1 - MOTOR HOUSING
BSD-1605102085.A12
1605102085
|
-
|
|
|
|
2 - SEAL RING
BSD-1600209011.A272
1600209011
|
£2.80
|
£3.36
|
|
|
3 - STATOR 200V/300HZ.135V/200HZ
BSD-1604229201.A25
1604229201
|
£410.78
|
£492.94
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600502005.A109
1600502005
|
£2.61
|
£3.13
|
|
|
5 - ROTOR WITHOUT WINDING
BSD-3604080003.A11
3604080003
|
£179.37
|
£215.24
|
|
|
6 - GROOVE BALL BEARING 5x16x5
BSD-1900900232.A24
1900900232
|
£16.74
|
£20.09
|
|
|
7 - RETAINING RING 5 DIN 9045
BSD-2916600002.A2
2916600002
|
-
|
|
|
|
8 - GROOVE BALL BEARING 9x24x7
BSD-1900905017.A237
1900905017
|
£23.86
|
£28.63
|
|
|
9 - BEARING FLANGE
BSD-3605820059.A17
3605820059
|
£63.50
|
£76.20
|
|
|
12 - POWER SUPPLY CORD
BSD-1604462053.A8
1604462053
|
-
|
|
|
|
13 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A301
3600703011
|
£2.80
|
£3.36
|
|
|
14 - FASTENING CLAMP
BSD-1601302014.A73
1601302014
|
£2.61
|
£3.13
|
|
|
17 - GROOVE BALL BEARING 609-ZY DIN 625
BSD-1900905007.A85
1900905007
|
-
|
|
|
|
18 - SPINDLE BEARING
BSD-1605806291.A11
1605806291
|
-
|
|
|
|
19 - DRILLING SPINDLE
BSD-1603523067.A4
1603523067
|
-
|
|
|
|
20 - DISC SPRING
BSD-1600550007.A9
1600550007
|
-
|
|
|
|
21 - GUIDE SLEEVE
BSD-1600700018.A3
1600700018
|
-
|
|
|
|
22 - SHIM WASHER
BSD-1600101015.A36
1600101015
|
-
|
|
|
|
23 - BALL BEARING 9x26x8
BSD-1900905025.A34
1900905025
|
£21.52
|
£25.83
|
|
|
24 - THREADED RING
BSD-3603344059.A0
3603344059
|
£39.17
|
£47.00
|
|
|
25 - CYLINDRICAL GEAR Z=29
BSD-1606329020.A1
1606329020
|
£81.81
|
£98.17
|
|
|
26 - CYLINDRICAL GEAR Z=47
BSD-1606329016.A7
1606329016
|
£135.25
|
£162.30
|
|
|
27 - COLLET dia 6 MM
BSD-1608570061.A17
1608570061
|
-
|
|
|
|
28 - NAMEPLATE
BSD-3601106053.A820
3601106053
|
£5.30
|
£6.36
|
|
|
29 - GROOVED NAIL
BSD-3603133000.A692
3603133000
|
£2.61
|
£3.13
|
|
|
30 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A89
2916060003
|
£1.32
|
£1.58
|
|
|
31 - PLAIN WASHER DIN 46 255-DPG 9
BSD-2916010409.A47
2916010409
|
-
|
|
|
|
32 - SPRING WASHER dia4.2 MM
BSD-3600150006.A305
3600150006
|
£2.61
|
£3.13
|
|
|
33 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A187
2910110116
|
£1.75
|
£2.10
|
|
|
34 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A13
2910110048
|
£1.75
|
£2.10
|
|
|
35 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A651
2910021116
|
£2.16
|
£2.59
|
|
|
36 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x12-8.8
BSD-2910141122.A165
2910141122
|
£2.16
|
£2.59
|
|
|
37 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A20
2910141140
|
£1.75
|
£2.10
|
|
|
38 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x35-8.8
BSD-2910141136.A158
2910141136
|
£2.80
|
£3.36
|
|
|
39 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x22-8.8
BSD-2910141131.A78
2910141131
|
£2.16
|
£2.59
|
|
|
45 - SET SCREW
BSD-3603402000.A386
3603402000
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A672
3601119236
|
£3.72
|
£4.47
|
|
|
700 - COLLET dia 8 MM
BSD-2608570081.A54
2608570081
|
£21.68
|
£26.01
|
|
|
805 - HANDLE
BSD-3607031145.A19
3607031145
|
-
|
|
|
|
805/11 - CONNECTION HOUSING
BSD-3600099004.A12
3600099004
|
£21.68
|
£26.01
|
|
|
805/15 - SEALING CAP
BSD-3605500074.A109
3605500074
|
£21.68
|
£26.01
|
|
|
805/16 - SUPPORTING DISC
BSD-3600200001.A7
3600200001
|
-
|
|
|
