610210026.A41
1610210026
|
£1.75
|
£2.10
|
|
|
71 - SEAL RING dia 31.5x42x7 MM
BSD-1610283012.A27
1610283012
|
£8.49
|
£10.19
|
|
|
72 - ROTARY SHAFT LIP SEAL dia13.8xdia26x7.5 MM
BSD-1610283014.A64
1610283014
|
-
|
|
|
|
74 - NEEDLE BEARING dia35xdia42x12 MM
BSD-1610910051.A9
1610910051
|
-
|
|
|
|
75 - NEEDLE BEARING dia14xdia22x13 MM
BSD-1610910056.A9
1610910056
|
-
|
|
|
|
76 - NEEDLE BEARING
BSD-1610910069.A61
1610910069
|
-
|
|
|
|
77 - NEEDLE BEARING dia8xdia12x10 MM
BSD-1610910057.A130
1610910057
|
£2.80
|
£3.36
|
|
|
78 - GROOVE BALL BEARING 25x47x12
BSD-1900900275.A1
1900900275
|
-
|
|
|
|
79 - GROOVE BALL BEARING DIN 625 6000J C5
BSD-1900900278.A31
1900900278
|
-
|
|
|
|
80 - GROOVE BALL BEARING 10x26x8
BSD-1610905002.A45
1610905002
|
-
|
|
|
|
81 - LUBRICATING FELT
BSD-1610205003.A5
1610205003
|
-
|
|
|
|
83 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1346
2603410001
|
£1.84
|
£2.21
|
|
|
84 - TAPPING SCREW B 4.8x68 MM
BSD-1613412001.A162
1613412001
|
£1.75
|
£2.10
|
|
|
85 - SCREW B 4.8x45 MM
BSD-3603415560.A52
3603415560
|
£1.75
|
£2.10
|
|
|
86 - TAPPING SCREW DIN 7971-BZ4.8x32
BSD-2910211037.A16
2910211037
|
£1.84
|
£2.21
|
|
|
87 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A869
2910211021
|
£1.75
|
£2.10
|
|
|
88 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A4
2910211018
|
£1.75
|
£2.10
|
|
|
89 - TAPPING SCREW DIN 7971-BZ3.9x9.5
BSD-2910211017.A332
2910211017
|
-
|
|
|
|
90 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A128
2910141166
|
£1.84
|
£2.21
|
|
|
92 - COUNTERSUNK-HEAD SCREW
BSD-1613421000.A32
1613421000
|
-
|
|
|
|
94 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1487
2910021118
|
£1.84
|
£2.21
|
|
|
95 - SOCKET HEAD CAP SCREW DIN 84-BM4x30-8.8
BSD-2910021134.A64
2910021134
|
£1.75
|
£2.10
|
|
|
99 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x40-8.8
BSD-2910141170.A138
2910141170
|
£2.61
|
£3.13
|
|
|
100 - TAPPING SCREW BZ 3.9x19 DIN 7972
BSD-2910601120.A51
2910601120
|
-
|
|
|
|
102 - STRAIGHT PIN RIKO 6325-8m6x40
BSD-2917550184.A31
2917550184
|
-
|
|
|
|
103 - COMPRESSION SPRING
BSD-1614616004.A2
1614616004
|
-
|
|
|
|
104 - PROTECTION SLEEVE
BSD-1610499004.A2
1610499004
|
-
|
|
|
|
105 - RUBBER RING dia42xdia4.5x10 MM
BSD-1610206016.A26
1610206016
|
£1.75
|
£2.10
|
|
|
112 - PROTECTIVE CAP
BSD-1610590000.A27
1610590000
|
-
|
|
|
|
113 - RETAINING RING 26 DIN 9045
BSD-2916601014.A22
2916601014
|
-
|
|
|
|
115 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001003.A102
1613001003
|
£4.25
|
£5.10
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025019.A32
1612025019
|
£6.85
|
£8.22
|
|
|
121 - SUPPORT CLAMP
BSD-1618040077.A132
1618040077
|
-
|
|
|
|
122 - STUD BOLT M8
BSD-1613521001.A186
1613521001
|
£5.58
|
£6.70
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316003.A151
1611316003
|
£2.61
|
£3.13
|
|
|
124 - STRAIGHT PIN
BSD-1613100012.A169
1613100012
|
£2.61
|
£3.13
|
|
|
125 - WING SCREW M6x25 MM
BSD-1613480009.A115
1613480009
|
£1.88
|
£2.25
|
|
|
126 - HEX NUT M6
BSD-1613300006.A129
1613300006
|
£1.38
|
£1.66
|
|
|
127 - CLAMPING PLATE
BSD-1611030009.A79
1611030009
|
-
|
|
|
|
135 - REFERENCE PLATE
BSD-1611110387.A2
1611110387
|
£1.84
|
£2.21
|
|
|
802 - CARBON-BRUSH SET
BSD-1617014106.A35
1617014106
|
£22.60
|
£27.12
|
|
|
803 - ARMATURE 110-115V
BSD-1614010028.A7
1614010028
|
-
|
|
|
|
805 - PARTS SET
BSD-1617000064.A27
1617000064
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3HC.A77
160111A3HC
|
£2.74
|
£3.29
|
|
|
810 - PARTS SET
BSD-1617000061.A4
1617000061
|
-
|
|
|
|
813 - AUXILIARY HANDLE
BSD-1612025020.A90
1612025020
|
£26.12
|
£31.35
|
|
|
820 - PARTS SET 110V
BSD-1617000142.A0
1617000142
|
-
|
|
|
|
822 - PARTS SET Z=9/48
BSD-1617000929.A19
1617000929
|
-
|
|
|
|
876 - NEEDLE BEARING dia14xdia22x13 MM
BSD-1610910056.A10
1610910056
|
-
|
|
|
