Bosch ---- / 1608580010 / --- Spare Parts

An exploded drawing and listing for the Bosch ---- / 1608580010 / ---

	Ex VAT	Inc VAT
1 - GEAR HOUSING BSD-1605806230.A0 1605806230	-
2 - BALL BSD-1900920001.A0 1900920001	-
3 - THREADED RING BSD-1606100003.A0 1606100003	-
4 - BALL DIN 5401-5.5MM-III-ST BSD-1903230010.A269 1903230010	£1.75	£2.10
5 - ADAPTOR PLATE 0.05 MM BSD-1600102612.A0 1600102612	-
5 - SHIM 0.10 MM BSD-1600102613.A2 1600102613	-
5 - ADAPTOR PLATE 0.2 MM BSD-1600102614.A0 1600102614	-
6 - SHIM BSD-1605808031.A0 1605808031	-
7 - SPRING RETAINING RING BSD-1606333047.A0 1606333047	-
8 - SOCKET HEAD CAP SCREW BSD-1603344014.A0 1603344014	-
9 - HEX SCREW BSD-1900900204.A0 1900900204	-
10 - MANUFACTURER'S NAMEPLATE BSD-1600200007.A0 1600200007	-
11 - LUBRIC. HEAD DIN 3404-6-AM BSD-1907401000.A0 1907401000	-
12 - THREADED SPINDLE BSD-1601315008.A0 1601315008	-
14 - SHIM 0.05 MM BSD-1600102638.A0 1600102638	£3.34	£4.01
14 - SHIM 0.1 MM BSD-1600102639.A234 1600102639	-
14 - SHIM 0.15 MM BSD-1600102640.A0 1600102640	-
15 - BEVEL GEAR BSD-1600108001.A0 1600108001	-
16 - DRIVE SHAFT BSD-1603212001.A0 1603212001	-
17 - SHIM 0.05 MM BSD-1200101605.A0 1200101605	-
17 - SHIM 0.10 MM BSD-1200101606.A0 1200101606	-
17 - SHIM 0.30 MM BSD-1200101607.A0 1200101607	-
17 - SHIM 0.20 MM BSD-1200101608.A0 1200101608	-
18 - SPACER RING BSD-1600211004.A0 1600211004	-
19 - FELT DISC BSD-1603212002.A0 1603212002	-

Attribute Name	Value
Brand	Bosch
