1 - MOTOR HOUSING
BSD-3600760110.A2
3600760110
|
£75.79
|
£90.95
|
|
|
2 - STATOR 180W
BSD-3604090061.A7
3604090061
|
£135.25
|
£162.30
|
|
|
3 - ROTOR
BSD-3604220080.A26
3604220080
|
£102.57
|
£123.08
|
|
|
5 - BEARING FLANGE
BSD-3605700107.A23
3605700107
|
£39.13
|
£46.96
|
|
|
6 - GROOVE BALL BEARING 7x19x6
BSD-1900905044.A5
1900905044
|
£7.72
|
£9.27
|
|
|
7 - BEARING FLANGE
BSD-3605700109.A5
3605700109
|
£47.95
|
£57.54
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A58
1900905028
|
£33.74
|
£40.49
|
|
|
26 - PINION Z=15
BSD-3606300018.A9
3606300018
|
£28.68
|
£34.41
|
|
|
27 - STOP DISC
BSD-3600101047.A51
3600101047
|
£2.16
|
£2.59
|
|
|
28 - RING GEAR dia19.5 MM
BSD-3606334085.A32
3606334085
|
£8.67
|
£10.41
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337181.A32
3606337181
|
£48.38
|
£58.06
|
|
|
31 - CYLINDRICAL GEAR Z=13
BSD-3606316010.A48
3606316010
|
-
|
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A441
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A40
3603201000
|
£1.84
|
£2.21
|
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A133
3600905002
|
£16.41
|
£19.69
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337018.A13
3606337018
|
£85.90
|
£103.08
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316114.A32
3606316114
|
£13.78
|
£16.54
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905015.A149
3600905015
|
£17.22
|
£20.67
|
|
|
44 - THREADED BUSHING
BSD-3600390003.A88
3600390003
|
£12.64
|
£15.17
|
|
|
46 - THREADED RING
BSD-3603344004.A65
3603344004
|
£15.65
|
£18.78
|
|
|
56 - CONNECTION HOUSING
BSD-3605190202.A18
3605190202
|
£102.57
|
£123.08
|
|
|
60 - STRAINER
BSD-3600002001.A22
3600002001
|
£2.61
|
£3.13
|
|
|
66 - STRAIGHT PIN
BSD-3603201083.A6
3603201083
|
£7.36
|
£8.83
|
|
|
67 - HALF-LENGTH GROOVED PIN ISO 8741-2x10-ST
BSD-2917690036.A42
2917690036
|
£1.75
|
£2.10
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A182
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119169.A5
3601119169
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1821
3601119236
|
£3.91
|
£4.69
|
|
|
650 - SILENCER
BSD-3607000075.A5
3607000075
|
£16.41
|
£19.69
|
|
|
651 - HOSE FITTING
BSD-3603386002.A36
3603386002
|
£3.34
|
£4.01
|
|
|
801 - ASSEMBLY KIT
BSD-3607030379.A0
3607030379
|
-
|
|
|
|
803 - ASSEMBLY KIT
BSD-3607030387.A2
3607030387
|
£410.78
|
£492.94
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607031304.A53
3607031304
|
£28.59
|
£34.31
|
|
|
805 - ASSEMBLY KIT
BSD-3607030388.A3
3607030388
|
£179.37
|
£215.24
|
|
|
809 - ASSEMBLY KIT
BSD-3607030383.A3
3607030383
|
£102.57
|
£123.08
|
|
|
855 - PARTS SET
BSD-3607010020.A21
3607010020
|
£9.11
|
£10.93
|
|
