1 - MOTOR HOUSING
BSD-3605105001.A9
3605105001
|
-
|
|
|
|
2 - STATOR 200V/150. 265V/200HZ
BSD-3604229049.A3
3604229049
|
-
|
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600117000.A7
1600117000
|
-
|
|
|
|
5 - GROMMET dia13.2-dia17.0x120 MM
BSD-1600703002.A14
1600703002
|
£5.26
|
£6.31
|
|
|
6 - ELEC. CABLE W/CONNECTION
BSD-3604462033.A11
3604462033
|
-
|
|
|
|
7 - CLAMP
BSD-1601315011.A2
1601315011
|
-
|
|
|
|
8 - SWITCH
BSD-3607200041.A3
3607200041
|
-
|
|
|
|
9/2 - SWITCH HOUSING
BSD-1605130014.A0
1605130014
|
-
|
|
|
|
10 - SWITCH
BSD-3607200000.A19
3607200000
|
£21.52
|
£25.83
|
|
|
11 - CABLE
BSD-1604440000.A9
1604440000
|
-
|
|
|
|
12 - PVC-INSULATED CABLE
BSD-1604441000.A8
1604441000
|
-
|
|
|
|
13/1 - SEALING CAP
BSD-1605500039.A3
1605500039
|
-
|
|
|
|
14 - SEALING CAP
BSD-3605500075.A9
3605500075
|
-
|
|
|
|
15 - SET SCREW
BSD-1603402004.A186
1603402004
|
£2.61
|
£3.13
|
|
|
17 - ROTOR WITHOUT WINDING
BSD-1604080028.A2
1604080028
|
-
|
|
|
|
17/5 - MAGNETO BALL BEARING E 10 DIN 615
BSD-1900900008.A8
1900900008
|
-
|
|
|
|
17/6 - OIL RETURN RING
BSD-1600313008.A8
1600313008
|
-
|
|
|
|
17/7 - MAGNETO BALL BEARING E 7 DIN 615
BSD-1900900005.A31
1900900005
|
£36.63
|
£43.96
|
|
|
18 - BEARING HOUSING
BSD-3605820049.A3
3605820049
|
-
|
|
|
|
19 - SEALING DISK
BSD-1600108006.A8
1600108006
|
-
|
|
|
|
20 - SHIM 0.5 MM
BSD-1600101633.A0
1600101633
|
£1.84
|
£2.21
|
|
|
21 - SHIM 0.05 MM
BSD-1600102654.A5
1600102654
|
£1.95
|
£2.34
|
|
|
22 - SHIM 0.2 MM
BSD-1600100609.A15
1600100609
|
-
|
|
|
|
23 - MULTIPLATE CLUTCH
BSD-1606401003.A7
1606401003
|
-
|
|
|
|
24 - BEARING FLANGE
BSD-1605820115.A2
1605820115
|
-
|
|
|
|
25 - COUPLING HALF
BSD-1606455043.A5
1606455043
|
-
|
|
|
|
26 - O-RING 22x3 MM
BSD-1900210123.A8
1900210123
|
£4.26
|
£5.11
|
|
|
27 - CONICAL SPRING WASHER
BSD-1600501016.A3
1600501016
|
-
|
|
|
|
28 - CYLINDRICAL GEAR Z=30
BSD-1606317051.A3
1606317051
|
-
|
|
|
|
29 - O-RING 54.0x3.0 MM
BSD-1600210004.A128
1600210004
|
£2.80
|
£3.36
|
|
|
30 - DRIVE SHAFT
BSD-1603123023.A3
1603123023
|
-
|
|
|
|
31 - BUSHING
BSD-1605801018.A20
1605801018
|
£47.95
|
£57.54
|
|
|
32 - COMPRESSION SPRING
BSD-1604619010.A30
1604619010
|
£6.85
|
£8.22
|
|
|
33 - STRIKER
BSD-1608710024.A2
1608710024
|
-
|
|
|
|
34 - PRESSURE SPINDLE
BSD-1603121007.A25
1603121007
|
-
|
|
|
|
35 - COMPRESSION SPRING
BSD-1604610006.A5
1604610006
|
-
|
|
|
|
36 - SPINDLE BEARING
BSD-3605806114.A9
3605806114
|
-
|
|
|
|
37 - SEALING DISK
BSD-1600108051.A2
1600108051
|
-
|
|
|
|
39 - NAMEPLATE
BSD-3601106054.A7
3601106054
|
£5.30
|
£6.36
|
|
|
40 - PROTECTION SLEEVE
BSD-1600328013.A1
1600328013
|
-
|
|
|
|
41 - COMPRESSION SPRING
BSD-1604616006.A0
1604616006
|
£7.72
|
£9.27
|
|
|
42 - PLAIN WASHER 1.0 MM
BSD-1600102623.A22
1600102623
|
£1.38
|
£1.66
|
|
|
43 - RETAINING RING
BSD-1600116001.A9
1600116001
|
-
|
|
|
|
45 - SOCKET HEAD CAP SCREW DIN 84-AM3x20-8.8
BSD-2910021062.A1
2910021062
|
£1.75
|
£2.10
|
|
|
46 - SOCKET HEAD CAP SCREW DIN 84-AM4x10-5.8
BSD-2910011120.A2
2910011120
|
£1.75
|
£2.10
|
|
|
47 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A311
2910021122
|
£2.27
|
£2.72
|
|
|
48/1 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A0
2910141140
|
£1.75
|
£2.10
|
|
|
49/1 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x6-5.8
BSD-2910011082.A7
2910011082
|
£1.75
|
£2.10
|
|
|
50 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x40-8.8
BSD-2910141170.A10
2910141170
|
£2.61
|
£3.13
|
|
|
51 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A550
2910110120
|
£1.84
|
£2.21
|
|
|
52 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A188
1900900287
|
£21.68
|
£26.01
|
|
|
53 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A326
1903230013
|
£2.27
|
£2.72
|
|
|
54 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A772
1903230007
|
£1.84
|
£2.21
|
|
|
55 - BALL DIN 5401-6 G28
BSD-1903230011.A408
1903230011
|
£2.74
|
£3.29
|
|
|
56 - SPRING WASHER dia4.2 MM
BSD-3600150006.A10
3600150006
|
£2.74
|
£3.29
|
|
|
57 - CLAMPING SADDLE
BSD-3601321001.A76
3601321001
|
£3.72
|
£4.47
|
|
|
58 - END SPLICE
BSD-3604477008.A309
3604477008
|
£1.75
|
£2.10
|
|
|
59 - SPRING LOCK WASHER DIN 127-B3.5
BSD-2916680004.A0
2916680004
|
-
|
|
|
|
60 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A1196
2916690003
|
£1.75
|
£2.10
|
|
|
61 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A226
3603133001
|
£2.61
|
£3.13
|
|
|
62/1 - COUPLING HALF 11 MM
BSD-1606455011.A1
1606455011
|
-
|
|
|
|
63 - DETENT PIN
BSD-1603124078.A8
1603124078
|
-
|
|
|
|
64 - COMPRESSION SPRING
BSD-1604611015.A2
1604611015
|
-
|
|
|
|
65 - GUIDE SLEEVE
BSD-1600506008.A6
1600506008
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A136
3601119236
|
£3.91
|
£4.69
|
|
|
705 - COUPLING HALF 7/16
BSD-1606455012.A0
1606455012
|
-
|
|
|
