1 - MOTOR HOUSING
BSD-3605102076.A25
3605102076
|
£50.80
|
£60.96
|
|
|
2 - STATOR 135V/200HZ.200V/300HZ
BSD-3604229114.A0
3604229114
|
£357.27
|
£428.72
|
|
|
3 - ROTOR WITHOUT WINDING
BSD-3604080053.A25
3604080053
|
£156.22
|
£187.46
|
|
|
3/3 - FAN
BSD-3606610010.A57
3606610010
|
£4.48
|
£5.37
|
|
|
4 - AIR-DEFLECTOR RING
BSD-3600209010.A25
3600209010
|
£16.41
|
£19.69
|
|
|
5 - SEAL RING
BSD-1600209006.A116
1600209006
|
£2.94
|
£3.53
|
|
|
6 - GROOVE BALL BEARING
BSD-3600905090.A26
3600905090
|
£22.76
|
£27.31
|
|
|
7 - O-RING 26.0x1.5 MM
BSD-2600210018.A24
2600210018
|
£3.72
|
£4.47
|
|
|
8 - GROOVE BALL BEARING
BSD-3608870327.A0
3608870327
|
£13.78
|
£16.54
|
|
|
10 - CLAMPING SADDLE
BSD-3601321004.A63
3601321004
|
£2.16
|
£2.59
|
|
|
11 - SPRING WASHER
BSD-3600150009.A80
3600150009
|
£2.80
|
£3.36
|
|
|
12 - CONNECTING ROD
BSD-3602300011.A3
3602300011
|
£16.41
|
£19.69
|
|
|
13 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A269
2910110048
|
£1.84
|
£2.21
|
|
|
14 - SPRING RETAINING RING DIN 472-26x1.2 MM
BSD-2916660010.A242
2916660010
|
£1.75
|
£2.10
|
|
|
15 - SHIM 19.3 X 25.8 X 0.35
BSD-3600119016.A1
3600119016
|
£3.72
|
£4.47
|
|
|
16 - O-RING 18.77x1.78 MM
BSD-3600210082.A8
3600210082
|
£2.27
|
£2.72
|
|
|
17 - COMPRESSION SPRING
BSD-3604610038.A1
3604610038
|
£3.91
|
£4.69
|
|
|
18 - LOCATING RING
BSD-3600203005.A27
3600203005
|
£12.04
|
£14.45
|
|
|
19 - TAPPING SCREW
BSD-3603435002.A3
3603435002
|
£1.75
|
£2.10
|
|
|
20 - LENS HEAD SCREW 4x32
BSD-2603490026.A58
2603490026
|
£1.84
|
£2.21
|
|
|
23 - THREAD-FORMING TAP. SCREW
BSD-2603435042.A199
2603435042
|
£1.75
|
£2.10
|
|
|
56 - SWITCH
BSD-3607200024.A17
3607200024
|
£25.05
|
£30.06
|
|
|
57 - SWITCH HANDLE
BSD-1602026057.A227
1602026057
|
£2.07
|
£2.48
|
|
|
58 - SWITCH COVER
BSD-3600508035.A24
3600508035
|
£15.65
|
£18.78
|
|
|
59 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A367
2600703013
|
£2.74
|
£3.29
|
|
|
59 - GROMMET dia6.4-dia7.2x67 MM
BSD-1600703030.A96
1600703030
|
£2.74
|
£3.29
|
|
|
60 - ELEC. CABLE W/CONNECTION
BSD-3604422066.A3
3604422066
|
£57.14
|
£68.57
|
|
|
62 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A287
2603490021
|
£1.84
|
£2.21
|
|
|
63 - FASTENING CLAMP
BSD-1601302017.A439
1601302017
|
£1.84
|
£2.21
|
|
|
65 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A884
2603490023
|
£1.84
|
£2.21
|
|
|
68 - ADJUSTING SLIDE
BSD-3602319014.A25
3602319014
|
£5.57
|
£6.68
|
|
|
69 - COMPRESSION SPRING
BSD-1604611026.A450
1604611026
