2 - SEAL RING
BSD-1600209011.A17
1600209011
|
£2.94
|
£3.53
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600502005.A359
1600502005
|
£2.61
|
£3.13
|
|
|
5 - ROTOR
BSD-3604080020.A16
3604080020
|
-
|
|
|
|
5/3 - FAN
BSD-1606610105.A10
1606610105
|
£15.65
|
£18.78
|
|
|
6 - GROOVE BALL BEARING 5x16x5
BSD-1900900232.A168
1900900232
|
£16.74
|
£20.09
|
|
|
7/1 - RUBBER RING 6MM.dia12xdia16.4x3MM
BSD-3600206002.A26
3600206002
|
-
|
|
|
|
8 - BALL BEARING 7x22x7
BSD-1900905018.A1010
1900905018
|
£19.91
|
£23.89
|
|
|
9 - BEARING HOUSING
BSD-1605820196.A17
1605820196
|
£161.73
|
£194.08
|
|
|
11 - HANDLE
BSD-3605132044.A19
3605132044
|
-
|
|
|
|
12 - CABLE
BSD-1604421020.A2
1604421020
|
-
|
|
|
|
13 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1185
3600703011
|
£2.94
|
£3.53
|
|
|
14 - FASTENING CLAMP
BSD-1601302014.A783
1601302014
|
£2.74
|
£3.29
|
|
|
15 - CONNECTION HOUSING
BSD-3600099005.A24
3600099005
|
£16.41
|
£19.69
|
|
|
16 - REVERSING SWITCH
BSD-1607200043.A19
1607200043
|
-
|
|
|
|
17 - SWITCH
BSD-1607200038.A63
1607200038
|
£57.14
|
£68.57
|
|
|
18 - PRESSURE SPINDLE
BSD-1603203024.A13
1603203024
|
-
|
|
|
|
19 - SEALING CAP
BSD-3605500071.A38
3605500071
|
£17.22
|
£20.67
|
|
|
21 - CYLINDRICAL GEAR Z=43
BSD-1606325021.A26
1606325021
|
-
|
|
|
|
22 - SPINDLE WITH GEAR Z=11
BSD-1606308017.A9
1606308017
|
-
|
|
|
|
23 - CARRIER
BSD-3606445022.A17
3606445022
|
-
|
|
|
|
24 - CARRIER
BSD-1606455063.A5
1606455063
|
-
|
|
|
|
25 - TAPER RING
BSD-1600250000.A27
1600250000
|
-
|
|
|
|
26 - THREADED BUSHING
BSD-3600364010.A24
3600364010
|
-
|
|
|
|
27 - CYLINDRICAL GEAR Z=5
BSD-2606319050.A16
2606319050
|
-
|
|
|
|
28 - COMPRESSION SPRING
BSD-1604619015.A28
1604619015
|
£5.01
|
£6.01
|
|
|
29 - ROLLER
BSD-1603200019.A31
1603200019
|
-
|
|
|
|
30 - RETAINING SNAP RING
BSD-2600209018.A22
2600209018
|
-
|
|
|
|
31 - HOLDING SPRING
BSD-3604682003.A80
3604682003
|
-
|
|
|
|
32 - COMPRESSION SPRING
BSD-1604612005.A23
1604612005
|
-
|
|
|
|
36 - SHIM 0.50 MM
BSD-2600100613.A220
2600100613
|
£1.75
|
£2.10
|
|
|
39 - NAMEPLATE
BSD-3601106053.A288
3601106053
|
£5.57
|
£6.68
|
|
|
40 - GROOVED NAIL
BSD-3603133000.A121
3603133000
|
£2.61
|
£3.13
|
|
|
41 - SPRING WASHER DIN 137-A5-FST
BSD-2916060006.A83
2916060006
|
£1.38
|
£1.66
|
|
|
42 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A277
2916060003
|
£1.32
|
£1.58
|
|
|
43 - CLAMPING SADDLE
BSD-3601321001.A616
3601321001
|
£3.72
|
£4.47
|
|
|
44 - SPRING WASHER dia4.2 MM
BSD-3600150006.A614
3600150006
|
£2.74
|
£3.29
|
|
|
45 - PAN HEAD SCREW DIN 85-AM4x8-MS
BSD-2910110118.A210
2910110118
|
£1.84
|
£2.21
|
|
|
46 - PAN HEAD SCREW DIN 85-AM3x5-4.8
BSD-2910091047.A2
2910091047
|
£1.84
|
£2.21
|
|
|
47 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A42
2910021116
|
£2.27
|
£2.72
|
|
|
48 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A750
2910021122
|
£2.27
|
£2.72
|
|
|
50 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x22-8.8
BSD-2910141131.A30
2910141131
|
£2.16
|
£2.59
|
|
|
51 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A139
2910141140
|
£1.75
|
£2.10
|
|
|
53 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A125
2910011162
|
£1.84
|
£2.21
|
|
|
54 - BALL DIN 5401-8 MM III-ST
BSD-1903230014.A145
1903230014
|
£1.75
|
£2.10
|
|
|
55 - BALL DIN 5401-6 G28
BSD-1903230011.A62
1903230011
|
£2.74
|
£3.29
|
|
|
56 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A500
1903230006
|
£2.27
|
£2.72
|
|
|
60 - RETAINING RING 10 DIN 9045
BSD-2916600006.A57
2916600006
|
£1.84
|
£2.21
|
|
|
62 - CONTROL SHAFT
BSD-1603124099.A7
1603124099
|
-
|
|
|
|
63 - GUIDE BUSHING
BSD-1600521018.A10
1600521018
|
-
|
|
|
|
64 - COMPRESSION SPRING
BSD-1604616019.A27
1604616019
|
-
|
|
|
|
66 - SET SCREW
BSD-3603402000.A197
3603402000
|
£1.84
|
£2.21
|
|
|
67 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A499
1903230006
|
£2.27
|
£2.72
|
|
|
69 - BUSHING
BSD-2600300058.A87
2600300058
|
-
|
|
|
|
70 - CLAMP BUSHING
BSD-1600300081.A11
1600300081
|
-
|
|
|
|
71 - RETAINING WASHER
BSD-3600190012.A38
3600190012
|
-
|
|
|
|
72 - COUNTERSUNK-HEAD SCREW DIN 963-M3x8-8.8
BSD-2910780050.A85
2910780050
|
-
|
|
|
|
73 - O-RING 8.0x1.0 MM
BSD-1600210045.A189
1600210045
|
£1.84
|
£2.21
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1597
3601119236
|
£3.91
|
£4.69
|
|
|
650 - SLOTTED SCREWDRIVER
BSD-1607950037.A44
1607950037
|
£51.22
|
£61.47
|
|
|
800/01 - MOTOR HOUSING
BSD-3605102026.A1
3605102026
|
-
|
|
|
|
801 - GEAR HOUSING
BSD-3605806013.A8
3605806013
|
-
|
|
|
|
802 - CARRIER
BSD-3606445017.A14
3606445017
|
-
|
|
|
|
804 - SPINDLE WITH GEAR Z=11/34
BSD-1606328102.A8
1606328102
|
-
|
|
|
|
809 - BEARING HOUSING
BSD-1605820196.A19
1605820196
|
£161.73
|
£194.08
|
|
|
810 - STATOR 42V/300HZ
BSD-1604229205.A6
1604229205
|
-
|
|
|
