1 - MOTOR HOUSING
BSD-16051082JD.A17
16051082JD
|
-
|
|
|
|
2 - STATOR 180W
BSD-3604090050.A74
3604090050
|
£93.88
|
£112.65
|
|
|
3 - ROTOR
BSD-3604220081.A24
3604220081
|
£107.69
|
£129.23
|
|
|
5 - BEARING FLANGE
BSD-3605700107.A50
3605700107
|
£37.27
|
£44.72
|
|
|
6 - GROOVE BALL BEARING 7x19x6
BSD-1900905044.A33
1900905044
|
£7.36
|
£8.83
|
|
|
7 - BEARING FLANGE
BSD-3605700109.A0
3605700109
|
£45.67
|
£54.80
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A112
1900905028
|
£33.74
|
£40.49
|
|
|
26 - PINION Z=15
BSD-3606300015.A9
3606300015
|
-
|
|
|
|
27 - STOP DISC
BSD-3600101047.A71
3600101047
|
£2.16
|
£2.59
|
|
|
28 - RING GEAR dia19.5 MM
BSD-3606334085.A17
3606334085
|
£8.67
|
£10.41
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337181.A20
3606337181
|
£48.38
|
£58.06
|
|
|
31 - CYLINDRICAL GEAR Z=13
BSD-3606316010.A36
3606316010
|
-
|
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A469
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A119
3603201000
|
£1.84
|
£2.21
|
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A184
3600905002
|
£16.41
|
£19.69
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337015.A17
3606337015
|
£98.57
|
£118.28
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316114.A25
3606316114
|
£13.78
|
£16.54
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905015.A183
3600905015
|
£17.22
|
£20.67
|
|
|
51 - COVER DISC
BSD-3600100065.A0
3600100065
|
£7.78
|
£9.33
|
|
|
54 - COMPRESSION SPRING
BSD-3604611017.A1
3604611017
|
£2.61
|
£3.13
|
|
|
56 - VALVE HOUSING
BSD-3605190177.A0
3605190177
|
-
|
|
|
|
58 - O-RING 4.3x2.4 MM
BSD-3600210084.A26
3600210084
|
£2.61
|
£3.13
|
|
|
60 - STRAINER
BSD-3600002000.A319
3600002000
|
£3.72
|
£4.47
|
|
|
61 - O-RING 9.0x1.5 MM
BSD-2600210021.A56
2600210021
|
£1.75
|
£2.10
|
|
|
62 - FITTING
BSD-3603458016.A73
3603458016
|
£11.87
|
£14.24
|
|
|
63 - STRAIGHT PIN L=9.5 MM
BSD-3603201062.A4
3603201062
|
£6.52
|
£7.83
|
|
|
65 - STRAIGHT PIN
BSD-3603201026.A11
3603201026
|
£7.72
|
£9.27
|
|
|
66 - STRAIGHT PIN
BSD-3603201077.A37
3603201077
|
£11.30
|
£13.56
|
|
|
68 - BALL DIN 5401-8 MM III-ST
BSD-1903230014.A120
1903230014
|
£1.75
|
£2.10
|
|
|
80 - COMPRESSION SPRING
BSD-3604615009.A23
3604615009
|
£2.27
|
£2.72
|
|
|
87 - SILENCER
BSD-3601010010.A121
3601010010
|
£2.16
|
£2.59
|
|
|
88 - SILENCER
BSD-3601010037.A4
3601010037
|
£11.87
|
£14.24
|
|
|
89 - SILENCER
BSD-3601010044.A72
3601010044
|
£7.36
|
£8.83
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A256
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119055.A23
3601119055
|
£3.72
|
£4.47
|
|
|
98 - STICKER
BSD-3601110204.A23
3601110204
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1924
3601119236
|
£3.91
|
£4.69
|
|
|
100 - HOUSING
BSD-3605125011.A22
3605125011
|
£48.38
|
£58.06
|
|
|
101 - CLUTCH ELEMENT
BSD-3606432006.A10