|
£1.84
|
£2.21
|
|
|
95 - NAMEPLATE
BSD-3601106054.A65
3601106054
|
£5.30
|
£6.36
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110246.A25
3601110246
|
£3.91
|
£4.69
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1015
3601119236
|
£3.91
|
£4.69
|
|
|
102 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A747
1600910018
|
£5.57
|
£6.68
|
|
|
103 - GROOVE BALL BEARING
BSD-3600905069.A28
3600905069
|
£17.22
|
£20.67
|
|
|
104 - GRINDING SPINDLE M14. SW17
BSD-3603523014.A8
3603523014
|
£28.68
|
£34.41
|
|
|
107 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A307
2916660013
|
£2.16
|
£2.59
|
|
|
108 - SHIM 0.2 MM
BSD-1600136010.A51
1600136010
|
£2.61
|
£3.13
|
|
|
108 - SHIM 0.3 MM
BSD-1600136011.A272
1600136011
|
£2.16
|
£2.59
|
|
|
108 - SHIM 0.1 MM
BSD-1600136012.A51
1600136012
|
£1.75
|
£2.10
|
|
|
111 - THREAD-FORMING TAP. SCREW DIN 7500-TM4x12
BSD-2914471401.A41
2914471401
|
£1.75
|
£2.10
|
|
|
115 - CROWN GEAR Z=35
BSD-3606334087.A2
3606334087
|
£120.11
|
£144.13
|
|
|
116 - BEVEL GEAR
BSD-3606333058.A1
3606333058
|
£71.84
|
£86.21
|
|
|
118 - HEX NUT M7. SW10
BSD-1603300016.A5
1603300016
|
£1.84
|
£2.21
|
|
|
119 - O-RING 46.0x1.1 MM
BSD-3600210124.A233
3600210124
|
£2.94
|
£3.53
|
|
|
130 - FAN HOUSING
BSD-3605500076.A0
3605500076
|
£41.62
|
£49.95
|
|
|
131 - FAN
BSD-3606610006.A0
3606610006
|
-
|
|
|
|
132 - WASHER
BSD-3608601004.A3
3608601004
|
-
|
|
|
|
133 - ECCENTRIC SHAFT
BSD-3606110006.A6
3606110006
|
£59.87
|
£71.84
|
|
|
134 - WASHER
BSD-3608601010.A0
3608601010
|
-
|
|
|
|
135 - BACKING PAD
BSD-2608601026.A0
2608601026
|
£35.42
|
£42.51
|
|
|
136 - HANDLE COVER
BSD-3605132047.A6
3605132047
|
£9.97
|
£11.96
|
|
|
137 - TOLERANCE RING
BSD-3600290033.A8
3600290033
|
£3.51
|
£4.21
|
|
|
138 - GROOVE BALL BEARING DIN 625-7x19x6
BSD-3600905148.A2
3600905148
|
£8.92
|
£10.70
|
|
|
139 - GROOVE BALL BEARING 12x28x8
BSD-1600905031.A47
1600905031
|
£6.85
|
£8.22
|
|
|
140 - RETAINING RING 12 DIN 9045
BSD-2916600007.A147
2916600007
|
£2.80
|
£3.36
|
|
|
141 - SPRING RETAINING RING DIN 472-28x1.2 MM
BSD-2916660011.A32
2916660011
|
£1.75
|
£2.10
|
|
|
143 - HEX SOCKET HEAD CAP SCREW
BSD-3603414017.A1
3603414017
|
£2.27
|
£2.72
|
|
|
144 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A162
2910211011
|
£1.84
|
£2.21
|
|
|
145 - PAN HEAD SCREW M 10x12 MM
BSD-3603490015.A14
3603490015
|
£4.48
|
£5.37
|
|
|
146 - RING dia 88x5.7 MM
BSD-3600290034.A1
3600290034
|
£5.57
|
£6.68
|
|
|
147 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x35-8.8
