2 - STATOR 200V/300HZ
BSD-3604229064.A17
3604229064
|
£500.46
|
£600.55
|
|
|
3/8 - GROOVE BALL BEARING 12x32x10
BSD-3600905119.A159
3600905119
|
£27.23
|
£32.68
|
|
|
4 - AIR-DEFLECTOR RING
BSD-3600209006.A104
3600209006
|
£5.58
|
£6.70
|
|
|
6 - GROOVE BALL BEARING
BSD-3600905095.A192
3600905095
|
£21.52
|
£25.83
|
|
|
7 - BEARING FLANGE
BSD-3605805009.A107
3605805009
|
£59.53
|
£71.44
|
|
|
14 - THREADED RING
BSD-3603344024.A234
3603344024
|
£16.41
|
£19.69
|
|
|
15 - O-RING 38.1x2.2 MM
BSD-1600210037.A112
1600210037
|
£2.61
|
£3.13
|
|
|
20 - THREAD-FORMING TAP. SCREW
BSD-2914451079.A2
2914451079
|
£2.61
|
£3.13
|
|
|
21 - THREAD-FORMING TAP. SCREW AM 6x80-ST
BSD-3603410007.A123
3603410007
|
£3.72
|
£4.47
|
|
|
23 - COMPRESSION SPRING
BSD-3604611019.A170
3604611019
|
£2.61
|
£3.13
|
|
|
27 - SEALING DISC
BSD-3600100049.A99
3600100049
|
£3.72
|
£4.47
|
|
|
28 - SEALING DISC
BSD-3600100048.A177
3600100048
|
£2.80
|
£3.36
|
|
|
60 - ELEC. CABLE W/CONNECTION
BSD-3604462017.A132
3604462017
|
£54.42
|
£65.30
|
|
|
61 - TAPPING SCREW BZ4.8x63 MM
BSD-1603435008.A66
1603435008
|
£1.32
|
£1.58
|
|
|
62 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A371
2910211020
|
£2.16
|
£2.59
|
|
|
63 - CABLE ROUTING
BSD-1602388027.A268
1602388027
|
£2.61
|
£3.13
|
|
|
64 - FASTENING CLAMP
BSD-3601303002.A47
3601303002
|
£2.61
|
£3.13
|
|
|
64 - FASTENING CLAMP
BSD-3601303004.A112
3601303004
|
£5.58
|
£6.70
|
|
|
65 - STORAGE LEDGE
BSD-1602388029.A345
1602388029
|
£1.75
|
£2.10
|
|
|
94 - SET SCREW DIN 915-M4x6-45H
BSD-2912081116.A384
2912081116
|
£2.61
|
£3.13
|
|
|
95 - NAMEPLATE
BSD-3601106053.A1221
3601106053
|
£5.30
|
£6.36
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A64
3601110047
|
£2.80
|
£3.36
|
|
|
97 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A354
3603133001
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A145
3601119236
|
£3.72
|
£4.47
|
|
|
103 - GRINDING SPINDLE
BSD-3606120009.A21
3606120009
|
£218.41
|
£262.09
|
|
|
105 - GROOVE BALL BEARING
BSD-3600905060.A78
3600905060
|
£21.52
|
£25.83
|
|
|
106 - GROOVE BALL BEARING
BSD-3600905057.A19
3600905057
|
£21.68
|
£26.01
|
|
|
108 - TOOTHED GEAR Z=25
BSD-3606300094.A3
3606300094
|
£93.88
|
£112.65
|
|
|
109 - TOOTHED GEAR Z=44
BSD-3606300093.A10
3606300093
|
-
|
|
|
|
110 - SPACER SLEEVE
BSD-3600700056.A11
3600700056
|
£40.80
|
£48.96
|
|
|
112 - O-RING 43.0x2.0 MM
BSD-3600210058.A14
3600210058
|
£1.75
|
£2.10
|
|
|
114 - THREADED RING
BSD-3603344024.A233
3603344024
|
£16.41
|
£19.69
|
|
|
115 - O-RING 33.0x2.5 MM
BSD-3600210050.A60
3600210050
|
£2.61
|
£3.13
|
|
|
117 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x20-8.8
BSD-2910141201.A375
2910141201
|
£2.61
|
£3.13
|
|
|
118 - PLAIN WASHER
BSD-3600100043.A123
3600100043
|
£3.72
|
£4.47
|
|
|
119 - O-RING 79.0x1.78 MM
BSD-1600210033.A882
1600210033
|
£1.75
|
£2.10
|
|
|
123 - RETAINING RING 24x2 DIN9045-24
BSD-2916609112.A144
2916609112
|
£2.61
|
£3.13
|
|
|
650 - SINGLE-HEAD ENG. WRENCH SW32
BSD-3607950010.A35
3607950010
|
£27.23
|
£32.68
|
|
|
651 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A756
1607950061
|
£5.42
|
£6.50
|
|
|
655 - PROTECTIVE COVER dia 125 MM
BSD-3605510030.A16
3605510030
|
£27.23
|
£32.68
|
|
|
656 - CLAMPING-FLANGE
BSD-3605703112.A28
3605703112
|
£48.38
|
£58.06
|
|
|
656/10 - CLAMPING-FLANGE
BSD-3605703071.A13
3605703071
|
-
|
|
|
|
657 - CLAMPING RING
BSD-3605703077.A14
3605703077
|
£37.27
|
£44.72
|
|
|
657/10 - CLAMPING RING
BSD-3605703075.A11
3605703075
|
£27.23
|
£32.68
|
|
|
658 - RETAINING RING 24x2 DIN9045-24
BSD-2916609112.A145
2916609112
|
£2.61
|
£3.13
|
|
|
801 - MOTOR HOUSING GR.88
BSD-3605108160.A55
3605108160
|
£179.37
|
£215.24
|
|
|
803 - ROTOR
BSD-3604080025.A25
3604080025
|
£283.50
|
£340.20
|
|
|
803 - ROTOR
BSD-3604080025.A26
3604080025
|
£283.50
|
£340.20
|
|
|
810 - BEARING FLANGE
BSD-3607031292.A42
3607031292
|
£156.22
|
£187.46
|
|
|
810/020 - SPINDLE BEARING
BSD-3607031291.A44
3607031291
|
£357.27
|
£428.72
|
|
|
810/077 - SET OF EARTLING MATERIAL
BSD-3607031299.A130
3607031299
|
£8.67
|
£10.41
|
|
|
811 - FASTENING PARTS KIT
BSD-3607031290.A13
3607031290
|
£120.11
|
£144.13
|
|
|
823 - SPRING SET
BSD-3607031296.A147
3607031296
|
£16.41
|
£19.69
|
|
|
856 - SWITCH KIT
BSD-3607031298.A81
3607031298
|
£81.81
|
£98.17
|
|
|
858 - HANDLE
BSD-3607031297.A117
3607031297
|
£37.27
|
£44.72
|
|
|
859 - GROMMET
BSD-3607031550.A35
3607031550
|
£13.12
|
£15.75
|
|
