1 - MOTOR HOUSING
BSD-3605102044.A4
3605102044
|
£218.41
|
£262.09
|
|
|
2 - STATOR 265V/200HZ. 200V/150HZ
BSD-1604229200.A1
1604229200
|
£481.43
|
£577.72
|
|
|
3 - ROTOR WITHOUT WINDING
BSD-3604080015.A5
3604080015
|
-
|
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600502005.A171
1600502005
|
£2.61
|
£3.13
|
|
|
5 - INTERMEDIATE BEARING
BSD-3605700099.A8
3605700099
|
-
|
|
|
|
6 - GROOVE BALL BEARING 9x24x7
BSD-1900905017.A88
1900905017
|
£23.86
|
£28.63
|
|
|
8 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A190
1900905015
|
£30.42
|
£36.51
|
|
|
9 - CLAMPING SADDLE
BSD-3601321001.A403
3601321001
|
£3.72
|
£4.47
|
|
|
10 - SPRING WASHER dia4.2 MM
BSD-3600150006.A651
3600150006
|
£2.74
|
£3.29
|
|
|
11 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A37
2910110120
|
£1.84
|
£2.21
|
|
|
12 - SET SCREW
BSD-3603402000.A75
3603402000
|
£1.75
|
£2.10
|
|
|
14 - RUBBER RING 6MM.dia12xdia16.4x3MM
BSD-3600206002.A4
3600206002
|
-
|
|
|
|
15 - SOCKET HEAD CAP SCREW DIN 84-AM4x16-8.8
BSD-2910021126.A71
2910021126
|
£1.84
|
£2.21
|
|
|
16 - O-RING 53.0x2.0 MM
BSD-3600210017.A68
3600210017
|
£3.72
|
£4.47
|
|
|
56 - SWITCH
BSD-3607200041.A30
3607200041
|
-
|
|
|
|
58 - HANDLE
BSD-3605132041.A5
3605132041
|
£23.86
|
£28.63
|
|
|
59 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A785
3600703011
|
£2.94
|
£3.53
|
|
|
60 - HELICAL CONDUCTOR
BSD-3604462005.A4
3604462005
|
-
|
|
|
|
60 - PVC-INSULATED CABLE
BSD-3604412000.A11
3604412000
|
-
|
|
|
|
61 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A152
2910211020
|
£2.16
|
£2.59
|
|
|
62 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A309
2910021116
|
£2.27
|
£2.72
|
|
|
63 - FASTENING CLAMP
BSD-1601302014.A1077
1601302014
|
£2.74
|
£3.29
|
|
|
65 - SWITCH
BSD-3607200000.A27
3607200000
|
£21.52
|
£25.83
|
|
|
67 - END SPLICE
BSD-3604477008.A75
3604477008
|
£1.75
|
£2.10
|
|
|
73 - SERRATED LOCK-WASHER A 4.3 DIN 6798-ST
BSD-2916070006.A25
2916070006
|
£1.75
|
£2.10
|
|
|
76 - CONNECTOR PLUG
BSD-3604484003.A9
3604484003
|
-
|
|
|
|
95 - NAMEPLATE
BSD-3601106053.A385
3601106053
|
£5.57
|
£6.68
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110483.A81
1601110483
|
£2.74
|
£3.29
|
|
|
98 - STICKER
BSD-3601103012.A25
3601103012
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1059
3601119236
|
£3.91
|
£4.69
|
|
|
214 - CYLINDRICAL GEAR Z=12
BSD-3606316098.A6
3606316098
|
£27.23
|
£32.68
|
|
|
215 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A286
3600913000
|
£4.26
|
£5.11
|
|
|
226 - PINION Z=23
BSD-3606300002.A6
3606300002
|
£25.05
|
£30.06
|
|
|
227 - STOP DISC
BSD-3600101001.A43
3600101001
|
£2.61
|
£3.13
|
|
|
228 - RING GEAR Z=40
BSD-3606334043.A0
3606334043
|
£218.41
|
£262.09
|
|
|
229 - PLANETARY-GEAR CARRIER
BSD-3606337071.A5
3606337071
|
-
|
|
|
|
230 - CYLINDRICAL GEAR Z=16