BSD-2910141136.A64
2910141136
|
£2.80
|
£3.36
|
|
|
650 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A782
160202509T
|
£3.91
|
£4.69
|
|
|
650/20 - HEX SCREW DIN 933 M10x35-5.6
BSD-2911051295.A3
2911051295
|
-
|
|
|
|
651 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A456
1907950007
|
£5.57
|
£6.68
|
|
|
656 - O-RING 20.0x1.5 MM
BSD-1610210075.A30
1610210075
|
£2.74
|
£3.29
|
|
|
751 - BACKING PAD dia 150 MM
BSD-3608601006.A3
3608601006
|
£21.72
|
£26.06
|
|
|
751 - BACKING PAD dia 150 MM
BSD-3608601007.A1
3608601007
|
-
|
|
|
|
751 - BACKING PAD dia 150 MM
BSD-3608601008.A3
3608601008
|
-
|
|
|
|
752 - AIR HOSE dia19 MM. L=5M. 3/4
BSD-1610793002.A34
1610793002
|
£36.74
|
£44.09
|
|
|
753 - REDUCTION SLEEVE dia 49/35 MM+3/4
BSD-1609200933.A159
1609200933
|
£7.57
|
£9.08
|
|
|
754 - POLISHING CAP dia 150-160 MM
BSD-3608610000.A1
3608610000
|
£20.39
|
£24.47
|
|
|
755 - POLISHING SPONGE dia 160x15 MM
BSD-3608613000.A3
3608613000
|
-
|
|
|
|
756 - POLISHING DISC dia 150-160 MM
BSD-3608604000.A3
3608604000
|
£20.99
|
£25.19
|
|
|
756 - POLISHING DISC dia 150-160 MM
BSD-3608604001.A1
3608604001
|
£14.74
|
£17.69
|
|
|
757 - ABRASIVE WEB dia 150 MM
BSD-3608604023.A3
3608604023
|
£43.36
|
£52.03
|
|
|
757 - ABRASIVE WEB dia 150 MM
BSD-3608604024.A1
3608604024
|
£39.72
|
£47.66
|
|
|
757 - ABRASIVE WEB dia 150 MM
BSD-3608604025.A3
3608604025
|
£29.44
|
£35.33
|
|
|
758 - SEALING CAP
BSD-3600508024.A3
3600508024
|
-
|
|
|
|
759 - CARRYING CASE
BSD-3605438004.A3
3605438004
|
-
|
|
|
|
770 - COMBI POLISHING ACCESS.
BSD-2607001125.A4
2607001125
|
-
|
|
|
|
770 - ADAPTER
BSD-2608613010.A1
2608613010
|
-
|
|
|
|
770 - POLISHING CAP
BSD-2608610007.A3
2608610007
|
-
|
|
|
|
780 - DUST BAG
BSD-2605411027.A30
2605411027
|
-
|
|
|
|
780/20 - ADAPTER
BSD-3605702003.A3
3605702003
|
-
|
|
|
|
781 - DUST BAG
BSD-2605411068.A18
2605411068
|
£14.69
|
£17.63
|
|
|
782 - DUST BAG
BSD-1605411028.A23
1605411028
|
£15.74
|
£18.89
|
|
|
800 - TRANSMISSION CASE
BSD-3607030251.A1
3607030251
|
£102.57
|
£123.08
|
|
|
801 - PARTS SET
BSD-3607030406.A3
3607030406
|
-
|
|
|
|
803 - ASSEMBLY OF SERVICE PARTS
BSD-3607031209.A1
3607031209
|
£134.16
|
£160.99
|
|
|
804 - WASHER
BSD-3608601004.A2
3608601004
|
-
|
|
|
|
805 - ECCENTRIC DISC
BSD-3607031532.A3
3607031532
|
£50.80
|
£60.96
|
|
|
806 - ASSEMBLY OF SERVICE PARTS
BSD-3607031533.A1
3607031533
|
£9.49
|
£11.39
|
|
|
820 - PUSH-BUTTON
BSD-1607000253.A43
1607000253
|
£2.49
|
£2.99
|
|
