2 - STATOR
BSD-3604229131.A1
3604229131
|
£431.32
|
£517.59
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600209002.A135
1600209002
|
£5.30
|
£6.36
|
|
|
6 - GRINDING SPINDLE
BSD-3603523032.A33
3603523032
|
£57.14
|
£68.57
|
|
|
7 - SEAL RING
BSD-1600290020.A261
1600290020
|
£1.84
|
£2.21
|
|
|
10 - O-RING 45x3MM
BSD-1900210146.A39
1900210146
|
£4.48
|
£5.37
|
|
|
14 - HANDLE
BSD-3605132079.A19
3605132079
|
£45.67
|
£54.80
|
|
|
15 - GROMMET dia12.8xdia13.5x100 MM
BSD-3600703003.A4
3600703003
|
£5.57
|
£6.68
|
|
|
16 - ELEC. CABLE W/CONNECTION
BSD-3604462017.A91
3604462017
|
£57.14
|
£68.57
|
|
|
17 - SWITCH
BSD-3607200055.A33
3607200055
|
£93.88
|
£112.65
|
|
|
22 - NAMEPLATE
BSD-3601106053.A109
3601106053
|
£5.57
|
£6.68
|
|
|
25 - FASTENING CLAMP
BSD-3601303004.A273
3601303004
|
£5.87
|
£7.04
|
|
|
26 - O-RING 66.0x3.0 MM
BSD-1600210005.A185
1600210005
|
£2.80
|
£3.36
|
|
|
27 - SHIM
BSD-3600100075.A18
3600100075
|
£11.30
|
£13.56
|
|
|
27 - SHIM
BSD-3600100076.A30
3600100076
|
£11.30
|
£13.56
|
|
|
27 - SHIM
BSD-3600100077.A18
3600100077
|
£12.04
|
£14.45
|
|
|
28 - SPRING RETAINING RING
BSD-3603435038.A19
3603435038
|
£2.74
|
£3.29
|
|
|
33 - NEEDLE BEARING dia22x11.3 MM
BSD-1600910010.A72
1600910010
|
£45.67
|
£54.80
|
|
|
34 - GROOVE BALL BEARING 6303-2RS1
BSD-3608870382.A18
3608870382
|
£33.22
|
£39.87
|
|
|
35 - RETAINING RING dia22 MM
BSD-2916620011.A184
2916620011
|
£1.84
|
£2.21
|
|
|
37 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x20-8.8
BSD-2910141162.A63
2910141162
|
£2.27
|
£2.72
|
|
|
38 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x18-8.8
BSD-2910141160.A30
2910141160
|
£2.27
|
£2.72
|
|
|
41 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2115
2910211019
|
£1.84
|
£2.21
|
|
|
44 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A233
2910110120
|
£1.84
|
£2.21
|
|
|
45 - CLAMPING SADDLE
BSD-3601321001.A716
3601321001
|
£3.72
|
£4.47
|
|
|
46 - THREAD-FORMING TAP. SCREW
BSD-3603435004.A51
3603435004
|
£2.94
|
£3.53
|
|
|
47 - SPRING WASHER dia4.2 MM
BSD-3600150006.A511
3600150006
|
£2.74
|
£3.29
|
|
|
48 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A667
3603133001
|
£2.61
|
£3.13
|
|
|
52 - SCREW 4x16
BSD-2603490022.A82
2603490022
|
£1.84
|
£2.21
|
|
|
55 - BEVEL GEAR Z=48
BSD-1606333087.A0
1606333087
|
£135.25
|
£162.30
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1866
2910021118
|
£1.84
|
£2.21
|
|
|
68 - SEALING PLATE
BSD-3600054006.A15
3600054006
|
£3.72
|
£4.47
|
|
|
71 - ROTOR WITHOUT WINDING
BSD-1604080036.A0
1604080036
|
£375.13
|
£450.16
|
|
|
72 - BEARING COVER
BSD-1600501019.A401
1600501019
|
£25.05
|
£30.06
|
|
|
73 - BEARING FLANGE
BSD-3605820064.A10
3605820064
|
£71.84
|
£86.21
|
|
|
74 - GROOVE BALL BEARING
BSD-3600905095.A84
3600905095
|
£21.52
|
£25.83
|
|
|
75 - TORX FLAT-HEAD SCREW M4x20
BSD-3603435051.A20
3603435051
|
£1.84
|
£2.21
|
|
|
76 - GROOVE BALL BEARING 7x22x7
BSD-3600905147.A33
3600905147
|
£13.78
|
£16.54
|
|
|
77 - O-RING 22x2 MM
BSD-1900210321.A141
1900210321
|
£5.57
|
£6.68
|
|
|
78 - FELT DISC
BSD-1600108018.A50
1600108018
|
£2.61
|
£3.13
|
|
|
79 - COVER DISC
BSD-1600501024.A93
1600501024
|
£17.22
|
£20.67
|
|
|
80 - SHIM 0.1 MM
BSD-1600102633.A17
1600102633
|
£1.75
|
£2.10
|
|
|
80 - SHIM 0.15 MM
BSD-1600102634.A11
1600102634
|
£2.74
|
£3.29
|
|
|
80 - SHIM 0.05 MM
BSD-1600102632.A11
1600102632
|
£2.27
|
£2.72
|
|
|
81 - SEAL RING
BSD-1600209004.A89
1600209004
|
£2.94
|
£3.53
|
|
|
83 - THREADED RING
BSD-1603344029.A71
1603344029
|
£71.84
|
£86.21
|
|
|
90 - STRIP TERMINAL
BSD-1901091110.A5
1901091110
|
£1.84
|
£2.21
|
|
|
94 - SET SCREW
BSD-1603402002.A74
1603402002
|
£1.75
|
£2.10
|
|
|
95 - SET SCREW
BSD-1603402004.A50
1603402004
|
£2.61
|
£3.13
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A302
3601110047
|
£2.94
|
£3.53
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1685
3601119236
|
£3.91
|
£4.69
|
|
|
656 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A384
2607950511
|
£4.48
|
£5.37
|
|
|
657 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A225
1602025030
|
£19.91
|
£23.89
|
|
|
700/10 - AUXILIARY HANDLE
BSD-160202507H.A630
160202507H
|
£11.87
|
£14.24
|
|
|
700/20 - ADAPTER M8/M14
BSD-3603523013.A11
3603523013
|
£16.41
|
£19.69
|
|
|
801 - MOTOR HOUSING
BSD-3605102079.A89
3605102079
|
£188.33
|
£226.00
|
|
|
804 - GEAR HOUSING
BSD-3607030321.A39
3607030321
|
£297.68
|
£357.21
|
|
|
809/01 - BEARING FLANGE
BSD-3607030375.A95
3607030375
|
£205.02
|
£246.03
|
|
|
809/02 - BEARING FLANGE
BSD-3607030376.A4
3607030376
|
£126.12
|
£151.34
|
|
|
810 - SEAL KIT
BSD-1607000039.A39
1607000039
|
£13.78
|
£16.54
|
|
|
811 - SEAL KIT
BSD-1607000044.A47
1607000044
|
£9.49
|
£11.39
|
|
|
835 - HANDLE
BSD-3607031870.A19
3607031870
|
-
|
|
|
