1 - MOTOR HOUSING
BSD-3600760045.A0
3600760045
|
-
|
|
|
|
2 - STATOR 120W
BSD-3604090017.A19
3604090017
|
£85.90
|
£103.08
|
|
|
3 - ROTOR
BSD-3604220013.A9
3604220013
|
£102.57
|
£123.08
|
|
|
5 - BEARING FLANGE
BSD-3605700023.A10
3605700023
|
£23.86
|
£28.63
|
|
|
6 - BALL BEARING 7x19x6
BSD-2600905032.A1285
2600905032
|
£5.57
|
£6.68
|
|
|
7 - BEARING FLANGE
BSD-3605700022.A12
3605700022
|
£72.18
|
£86.62
|
|
|
8 - GROOVE BALL BEARING 7x14x5
BSD-1900905030.A9
1900905030
|
£33.74
|
£40.49
|
|
|
11 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A216
2916011011
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A178
2911061150
|
£2.61
|
£3.13
|
|
|
26 - CARRIER
BSD-3603050007.A0
3603050007
|
-
|
|
|
|
27 - DISC SPRING DIN 2093-B25-GR 1
BSD-2916160059.A1
2916160059
|
-
|
|
|
|
46 - THREADED RING
BSD-3603463008.A0
3603463008
|
-
|
|
|
|
47 - CONNECTING FLANGE
BSD-3600390017.A0
3600390017
|
-
|
|
|
|
48 - SEAL RING
BSD-3600283031.A0
3600283031
|
-
|
|
|
|
54 - COMPRESSION SPRING
BSD-3604611017.A26
3604611017
|
£2.61
|
£3.13
|
|
|
56 - VALVE HOUSING
BSD-3605190138.A3
3605190138
|
£218.41
|
£262.09
|
|
|
59 - SILENCER
BSD-3607000020.A1
3607000020
|
£10.10
|
£12.12
|
|
|
60 - FITTING
BSD-3603373008.A3
3603373008
|
£21.52
|
£25.83
|
|
|
61 - MEMBRANE
BSD-3600106000.A0
3600106000
|
£1.75
|
£2.10
|
|
|
63 - NEEDLE ROLLER
BSD-1903201024.A0
1903201024
|
£1.75
|
£2.10
|
|
|
64 - PLAIN WASHER DIN 125-A3.2-ST
BSD-2916011006.A14
2916011006
|
£1.75
|
£2.10
|
|
|
65 - O-RING 2.4x1.9 MM
BSD-2600210007.A80
2600210007
|
£2.27
|
£2.72
|
|
|
66 - STRAIGHT PIN
BSD-3603201001.A41
3603201001
|
£4.26
|
£5.11
|
|
|
68 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A38
1903230013
|
£2.16
|
£2.59
|
|
|
69 - COMPRESSION SPRING
BSD-3604611006.A19
3604611006
|
£2.16
|
£2.59
|
|
|
70 - STRAINER
BSD-3600002001.A34
3600002001
|
£2.61
|
£3.13
|
|
|
76 - THREADED RING
BSD-3603344003.A10
3603344003
|
£2.61
|
£3.13
|
|
|
77 - CONTROL LEVER
BSD-3601902001.A103
3601902001
|
£6.52
|
£7.83
|
|
|
78 - GROOVED PIN DIN 1475-2x18-ST
BSD-2917700040.A63
2917700040
|
£2.80
|
£3.36
|
|
|
82 - O-RING 20.0x1.0 MM
BSD-3600210012.A44
3600210012
|
£2.94
|
£3.53
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1855
3601119236
|
£3.91
|
£4.69
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030259.A39
3607030259
|
£31.64
|
£37.97
|
|
|
846 - ASSEMBLY OF SERVICE PARTS
BSD-3607031198.A0
3607031198
|
-
|
|
|
|
859 - HOLDING BELT
BSD-3604710062.A5
3604710062
|
£1.84
|
£2.21
|
|
|
899 - AIR HOSE
BSD-3607000064.A0
3607000064
|
£27.23
|
£32.68
|
|