3606432006
|
£85.90
|
£103.08
|
|
|
102 - DRIVE SHAFT
BSD-3606122009.A0
3606122009
|
£81.81
|
£98.17
|
|
|
106 - COMPRESSION SPRING
BSD-3604615000.A10
3604615000
|
£1.75
|
£2.10
|
|
|
109 - COMPRESSION SPRING
BSD-3604619003.A38
3604619003
|
£5.58
|
£6.70
|
|
|
110 - RETAINING RING
BSD-3604601002.A12
3604601002
|
£1.84
|
£2.21
|
|
|
113 - UNION NUT
BSD-3603340000.A18
3603340000
|
£4.26
|
£5.11
|
|
|
114 - BUSHING
BSD-3600202000.A12
3600202000
|
£5.87
|
£7.04
|
|
|
115 - SEALING PLATE
BSD-3600001002.A60
3600001002
|
£3.72
|
£4.47
|
|
|
116 - ADJUSTING DISC
BSD-3600134003.A19
3600134003
|
£2.61
|
£3.13
|
|
|
119 - SUPPORT DISC
BSD-3600114002.A63
3600114002
|
£12.04
|
£14.45
|
|
|
120 - ROUND NUT
BSD-3603344009.A59
3603344009
|
£28.59
|
£34.31
|
|
|
124 - COUPLING PLATE
BSD-3600220000.A6
3600220000
|
£10.10
|
£12.12
|
|
|
126 - LEAF SPRING
BSD-2601250001.A76
2601250001
|
£3.72
|
£4.47
|
|
|
127 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A150
1903230007
|
£1.84
|
£2.21
|
|
|
128 - BALL DIN 5401-5 G28
BSD-1903230009.A176
1903230009
|
£1.84
|
£2.21
|
|
|
129 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A451
1903230003
|
£2.74
|
£3.29
|
|
|
130 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A452
1903230003
|
£2.74
|
£3.29
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A85
2916600008
|
£2.80
|
£3.36
|
|
|
652 - HOSE FITTING
BSD-3603386066.A1
3603386066
|
£14.91
|
£17.89
|
|
|
653 - ANGLE PIECE
BSD-3601329007.A50
3601329007
|
£4.48
|
£5.37
|
|
|
660 - SUSPENSION LOOP
BSD-2604720004.A108
2604720004
|
£4.26
|
£5.11
|
|
|
705 - HANDLE
BSD-3600499001.A26
3600499001
|
£31.64
|
£37.97
|
|
|
706 - COMPRESSION SPRING
BSD-3604618003.A59
3604618003
|
£7.72
|
£9.27
|
|
|
708 - SINGLE-HEAD ENG. WRENCH SW22
BSD-1607950505.A120
1607950505
|
£17.22
|
£20.67
|
|
|
712 - HEXAGON-SOCKET KEY
BSD-3607950001.A175
3607950001
|
£2.80
|
£3.36
|
|
|
751 - GUIDE SLEEVE
BSD-3600329000.A81
3600329000
|
£7.36
|
£8.83
|
|
|
801 - OVERRIDING CLUTCH
BSD-3607031119.A0
3607031119
|
-
|
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031219.A2
3607031219
|
-
|
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607031304.A16
3607031304
|
£28.59
|
£34.31
|
|
|
808 - ASSEMBLY OF SERVICE PARTS
BSD-3607031363.A1
3607031363
|
-
|
|
|
|
821 - ASSEMBLY OF SERVICE PARTS
BSD-3607031087.A124
3607031087
|
£12.64
|
£15.17
|
|
|
843 - PARTS SET
BSD-3607010010.A78
3607010010
|
£7.36
|
£8.83
|
|
|
859 - HOLDING BELT
BSD-3604710062.A12
3604710062
|
£1.84
|
£2.21
|
|
|
876 - PARTS SET
BSD-3607010020.A51
3607010020
|
£9.11
|
£10.93
|
|
|
882 - O-RING
BSD-3607010006.A135
3607010006
|
£33.22
|
£39.87
|
|
|
890 - AUXILIARY HANDLE
BSD-3607031351.A24
3607031351
|
£72.18
|
£86.62
|
|
|
891 - AIR HOSE
BSD-3607000083.A53
3607000083
|
£62.51
|
£75.01
|
|
|
899 - AIR HOSE
BSD-3607000064.A23
3607000064
|
£27.23
|
£32.68
|
|
