1 - MOTOR HOUSING
BSD-3600760020.A7
3600760020
|
£61.70
|
£74.04
|
|
|
2 - STATOR 180W
BSD-3604090010.A33
3604090010
|
£85.90
|
£103.08
|
|
|
3 - ROTOR
BSD-3604220009.A5
3604220009
|
£75.79
|
£90.95
|
|
|
5 - BEARING FLANGE
BSD-3605700015.A89
3605700015
|
£47.95
|
£57.54
|
|
|
6 - BALL BEARING 7x19x6
BSD-2600905032.A2311
2600905032
|
£5.57
|
£6.68
|
|
|
7 - BEARING FLANGE
BSD-3605700017.A31
3605700017
|
£50.80
|
£60.96
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A284
1900905028
|
£33.74
|
£40.49
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A249
2916011012
|
£1.84
|
£2.21
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A64
2911061150
|
£2.74
|
£3.29
|
|
|
26 - PINION
BSD-3606300013.A35
3606300013
|
£14.08
|
£16.89
|
|
|
27 - STOP DISC
BSD-3600101047.A150
3600101047
|
£2.16
|
£2.59
|
|
|
28 - RING GEAR Z=42/54
BSD-3606334021.A37
3606334021
|
£18.96
|
£22.75
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337056.A9
3606337056
|
£48.38
|
£58.06
|
|
|
31 - CYLINDRICAL GEAR Z=14
BSD-3606316011.A27
3606316011
|
£8.17
|
£9.80
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A117
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A252
3603201000
|
£1.84
|
£2.21
|
|
|
36 - GROOVE BALL BEARING 12x21x5
BSD-3600905002.A26
3600905002
|
£16.41
|
£19.69
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337037.A4
3606337037
|
-
|
|
|
|
39 - CYLINDRICAL GEAR Z=14
BSD-3606316011.A28
3606316011
|
£8.17
|
£9.80
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905015.A53
3600905015
|
£17.22
|
£20.67
|
|
|
43 - PARTS SET
BSD-3607010010.A21
3607010010
|
£7.36
|
£8.83
|
|
|
56 - MOTOR HOUSING
BSD-3605190155.A1
3605190155
|
-
|
|
|
|
57 - HOUSING COVER
BSD-3605500003.A22
3605500003
|
£2.61
|
£3.13
|
|
|
59 - SILENCER
BSD-3600002002.A28
3600002002
|
£3.72
|
£4.47
|
|
|
60 - STRAINER
BSD-3600002001.A148
3600002001
|
£2.61
|
£3.13
|
|
|
62 - SUSPENSION LOOP
BSD-3604720004.A8
3604720004
|
£2.94
|
£3.53
|
|
|
63 - NEEDLE ROLLER
BSD-3603201024.A10
3603201024
|
-
|
|
|
|
66 - STRAIGHT PIN
BSD-3603201009.A50
3603201009
|
£5.58
|
£6.70
|
|
|
68 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A274
1903230013
|
£2.27
|
£2.72
|
|
|
69 - COMPRESSION SPRING
BSD-3604611006.A61
3604611006
|
£2.27
|
£2.72
|
|
|
71 - CONTROL PISTON
BSD-3608750001.A8
3608750001
|
-
|
|
|
|
72 - COILED SPRING PIN DIN 7343-1.5x10
BSD-2917800016.A89
2917800016
|
£1.75
|
£2.10
|
|
|
74 - COMPRESSION SPRING
BSD-3604611007.A41
3604611007
|
£2.16
|
£2.59
|
|
|
76 - THREADED RING
BSD-3603344003.A82
3603344003
|
£2.61
|
£3.13
|
|
|
77 - CONTROL LEVER
BSD-3601902001.A31
3601902001
|
£6.52
|
£7.83
|
|
|
78 - GROOVED PIN DIN 1475-2x18-ST
BSD-2917700040.A103
2917700040
|
£2.80
|
£3.36
|
|
|
86 - COUNTERSUNK-HEAD SCREW M 4x10 DIN 963-4.8
BSD-2910762120.A19
2910762120
|
£1.75
|
£2.10
|
|
|
87 - SEALING PLATE
BSD-3600054001.A13
3600054001
