2 - STATOR 135V/200HZ
BSD-3604229082.A23
3604229082
|
£458.51
|
£550.21
|
|
|
3/8 - GROOVE BALL BEARING 12x32x10
BSD-3600905119.A12
3600905119
|
£27.23
|
£32.68
|
|
|
4 - AIR-DEFLECTOR RING
BSD-3600209008.A49
3600209008
|
£8.67
|
£10.41
|
|
|
6 - GROOVE BALL BEARING
BSD-3600905095.A314
3600905095
|
£21.52
|
£25.83
|
|
|
7 - BEARING FLANGE
BSD-3605805009.A199
3605805009
|
£59.53
|
£71.44
|
|
|
14 - THREADED RING
BSD-3603344024.A9
3603344024
|
£16.41
|
£19.69
|
|
|
15 - O-RING 38.1x2.2 MM
BSD-1600210037.A224
1600210037
|
£2.61
|
£3.13
|
|
|
20 - THREAD-FORMING TAP. SCREW
BSD-2914451079.A150
2914451079
|
£2.61
|
£3.13
|
|
|
21 - THREAD-FORMING TAP. SCREW AM 6x80-ST
BSD-3603410007.A68
3603410007
|
£3.72
|
£4.47
|
|
|
23 - COMPRESSION SPRING
BSD-3604611019.A111
3604611019
|
£2.61
|
£3.13
|
|
|
27 - SEALING DISC
BSD-3600100049.A6
3600100049
|
£3.72
|
£4.47
|
|
|
28 - SEALING DISC
BSD-3600100048.A271
3600100048
|
£2.80
|
£3.36
|
|
|
60 - ELEC. CABLE W/CONNECTION
BSD-3604462017.A196
3604462017
|
£54.42
|
£65.30
|
|
|
61 - TAPPING SCREW BZ4.8x63 MM
BSD-1603435008.A111
1603435008
|
£1.32
|
£1.58
|
|
|
62 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A454
2910211020
|
£2.16
|
£2.59
|
|
|
63 - CABLE ROUTING
BSD-1602388027.A369
1602388027
|
£2.61
|
£3.13
|
|
|
64 - FASTENING CLAMP
BSD-3601303002.A75
3601303002
|
£2.61
|
£3.13
|
|
|
64 - FASTENING CLAMP
BSD-3601303004.A2
3601303004
|
£5.58
|
£6.70
|
|
|
65 - STORAGE LEDGE
BSD-1602388029.A220
1602388029
|
£1.75
|
£2.10
|
|
|
94 - SET SCREW DIN 915-M4x6-45H
BSD-2912081116.A264
2912081116
|
£2.61
|
£3.13
|
|
|
95 - NAMEPLATE
BSD-3601106053.A796
3601106053
|
£5.30
|
£6.36
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A200
3601110047
|
£2.80
|
£3.36
|
|
|
97 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A104
3603133001
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A652
3601119236
|
£3.72
|
£4.47
|
|
|
102 - SPINDLE HOUSING
BSD-3605806077.A4
3605806077
|
£306.65
|
£367.98
|
|
|
103 - GRINDING SPINDLE
BSD-3606120008.A9
3606120008
|
£102.57
|
£123.08
|
|
|
105 - GROOVE BALL BEARING
BSD-3600905060.A47
3600905060
|
£21.52
|
£25.83
|
|
|
106 - GROOVE BALL BEARING
BSD-3600905058.A76
3600905058
|
£21.52
|
£25.83
|
|
|
108 - PINION Z=21
BSD-3606300074.A1
3606300074
|
£72.18
|
£86.62
|
|
|
109 - CLUTCH ELEMENT Z=21
BSD-3606491000.A23
3606491000
|
£6.52
|
£7.83
|
|
|
110 - SPACER SLEEVE
BSD-3600700055.A42
3600700055
|
£31.64
|
£37.97
|
|
|
112 - O-RING 32.0x1.5 MM
BSD-3600210057.A94
3600210057
|
£2.61
|
£3.13
|
|
|
114 - THREADED RING
BSD-3603344024.A8
3603344024
|
£16.41
|
£19.69
|
|
|
115 - O-RING 33.0x2.5 MM
BSD-3600210050.A118
3600210050
|
£2.61
|
£3.13
|
|
|
123 - RETAINING RING 24x2 DIN9045-24
BSD-2916609112.A230
2916609112
|
£2.61
|
£3.13
|
|
|
650 - SINGLE-HEAD ENG. WRENCH SW32
BSD-2607950021.A38
2607950021
|
£27.23
|
£32.68
|
|
|
651 - PIN-TYPE FACE-WRENCH
BSD-2607950022.A31
2607950022
|
£31.64
|
£37.97
|
|
|
655 - PROTECTIVE COVER dia100 MM
BSD-3605510032.A38
3605510032
|
£179.37
|
£215.24
|
|
|
656 - CLAMPING-FLANGE
BSD-3605703089.A25
3605703089
|
£63.50
|
£76.20
|
|
|
656/10 - CLAMPING-FLANGE
BSD-3605703070.A32
3605703070
|
£93.88
|
£112.65
|
|
|
657 - CLAMPING RING
BSD-3605703074.A50
3605703074
|
£21.68
|
£26.01
|
|
|
657/10 - CLAMPING RING
BSD-3605703066.A23
3605703066
|
-
|
|
|
|
658 - RETAINING RING 24x2 DIN9045-24
BSD-2916609112.A231
2916609112
|
£2.61
|
£3.13
|
|
|
801 - MOTOR HOUSING GR.83
BSD-3605108158.A36
3605108158
|
-
|
|
|
|
803 - ROTOR
BSD-3604080038.A34
3604080038
|
£357.27
|
£428.72
|
|
|
810 - BEARING FLANGE
BSD-3607020109.A14
3607020109
|
£283.50
|
£340.20
|
|
|
810/077 - SET OF EARTLING MATERIAL
BSD-3607031299.A47
3607031299
|
£8.67
|
£10.41
|
|
|
811 - FASTENING PARTS KIT
BSD-3607031288.A29
3607031288
|
£120.11
|
£144.13
|
|
|
823 - SPRING SET
BSD-3607031296.A230
3607031296
|
£16.41
|
£19.69
|
|
|
856 - SWITCH KIT
BSD-3607031295.A16
3607031295
|
-
|
|
|
|
858 - HANDLE
BSD-3607031297.A47
3607031297
|
£37.27
|
£44.72
|
|
|
859 - GROMMET
BSD-3607031550.A89
3607031550
|
£13.12
|
£15.75
|
|
