1 - MOTOR HOUSING
BSD-3605102058.A67
3605102058
|
£120.11
|
£144.13
|
|
|
2 - SEAL RING
BSD-1600209011.A259
1600209011
|
£2.94
|
£3.53
|
|
|
3 - STATOR 200V/300HZ.135V/200HZ
BSD-1604229201.A22
1604229201
|
£431.32
|
£517.59
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600502005.A93
1600502005
|
£2.61
|
£3.13
|
|
|
5 - ROTOR WITHOUT WINDING
BSD-3604080003.A19
3604080003
|
£188.33
|
£226.00
|
|
|
6 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A79
1900905015
|
£30.42
|
£36.51
|
|
|
7 - O-RING 12.0x2.25 MM
BSD-3600210039.A27
3600210039
|
£7.36
|
£8.83
|
|
|
8 - GROOVE BALL BEARING 9x24x7
BSD-1900905017.A230
1900905017
|
£23.86
|
£28.63
|
|
|
9 - INTERMEDIATE BEARING
BSD-3605820062.A3
3605820062
|
£126.12
|
£151.34
|
|
|
10 - INTERMEDIATE RING
BSD-3600202008.A18
3600202008
|
£2.74
|
£3.29
|
|
|
11 - CONNECTION HOUSING
BSD-3600099004.A1
3600099004
|
£21.68
|
£26.01
|
|
|
12 - PVC-INSULATED CABLE
BSD-3604462052.A64
3604462052
|
£57.14
|
£68.57
|
|
|
13 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A305
3600703011
|
£2.94
|
£3.53
|
|
|
14 - FASTENING CLAMP
BSD-1601302014.A63
1601302014
|
£2.74
|
£3.29
|
|
|
15 - SEALING CAP
BSD-3605500074.A110
3605500074
|
£22.76
|
£27.31
|
|
|
16 - SWITCH
BSD-3607200001.A115
3607200001
|
£71.84
|
£86.21
|
|
|
17 - GROOVE BALL BEARING
BSD-3600905038.A39
3600905038
|
£15.65
|
£18.78
|
|
|
18 - SPINDLE BEARING
BSD-3605806120.A0
3605806120
|
£283.50
|
£340.20
|
|
|
19 - GRINDING SPINDLE
BSD-1603523082.A8
1603523082
|
£179.37
|
£215.24
|
|
|
20 - DISC SPRING
BSD-1600550008.A23
1600550008
|
£2.94
|
£3.53
|
|
|
21 - SPACER BUSHING
BSD-1600300083.A34
1600300083
|
£18.96
|
£22.75
|
|
|
22 - SHIM WASHER
BSD-1600103027.A11
1600103027
|
£28.59
|
£34.31
|
|
|
23 - GROOVE BALL BEARING 12x32x10
BSD-1900905201.A0
1900905201
|
£31.64
|
£37.97
|
|
|
24 - THREADED RING
BSD-1603344053.A8
1603344053
|
£57.14
|
£68.57
|
|
|
25 - CYLINDRICAL GEAR Z=22
BSD-1606329019.A8
1606329019
|
£135.25
|
£162.30
|
|
|
26 - CYLINDRICAL GEAR Z=54
BSD-1606329015.A8
1606329015
|
£120.11
|
£144.13
|
|
|
27 - COLLET dia 6 MM
BSD-2608570129.A5
2608570129
|
£19.91
|
£23.89
|
|
|
28 - NAMEPLATE
BSD-3601106053.A822
3601106053
|
£5.57
|
£6.68
|
|
|
29 - GROOVED NAIL
BSD-3603133000.A674
3603133000
|
£2.61
|
£3.13
|
|
|
31 - CLAMPING SADDLE
BSD-3601321001.A320
3601321001
|
£3.72
|
£4.47
|
|
|
32 - SPRING WASHER dia4.2 MM
BSD-3600150006.A314
3600150006
|
£2.74
|
£3.29
|
|
|
33 - PAN HEAD SCREW DIN 85-AM4x8-MS
BSD-2910110118.A112
2910110118
|
£1.84
|
£2.21
|
|
|
34 - DISC SPRING
BSD-3600150013.A138
3600150013
|
£3.91
|
£4.69
|
|
|
35 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A655
2910021116
|
£2.27
|
£2.72
|
|
|
36 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x12-8.8
BSD-2910141122.A163
2910141122
|
£2.27
|
£2.72
|
|
|
37 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A23
2910141140
|
£1.75
|
£2.10
|
|
|
38 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x35-8.8
BSD-2910141136.A157
2910141136
|
£2.80
|
£3.36
|
|
|
39 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x22-8.8
BSD-2910141131.A80
2910141131
|
£2.16
|
£2.59
|
|
|
42 - PROTECTIVE RING
BSD-3600250007.A6
3600250007
|
£22.60
|
£27.12
|
|
|
45 - SET SCREW
BSD-3603402000.A378
3603402000
|
£1.84
|
£2.21
|
|
|
46 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A53
1901091012
|
£5.57
|
£6.68
|
|
|
47 - ROUND NUT
BSD-3603342009.A115
3603342009
|
£14.91
|
£17.89
|
|
|
56 - END SPLICE
BSD-3604477008.A410
3604477008
|
£1.75
|
£2.10
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A523
1601110481
|
£2.27
|
£2.72
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A688
3601119236
|
£3.91
|
£4.69
|
|
|
650 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A362
2607950511
|
£4.48
|
£5.37
|
|
|
700 - COLLET dia 3 MM
BSD-2608570077.A6
2608570077
|
£21.68
|
£26.01
|
|
|
700 - COLLET dia 1/8 (3.175 MM)
BSD-2608570078.A35
2608570078
|
£35.42
|
£42.51
|
|
|
700 - COLLET dia 6 MM
BSD-2608570084.A4
2608570084
|
£36.68
|
£44.02
|
|
|
700 - COLLET dia 1/4 (6.35 MM)
BSD-2608570080.A12
2608570080
|
-
|
|
|
|
700 - COLLET dia 8 MM
BSD-2608570081.A44
2608570081
|
£22.76
|
£27.31
|
|
|
801 - MOTOR HOUSING
BSD-3605102028.A120
3605102028
|
£156.22
|
£187.46
|
|