|
£1.75
|
£2.10
|
|
|
88 - SILENCER
BSD-3601010003.A16
3601010003
|
-
|
|
|
|
89 - SILENCER
BSD-3601010010.A78
3601010010
|
£2.16
|
£2.59
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A600
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A419
1601110481
|
£2.27
|
£2.72
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A404
3601119236
|
£3.91
|
£4.69
|
|
|
100 - HOUSING
BSD-3605125011.A7
3605125011
|
£50.80
|
£60.96
|
|
|
101 - CLUTCH ELEMENT
BSD-3606432006.A45
3606432006
|
£85.90
|
£103.08
|
|
|
102 - DRIVE SHAFT
BSD-3606122009.A10
3606122009
|
£81.81
|
£98.17
|
|
|
106 - COMPRESSION SPRING
BSD-3604615000.A42
3604615000
|
£1.84
|
£2.21
|
|
|
109 - COMPRESSION SPRING
BSD-3604619003.A88
3604619003
|
£5.58
|
£6.70
|
|
|
110 - RETAINING RING
BSD-3604601002.A34
3604601002
|
£1.84
|
£2.21
|
|
|
113 - UNION NUT
BSD-3603340000.A72
3603340000
|
£4.26
|
£5.11
|
|
|
114 - BUSHING
BSD-3600322002.A25
3600322002
|
£5.30
|
£6.36
|
|
|
115 - SEALING PLATE
BSD-3600001002.A24
3600001002
|
£3.72
|
£4.47
|
|
|
116 - ADJUSTING DISC
BSD-3600134003.A53
3600134003
|
£2.74
|
£3.29
|
|
|
119 - SUPPORT DISC
BSD-3600114002.A34
3600114002
|
£12.04
|
£14.45
|
|
|
120 - ROUND NUT
BSD-3603344009.A25
3603344009
|
£28.59
|
£34.31
|
|
|
124 - COUPLING PLATE
BSD-3600220000.A9
3600220000
|
£10.10
|
£12.12
|
|
|
126 - LEAF SPRING
BSD-2601250001.A142
2601250001
|
£3.72
|
£4.47
|
|
|
127 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A803
1903230007
|
£1.84
|
£2.21
|
|
|
128 - BALL DIN 5401-5 G28
BSD-1903230009.A915
1903230009
|
£1.84
|
£2.21
|
|
|
129 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A18
1903230003
|
£2.74
|
£3.29
|
|
|
130 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A19
1903230003
|
£2.74
|
£3.29
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A250
2916600008
|
£2.80
|
£3.36
|
|
|
651 - GUIDE SLEEVE
BSD-3600329000.A70
3600329000
|
£7.72
|
£9.27
|
|
|
652 - HOSE FITTING
BSD-3603386002.A139
3603386002
|
£3.34
|
£4.01
|
|
|
653 - ANGLE PIECE
BSD-3601329007.A109
3601329007
|
£4.48
|
£5.37
|
|
|
701 - GUIDE SLEEVE
BSD-3600328003.A49
3600328003
|
-
|
|
|
|
703 - HEX NUT
BSD-3603458003.A25
3603458003
|
£4.48
|
£5.37
|
|
|
704 - HOSE FITTING
BSD-3607010011.A21
3607010011
|
-
|
|
|
|
705 - HANDLE
BSD-3600499001.A2
3600499001
|
£33.22
|
£39.87
|
|
|
706 - COMPRESSION SPRING
BSD-3604618003.A121
3604618003
|
£7.72
|
£9.27
|
|
|
707 - OFFSET SCREWDRIVER DIN 911 SW10
BSD-1907950009.A181
1907950009
|
£22.76
|
£27.31
|
|
|
712 - HEXAGON-SOCKET KEY
BSD-3607950001.A101
3607950001
|
£2.80
|
£3.36
|
|
|
801 - OVERRIDING CLUTCH
BSD-3607031118.A2
3607031118
|
£264.25
|
£317.10
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031047.A1
3607031047
|
£243.45
|
£292.14
|
|
|
804 - PARTS SET
BSD-3607030256.A78
3607030256
|
£31.95
|
£38.34
|
|
|
882 - O-RING
BSD-3607010006.A31
3607010006
|
£33.22
|
£39.87
|
|
