2 - SEAL RING
BSD-1600209011.A179
1600209011
|
£2.94
|
£3.53
|
|
|
3 - STATOR 265V/200HZ. 200V/150HZ
BSD-1604229200.A10
1604229200
|
£481.43
|
£577.72
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600502005.A223
1600502005
|
£2.61
|
£3.13
|
|
|
5 - ROTOR WITHOUT WINDING
BSD-3604080003.A76
3604080003
|
£188.33
|
£226.00
|
|
|
5/4 - INTERMEDIATE RING
BSD-3600202008.A97
3600202008
|
£2.74
|
£3.29
|
|
|
6 - GROOVE BALL BEARING 5x16x5
BSD-1900900232.A198
1900900232
|
£16.74
|
£20.09
|
|
|
7 - RETAINING RING 5 DIN 9045
BSD-2916600002.A41
2916600002
|
-
|
|
|
|
8 - GROOVE BALL BEARING 9x24x7
BSD-1900905017.A123
1900905017
|
£23.86
|
£28.63
|
|
|
9 - BEARING FLANGE
BSD-3605820058.A44
3605820058
|
£33.74
|
£40.49
|
|
|
12 - POWER SUPPLY CORD
BSD-1604462061.A0
1604462061
|
-
|
|
|
|
13 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A846
3600703011
|
£2.94
|
£3.53
|
|
|
14 - FASTENING CLAMP
BSD-1601302014.A1093
1601302014
|
£2.74
|
£3.29
|
|
|
17/1 - NEEDLE-ROLLER BEARING
BSD-1600910002.A35
1600910002
|
£23.86
|
£28.63
|
|
|
18/3 - SPINDLE BEARING
BSD-1605806351.A5
1605806351
|
-
|
|
|
|
19/3 - GRINDING SPINDLE
BSD-1603123027.A8
1603123027
|
-
|
|
|
|
20/1 - O-RING 19.0x3.0 MM
BSD-1600210029.A22
1600210029
|
£6.16
|
£7.39
|
|
|
22/1 - GUIDE SLEEVE
BSD-1600422006.A6
1600422006
|
-
|
|
|
|
23/1 - BALL BEARING 9x26x8
BSD-1900905025.A169
1900905025
|
£21.52
|
£25.83
|
|
|
24/1 - THREADED RING
BSD-3603344059.A57
3603344059
|
£39.17
|
£47.00
|
|
|
25 - CARRIER
BSD-1600320028.A85
1600320028
|
£37.27
|
£44.72
|
|
|
26 - CARRIER
BSD-1606442000.A56
1606442000
|
£5.58
|
£6.70
|
|
|
27 - COLLET dia 6.35 MM = 1/4
BSD-2608570085.A0
2608570085
|
£29.38
|
£35.26
|
|
|
27/2 - ROUND NUT
BSD-3603342009.A41
3603342009
|
£14.91
|
£17.89
|
|
|
28 - NAMEPLATE
BSD-3601106053.A543
3601106053
|
£5.57
|
£6.68
|
|
|
29 - GROOVED NAIL
BSD-3603133000.A403
3603133000
|
£2.61
|
£3.13
|
|
|
30 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A470
2916060003
|
£1.32
|
£1.58
|
|
|
31 - PLAIN WASHER DIN 46 255-DPG 9
BSD-2916010409.A292
2916010409
|
-
|
|
|
|
32 - SPRING WASHER dia4.2 MM
BSD-3600150006.A830
3600150006
|
£2.74
|
£3.29
|
|
|
33 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A79
2910110116
|
£1.84
|
£2.21
|
|
|
34 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A289
2910110048
|
£1.84
|
£2.21
|
|
|
35 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A364
2910021116
|
£2.27
|
£2.72
|
|
|
36 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x35-8.8
BSD-2910141136.A33
2910141136
|
£2.80
|
£3.36
|
|
|
37 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A240
2910141140
|
£1.75
|
£2.10
|
|
|
38 - THREADED BUSHING
BSD-1600363001.A20
1600363001
|
£33.74
|
£40.49
|
|
|
39 - ECCENTRIC BOLT
BSD-1603180004.A24
1603180004
|
£23.86
|
£28.63
|
|
|
40 - BACKUP RING
BSD-1600202019.A15
1600202019
|
£6.85
|
£8.22
|
|
|
42 - RETAINING RING
BSD-1600224025.A45
1600224025
|
£2.61
|
£3.13
|
|
|
45 - SET SCREW
BSD-3603402000.A48
3603402000
|
£1.84
|
£2.21
|
|
|
46 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A183
1901091012
|
£5.57
|
£6.68
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1220
3601119236
|
£3.91
|
£4.69
|
|
|
650 - OFFSET SCREWDRIVER
BSD-1607950001.A45
1607950001
|
£22.60
|
£27.12
|
|
|
650 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A708
2607950511
|
£4.48
|
£5.37
|
|
|
800/1 - GRINDING SPINDLE
BSD-1606120009.A11
1606120009
|
-
|
|
|
|
805 - HANDLE
BSD-3607031145.A106
3607031145
|
-
|
|
|
|
805/11 - CONNECTION HOUSING
BSD-3600099004.A59
3600099004
|
£21.68
|
£26.01
|
|
|
805/15 - SEALING CAP
BSD-3605500074.A53
3605500074
|
£22.76
|
£27.31
|
|
|
805/16 - SWITCH
BSD-3607200001.A37
3607200001
|
£71.84
|
£86.21
|
|