BSD-3606316099.A106
3606316099
|
£22.76
|
£27.31
|
|
|
231 - FRICTION WASHER
BSD-3600113010.A8
3600113010
|
£2.94
|
£3.53
|
|
|
233 - NEEDLE ROLLER
BSD-3603201000.A144
3603201000
|
£1.84
|
£2.21
|
|
|
234 - NEEDLE ROLLER
BSD-3603201044.A5
3603201044
|
£1.75
|
£2.10
|
|
|
236 - GROOVE BALL BEARING
BSD-3600900016.A24
3600900016
|
-
|
|
|
|
238 - PLANETARY-GEAR CARRIER
BSD-3606337085.A1
3606337085
|
-
|
|
|
|
241 - GROOVE BALL BEARING
BSD-3600900017.A1
3600900017
|
-
|
|
|
|
245 - PLANETARY-GEAR CARRIER
BSD-3606337083.A0
3606337083
|
-
|
|
|
|
248 - CYLINDRICAL GEAR Z=13
BSD-3606316070.A6
3606316070
|
-
|
|
|
|
249 - NEEDLE ROLLER
BSD-3603201053.A11
3603201053
|
£1.84
|
£2.21
|
|
|
250 - STOP DISC
BSD-3600100036.A7
3600100036
|
-
|
|
|
|
253 - FRICTION WASHER
BSD-3600101024.A30
3600101024
|
£7.36
|
£8.83
|
|
|
339 - SPINDLE HOUSING
BSD-3608873773.A1
3608873773
|
£500.46
|
£600.55
|
|
|
340 - SUPPORT DISC
BSD-3600103004.A39
3600103004
|
£13.12
|
£15.75
|
|
|
341 - UNION NUT
BSD-3603340016.A3
3603340016
|
-
|
|
|
|
342 - RETAINING RING
BSD-1600116004.A76
1600116004
|
-
|
|
|
|
343 - SPRING RETAINING RING DIN 472-28x1.2 MM
BSD-2916660011.A35
2916660011
|
£1.75
|
£2.10
|
|
|
344 - SUPPORT DISC 15X28X2.75
BSD-3600150003.A8
3600150003
|
£12.04
|
£14.45
|
|
|
345 - THRUST NEEDLE RIM
BSD-1610913000.A59
1610913000
|
£2.94
|
£3.53
|
|
|
346 - O-RING 30x2.5 MM
BSD-1900210131.A17
1900210131
|
£4.48
|
£5.37
|
|
|
347 - NEEDLE BEARING
BSD-3600917010.A17
3600917010
|
£28.59
|
£34.31
|
|
|
348 - NEEDLE-ROLLER BEARING
BSD-2000910002.A7
2000910002
|
£3.72
|
£4.47
|
|
|
350 - BEVEL GEAR Z=10
BSD-3606100009.A4
3606100009
|
£205.02
|
£246.03
|
|
|
352 - BEARING FLANGE
BSD-3603490002.A1
3603490002
|
£102.57
|
£123.08
|
|
|
353 - O-RING 12.0x1.5 MM
BSD-3600210086.A55
3600210086
|
£2.80
|
£3.36
|
|
|
354 - NEEDLE-ROLLER ASSEMBLY
BSD-3600915002.A4
3600915002
|
£14.91
|
£17.89
|
|
|
356 - THRUST NEEDLE RIM
BSD-1610913000.A60
1610913000
|
£2.94
|
£3.53
|
|
|
357 - NEEDLE BEARING
BSD-2600914004.A9
2600914004
|
£4.26
|
£5.11
|
|
|
358 - NEEDLE ROLLER
BSD-3603201038.A4
3603201038
|
£1.95
|
£2.34
|
|
|
359 - SHIM
BSD-3600102007.A4
3600102007
|
£2.80
|
£3.36
|
|
|
359 - SHIM
BSD-3600102008.A7
3600102008
|
£2.61
|
£3.13
|
|
|
360 - GUIDE SLEEVE
BSD-3600320016.A3
3600320016
|
£14.91
|
£17.89
|
|
|
361 - COMPRESSION SPRING
BSD-1604611004.A57
1604611004
|
£2.80
|
£3.36
|
|
|
362 - PRESSURE SPINDLE
BSD-1603124060.A35
1603124060
|
£5.58
|
£6.70
|
|
|
363 - O-RING 26.0x1.5 MM
BSD-2600210018.A18
2600210018
|
£3.72
|
£4.47
|
|
|
364 - SHIM
BSD-3608870173.A2
3608870173
|
£2.94
|
£3.53
|
|
|
364 - SHIM
BSD-3608870176.A12
3608870176
|
£2.16
|
£2.59
|
|
|
365 - SUPPORTING DISC 1.2 MM
BSD-1610101627.A2
1610101627
|
£1.84
|
£2.21
|
|
|
650 - SUSPENSION LOOP
BSD-2601310002.A10
2601310002
|
£16.41
|
£19.69
|
|
