1 - MOTOR HOUSING
BSD-3605108091.A22
3605108091
|
£35.42
|
£42.51
|
|
|
3/50 - FAN
BSD-1606610122.A148
1606610122
|
£2.94
|
£3.53
|
|
|
4 - SWITCH
BSD-1607200079.A6
1607200079
|
£35.42
|
£42.51
|
|
|
4/10 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x6-5.8
BSD-2910011082.A13
2910011082
|
£1.75
|
£2.10
|
|
|
5 - POWER SUPPLY CORD USA/CDN 2.15m 2 x 2.08mm SJ 14/2
BSD-1604460092.A0
1604460092
|
£19.91
|
£23.89
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A487
3600703011
|
£2.94
|
£3.53
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A236
1601302014
|
£2.74
|
£3.29
|
|
|
9 - STICKER
BSD-2610906965.A0
2610906965
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1412
2600905032
|
£5.57
|
£6.68
|
|
|
14 - GROOVE BALL BEARING 9x26x8
BSD-3600905131.A69
3600905131
|
£11.87
|
£14.24
|
|
|
20 - STRAIGHT PIN DIN 7-5H8x14
BSD-2917500119.A9
2917500119
|
£1.75
|
£2.10
|
|
|
21 - SPINDLE BEARING
BSD-3605806222.A3
3605806222
|
£66.68
|
£80.01
|
|
|
27 - COUPLING HALF
BSD-1606455054.A15
1606455054
|
£205.02
|
£246.03
|
|
|
28 - SPACER RING
BSD-3600202019.A6
3600202019
|
£23.86
|
£28.63
|
|
|
29 - STRIKER
BSD-1608710028.A3
1608710028
|
£251.67
|
£302.00
|
|
|
30 - DRIVE SHAFT
BSD-1603124106.A6
1603124106
|
£142.02
|
£170.42
|
|
|
31 - BACKUP RING
BSD-3600220019.A2
3600220019
|
£102.57
|
£123.08
|
|
|
32 - AIR-DEFLECTOR RING
BSD-1600502019.A8
1600502019
|
£3.72
|
£4.47
|
|
|
33 - INTERMEDIATE RING
BSD-3600300042.A7
3600300042
|
£10.61
|
£12.73
|
|
|
35 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A17
1600910018
|
£5.57
|
£6.68
|
|
|
36 - GROOVE BALL BEARING 17x40x12
BSD-1900905281.A74
1900905281
|
£33.22
|
£39.87
|
|
|
37 - BALL DIN 5401-9 MM III-ST
BSD-1903230015.A24
1903230015
|
£2.74
|
£3.29
|
|
|
38 - BALL DIN 5401-5 G28
BSD-1903230009.A463
1903230009
|
£1.84
|
£2.21
|
|
|
39 - SPRING RETAINING RING
BSD-1600119004.A111
1600119004
|
£2.94
|
£3.53
|
|
|
40 - SPRING WASHER dia32.3xdia43.5x0.6 MM
BSD-1600150009.A60
1600150009
|
£2.80
|
£3.36
|
|
|
41 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A88
2916650006
|
£1.75
|
£2.10
|
|
|
42 - PARALLEL KEY DIN 6885-A6X4X14
BSD-1902300083.A8
1902300083
|
£1.84
|
£2.21
|
|
|
43 - CYLINDRICAL GEAR Z=25
BSD-3606301006.A5
3606301006
|
£63.50
|
£76.20
|
|
|
45 - SHIM 0.5 MM
BSD-1600100617.A23
1600100617
|
£1.75
|
£2.10
|
|
|
46 - O-RING 35.0x3.0 MM
BSD-3600210131.A34
3600210131
|
£3.91
|
£4.69
|
|
|
47 - O-RING 66.0x3.0 MM
BSD-1600210005.A2
1600210005
|
£2.80
|
£3.36
|
|
|
48 - RUBBER RING
BSD-1600206022.A15
1600206022
|
£2.16
|
£2.59
|
|
|
49 - BEARING COVER
BSD-3605500043.A18
3605500043
|
£4.48
|
£5.37
|
|
|
50 - INTERMEDIATE RING
BSD-1600502011.A559
1600502011
|
£2.74
|
£3.29
|
|
|
51 - COMPRESSION SPRING
BSD-1604613006.A3
1604613006
|
£1.75
|
£2.10
|
|
|
52 - COMPRESSION SPRING
BSD-3604610059.A3
3604610059
|
£22.60
|
£27.12
|
|
|
53 - SPIRAL SPRING
BSD-160465202C.A9
160465202C
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A206
2910021118
|
£1.84
|
£2.21
|
|
|
55 - INSULATING STRIP
BSD-3602317025.A10
3602317025
|
£2.61
|
£3.13
|
|
|
56 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A323
2910211019
|
£1.84
|
£2.21
|
|
|
59 - LENS HEAD SCREW
BSD-3603435040.A10
3603435040
|
£1.75
|
£2.10
|
|
|
60 - HEX SOCKET HEAD CAP SCREW DIN 912-BM 5x40-10.9
BSD-2910151170.A14
2910151170
|
£1.84
|
£2.21
|
|
|
