1 - MOTOR HOUSING
BSD-3605105001.A5
3605105001
|
-
|
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600117000.A4
1600117000
|
-
|
|
|
|
5 - GROMMET dia13.2-dia17.0x120 MM
BSD-1600703002.A4
1600703002
|
£5.26
|
£6.31
|
|
|
6 - ELEC. CABLE W/CONNECTION
BSD-3604462033.A13
3604462033
|
-
|
|
|
|
7 - CLAMP
BSD-1601315011.A0
1601315011
|
-
|
|
|
|
8 - SWITCH
BSD-3607200041.A13
3607200041
|
-
|
|
|
|
9 - SWITCH HOUSING
BSD-3605130030.A11
3605130030
|
-
|
|
|
|
10 - SWITCH
BSD-3607200000.A0
3607200000
|
£21.52
|
£25.83
|
|
|
11 - CABLE
BSD-1604440000.A5
1604440000
|
-
|
|
|
|
12 - PVC-INSULATED CABLE
BSD-1604441000.A12
1604441000
|
-
|
|
|
|
13 - SWITCH COVER
BSD-3605500070.A9
3605500070
|
-
|
|
|
|
14 - SEALING CAP
BSD-3605500075.A12
3605500075
|
-
|
|
|
|
15 - SET SCREW
BSD-1603402004.A239
1603402004
|
£2.61
|
£3.13
|
|
|
17 - ROTOR WITHOUT WINDING
BSD-1604080028.A1
1604080028
|
-
|
|
|
|
17/5 - MAGNETO BALL BEARING E 10 DIN 615
BSD-1900900008.A12
1900900008
|
-
|
|
|
|
17/6 - OIL RETURN RING
BSD-1600313008.A17
1600313008
|
-
|
|
|
|
17/7 - MAGNETO BALL BEARING E 7 DIN 615
BSD-1900900005.A17
1900900005
|
£36.63
|
£43.96
|
|
|
18 - BEARING HOUSING
BSD-3605820049.A0
3605820049
|
-
|
|
|
|
19 - SEALING DISK
BSD-1600108006.A16
1600108006
|
-
|
|
|
|
20 - SHIM 0.5 MM
BSD-1600101633.A12
1600101633
|
£1.84
|
£2.21
|
|
|
21 - SHIM 0.05 MM
BSD-1600102654.A17
1600102654
|
£1.95
|
£2.34
|
|
|
22 - SHIM 0.2 MM
BSD-1600100609.A1
1600100609
|
-
|
|
|
|
23 - MULTIPLATE CLUTCH
BSD-1606401005.A1
1606401005
|
-
|
|
|
|
24 - BEARING FLANGE
BSD-1605820115.A0
1605820115
|
-
|
|
|
|
25 - COUPLING HALF
BSD-1606455043.A0
1606455043
|
-
|
|
|
|
26 - O-RING 22x3 MM
BSD-1900210123.A12
1900210123
|
£4.26
|
£5.11
|
|
|
27 - CONICAL SPRING WASHER
BSD-1600501016.A0
1600501016
|
-
|
|
|
|
28 - CYLINDRICAL GEAR Z=33
BSD-1606317052.A1
1606317052
|
-
|
|
|
|
29 - O-RING 54.0x3.0 MM
BSD-1600210004.A175
1600210004
|
£2.80
|
£3.36
|
|
|
30 - DRIVE SHAFT
BSD-1603123023.A13
1603123023
|
-
|
|
|
|
31 - BUSHING
BSD-1605801018.A18
1605801018
|
£47.95
|
£57.54
|
|
|
32 - COMPRESSION SPRING
BSD-1604619010.A12
1604619010
|
£6.85
|
£8.22
|
|
|
33 - STRIKER
BSD-1608710024.A20
1608710024
|
-
|
|
|
|
34 - PRESSURE SPINDLE
BSD-1603121007.A1
1603121007
|
-
|
|
|
|
35 - COMPRESSION SPRING
BSD-1604610006.A1
1604610006
|
-
|
|
|
|
36 - SPINDLE BEARING
BSD-3605806114.A1
3605806114
|
-
|
|
|
|
37 - SEALING DISK
BSD-1600108051.A1
1600108051
|
-
|
|
|
|
39 - NAMEPLATE
BSD-3601106054.A39
3601106054
|
£5.30
|
£6.36
|
|
|
45 - SOCKET HEAD CAP SCREW DIN 84-AM3x20-8.8
BSD-2910021062.A16
2910021062
|
£1.75
|
£2.10
|
|
|
46 - SOCKET HEAD CAP SCREW DIN 84-AM4x10-5.8
BSD-2910011120.A121
2910011120
|
£1.75
|
£2.10
|
|
|
47 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A251
2910021122
|
£2.27
|
£2.72
|
|
|
48 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x35-8.8
BSD-2910141136.A167
2910141136
|
£2.80
|
£3.36
|
|
|
49 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A174
1602381001
|
-
|
|
|
|
50 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x40-8.8
BSD-2910141170.A89
2910141170
|
£2.61
|
£3.13
|
|
|
51 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A315
2910110120
|
£1.84
|
£2.21
|
|
|
52 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A264
1900900287
|
£21.68
|
£26.01
|
|
|
53 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A877
1903230013
|
£2.27
|
£2.72
|
|
|
54 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A448
1903230007
|
£1.84
|
£2.21
|
|
|
56 - SPRING WASHER dia4.2 MM
BSD-3600150006.A331
3600150006
|
£2.74
|
£3.29
|
|
|
57 - CLAMPING SADDLE
BSD-3601321001.A231
3601321001
|
£3.72
|
£4.47
|
|
|
60 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A879
2916690003
|
£1.75
|
£2.10
|
|
|
61 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A1
3603133001
|
£2.61
|
£3.13
|
|
|
62 - COUPLING HALF 1/2
BSD-3606455033.A1
3606455033
|
-
|
|
|
|
63 - DETENT PIN
BSD-1603124078.A13
1603124078
|
-
|
|
|
|
64 - SET SCREW
BSD-3603402000.A418
3603402000
|
£1.84
|
£2.21
|
|
|
65 - GUIDE SLEEVE
BSD-1600506008.A1
1600506008
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A556
3601119236
|
£3.91
|
£4.69
|
|
|
705 - COUPLING HALF 7/16
BSD-1606455012.A13
1606455012
|
-
|
|
|
|
801 - COUPLING HALF 5/8
BSD-1606455045.A11
1606455045
|
-
|
|
|
