1 - MOTOR HOUSING
BSD-3600760007.A7
3600760007
|
-
|
|
|
|
2 - STATOR 180W
BSD-3604090011.A48
3604090011
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220009.A59
3604220009
|
£75.79
|
£90.95
|
|
|
5 - BEARING FLANGE
BSD-3605700015.A10
3605700015
|
£47.95
|
£57.54
|
|
|
6 - BALL BEARING 7x19x6
BSD-2600905032.A1284
2600905032
|
£5.57
|
£6.68
|
|
|
7 - BEARING FLANGE
BSD-3605700015.A11
3605700015
|
£47.95
|
£57.54
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A64
1900905028
|
£33.74
|
£40.49
|
|
|
11 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A237
2916011011
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A193
2911061150
|
£2.74
|
£3.29
|
|
|
25 - SHIM WASHER
BSD-3600100007.A12
3600100007
|
£1.75
|
£2.10
|
|
|
26 - PINION Z=9
BSD-3606300046.A2
3606300046
|
£21.42
|
£25.71
|
|
|
27 - STOP DISC
BSD-3600101047.A55
3600101047
|
£2.16
|
£2.59
|
|
|
28 - RING GEAR Z=42
BSD-3606334005.A0
3606334005
|
£59.53
|
£71.44
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337041.A20
3606337041
|
£93.88
|
£112.65
|
|
|
31 - CYLINDRICAL GEAR
BSD-3606316112.A51
3606316112
|
£22.76
|
£27.31
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A420
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A56
3603201000
|
£1.84
|
£2.21
|
|
|
34 - STOP DISC
BSD-3600103003.A10
3600103003
|
£2.80
|
£3.36
|
|
|
35 - RETAINING RING
BSD-3600224002.A21
3600224002
|
£1.84
|
£2.21
|
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A152
3600905002
|
£16.41
|
£19.69
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337092.A1
3606337092
|
-
|
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316112.A52
3606316112
|
£22.76
|
£27.31
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905015.A154
3600905015
|
£17.22
|
£20.67
|
|
|
46 - THREADED RING
BSD-3603344021.A7
3603344021
|
-
|
|
|
|
47 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A266
2916650003
|
£1.75
|
£2.10
|
|
|
56 - CONNECTION HOUSING
BSD-3605190202.A11
3605190202
|
£102.57
|
£123.08
|
|
|
60 - STRAINER
BSD-3600002001.A14
3600002001
|
£2.61
|
£3.13
|
|
|
66 - STRAIGHT PIN
BSD-3603201009.A16
3603201009
|
£5.58
|
£6.70
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A175
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110013.A56
1601110013
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1830
3601119236
|
£3.91
|
£4.69
|
|
|
650 - SILENCER
BSD-3607000016.A15
3607000016
|
£21.52
|
£25.83
|
|
|
651 - HOSE FITTING
BSD-3603386002.A41
3603386002
|
£3.34
|
£4.01
|
|
|
701 - FASTENING FLANGE
BSD-3605700044.A5
3605700044
|
£75.79
|
£90.95
|
|
|
800 - ASSEMBLY OF SERVICE PARTS
BSD-3607031048.A2
3607031048
|
-
|
|
|
|
804 - PARTS SET
BSD-3607030256.A12
3607030256
|
£31.95
|
£38.34
|
|
|
855 - PARTS SET
BSD-3607010020.A42
3607010020
|
£9.11
|
£10.93
|
|