61 - LENS HEAD SCREW
BSD-3603435041.A10
3603435041
|
£1.75
|
£2.10
|
|
|
62 - TAPPING SCREW 5x30
BSD-3603435027.A43
3603435027
|
£1.84
|
£2.21
|
|
|
64 - PLAIN WASHER DIN 7603-A4x8
BSD-3600120013.A5
3600120013
|
£1.84
|
£2.21
|
|
|
65 - SHIM WASHER 0.4 MM
BSD-1600101600.A55
1600101600
|
£1.84
|
£2.21
|
|
|
66 - STICKER
BSD-2610906868.A0
2610906868
|
£3.91
|
£4.69
|
|
|
67 - SHRINKABLE TUBE
BSD-1600712027.A12
1600712027
|
£1.75
|
£2.10
|
|
|
69 - CONNECTING CABLE L=470 MM
BSD-3604438025.A36
3604438025
|
£7.36
|
£8.83
|
|
|
70 - CONNECTING CABLE L=330 MM
BSD-1604438012.A65
1604438012
|
£7.36
|
£8.83
|
|
|
71 - CONNECTING CABLE L=330 MM
BSD-3604460135.A4
3604460135
|
£8.67
|
£10.41
|
|
|
72 - CONNECTING CABLE L=160 MM
BSD-3604438008.A5
3604438008
|
£9.11
|
£10.93
|
|
|
73 - CONNECTING CABLE L=330 MM
BSD-3604460011.A1
3604460011
|
£2.94
|
£3.53
|
|
|
74 - CONNECTING CABLE L=200 MM
BSD-3604460012.A0
3604460012
|
£2.94
|
£3.53
|
|
|
75 - WIRE GUIDE
BSD-3601025003.A54
3601025003
|
£1.75
|
£2.10
|
|
|
76 - TORX OVAL-HEAD SCREW
BSD-2914201527.A66
2914201527
|
£2.27
|
£2.72
|
|
|
77 - SEALING CAP
BSD-3605500062.A7
3605500062
|
£13.12
|
£15.75
|
|
|
78 - SUSPENSION LOOP
BSD-3601310013.A2
3601310013
|
£21.68
|
£26.01
|
|
|
79 - HEX SOCKET HEAD CAP SCREW
BSD-2910131193.A5
2910131193
|
£1.75
|
£2.10
|
|
|
80 - TORX OVAL-HEAD SCREW
BSD-2914201508.A49
2914201508
|
£1.84
|
£2.21
|
|
|
81 - SHRINKABLE TUBE
BSD-3600707022.A104
3600707022
|
£3.72
|
£4.47
|
|
|
88 - SOCKET HEAD CAP SCREW
BSD-3603435045.A4
3603435045
|
£1.75
|
£2.10
|
|
|
89 - SEAL
BSD-3601023010.A2
3601023010
|
£6.85
|
£8.22
|
|
|
90 - TAB WASHER
BSD-1601030022.A377
1601030022
|
£1.84
|
£2.21
|
|
|
301/63 - CONNECTING CABLE L=60 MM
BSD-3604412002.A16
3604412002
|
£7.36
|
£8.83
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A1440
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1341
1602025030
|
£19.91
|
£23.89
|
|
|
700 - SPRING PULL 8-10 KG
BSD-0607950926.A2
0607950926
|
-
|
|
|
|
712 - BALL JOINT 1. 100 MM
BSD-1608500009.A4
1608500009
|
-
|
|
|
|
751 - THREADED FITTING M14. L=70 MM
BSD-1603527017.A3
1603527017
|
-
|
|
|
|
802 - FIELD 100-115V
BSD-3604220139.A1
3604220139
|
£75.79
|
£90.95
|
|
|
803 - ARMATURE 110-115V
BSD-3604010072.A0
3604010072
|
£156.22
|
£187.46
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3996
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-3607014012.A85
3607014012
|
£25.05
|
£30.06
|
|
|
816 - BRUSH HOLDER
BSD-3604336012.A103
3604336012
|
£5.58
|
£6.70
|
|
|
822 - GEAR HOUSING
BSD-3607031648.A4
3607031648
|
£120.11
|
£144.13
|
|
|
823 - INTERMEDIATE FLANGE
BSD-3605806168.A3
3605806168
|
£72.18
|
£86.62
|
|
|
824 - HANDLE
BSD-3605132061.A0
3605132061
|
£25.05
|
£30.06
|
|
|
825 - SEALING CAP
BSD-3605500063.A174
3605500063
|
£4.48
|
£5.37
|
|
|
826 - SWITCH
BSD-3607200025.A3
3607200025
|
£28.59
|
£34.31
|
|
|
834 - ROTARY SHAFT LIP SEAL
BSD-3600290070.A37
3600290070
|
£12.64
|
£15.17
|
|
|
844 - GEAR SHAFT
BSD-1607000C6N.A7
1607000C6N
|
£81.81
|
£98.17
|
|
|
860 - HEX SOCKET HEAD CAP SCREW
BSD-3603414028.A53
3603414028
|
£1.84
|
£2.21
|
|
|
869 - CONNECTING CABLE L=450 MM
BSD-3604460009.A36
3604460009
|
£6.52
|
£7.83
|
|
|
871 - CONNECTING CABLE L=345 MM
BSD-1604438013.A9
1604438013
|
£7.72
|
£9.27
|
|
|
875 - WIRE GUIDE
BSD-1601025001.A97
1601025001
|
£1.75
|
£2.10
|
|
