1 - MOTOR HOUSING
BSD-3605102048.A27
3605102048
|
£108.30
|
£129.96
|
|
|
3 - LUBRICATING FELT
BSD-1603212000.A106
1603212000
|
-
|
|
|
|
4 - SWITCH HOUSING
BSD-3605130031.A9
3605130031
|
£13.41
|
£16.09
|
|
|
5 - FELT WASHER
BSD-1600205026.A100
1600205026
|
£2.74
|
£3.29
|
|
|
6 - STATOR 72V/200HZ.110V/300HZ
BSD-1604229183.A14
1604229183
|
£321.98
|
£386.38
|
|
|
6/10 - END SPLICE A 0.5-6 DIN 46 228
BSD-1900452000.A66
1900452000
|
-
|
|
|
|
7 - AIR-DEFLECTOR RING
BSD-1600117001.A97
1600117001
|
£2.16
|
£2.59
|
|
|
8 - ROTOR WITHOUT WINDING
BSD-1604080086.A4
1604080086
|
-
|
|
|
|
9 - GROMMET dia5.5-dia8.3x75 MM
BSD-1600703012.A115
1600703012
|
£2.52
|
£3.02
|
|
|
10 - ELEC. CABLE W/CONNECTION
BSD-3604462048.A65
3604462048
|
-
|
|
|
|
11 - FASTENING CLAMP
BSD-1601302001.A58
1601302001
|
£1.75
|
£2.10
|
|
|
12 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A45
1901091012
|
£5.57
|
£6.68
|
|
|
14 - SWITCH
BSD-1607200036.A10
1607200036
|
-
|
|
|
|
15 - HOUSING COVER
BSD-3605130032.A16
3605130032
|
£21.52
|
£25.83
|
|
|
18 - DISC SPRING
BSD-1600550006.A1
1600550006
|
-
|
|
|
|
19 - DRILLING SPINDLE
BSD-1603523068.A1
1603523068
|
-
|
|
|
|
20 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A646
1600905011
|
£5.87
|
£7.04
|
|
|
21 - GROOVE BALL BEARING 6x19x6
BSD-1900900428.A151
1900900428
|
£17.58
|
£21.09
|
|
|
22 - SPINDLE HOUSING
BSD-1605806295.A2
1605806295
|
-
|
|
|
|
23 - THREADED RING
BSD-3603340002.A2
3603340002
|
-
|
|
|
|
25 - UNION NUT
BSD-1603314001.A4
1603314001
|
£66.68
|
£80.01
|
|
|
26 - COLLET dia 3 MM
BSD-1608570010.A5
1608570010
|
£33.74
|
£40.49
|
|
|
26 - COLLET dia 1/8 (3.175 MM)
BSD-1608570012.A4
1608570012
|
-
|
|
|
|
26 - COLLET dia 3/32 (2.35)
BSD-1608570011.A4
1608570011
|
-
|
|
|
|
27 - BEARING HOUSING
BSD-3605820052.A7
3605820052
|
£179.37
|
£215.24
|
|
|
28 - CYLINDRICAL GEAR Z=39
BSD-1606329022.A4
1606329022
|
-
|
|
|
|
29 - CYLINDRICAL GEAR Z=14
BSD-1606329021.A2
1606329021
|
-
|
|
|
|
30 - CONICAL SPRING WASHER
BSD-1600501030.A40
1600501030
|
-
|
|
|
|
34 - SHIM 0.60 MM
BSD-3600101016.A49
3600101016
|
-
|
|
|
|
36 - CLAMPING SADDLE
BSD-3601321002.A49
3601321002
|
£2.64
|
£3.17
|
|
|
37 - SPRING RETAINING RING DIN 471-8x0.8 FSt
BSD-2916640005.A114
2916640005
|
£1.75
|
£2.10
|
|
|
38 - SPRING WASHER
BSD-3600150009.A50
3600150009
|
£2.80
|
£3.36
|
|
|
39 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A67
2916060003
|
£1.32
|
£1.58
|
|
|
41 - GROOVE BALL BEARING 6x19x6
BSD-1900900428.A152
1900900428
|
£17.58
|
£21.09
|
|
|
42 - SINTERED-METAL BUSHING J4G7x8R6x6DIN1850
BSD-1900301003.A45
1900301003
|
-
|
|
|
|
43 - TAPPING SCREW DIN 7971-BZ4.2x13
BSD-2910211025.A10
2910211025
|
£1.84
|
£2.21
|
|
|
44 - PAN HEAD SCREW DIN 85-AM3.5x15-4.8
BSD-2910091046.A41
2910091046
|
£1.84
|
£2.21
|
|
|
45 - SOCKET HEAD CAP SCREW DIN 84-AM3x6-5.8
BSD-2910011048.A60
2910011048
|
£1.75
|
£2.10
|
|
|
46 - SOCKET HEAD CAP SCREW DIN 84-AM3x12-8.8
BSD-2910021054.A26
2910021054
|
£1.75
|
£2.10
|
|
|
47 - HEX SOCKET HEAD CAP SCREW DIN912-M3x30-8.8
BSD-2910141066.A4
2910141066
|
-
|
|
|
|
48 - PAN HEAD SCREW DIN 85-AM3x10-MS
BSD-2910110052.A3
2910110052
|
-
|
|
|
|
50 - SOCKET HEAD CAP SCREW DIN 84-AM3x10-4.8
BSD-2910001052.A126
2910001052
|
£2.27
|
£2.72
|
|
|
51 - HEX SOCKET HEAD CAP SCREW DIN 912-M3x12-8.8
BSD-2910141054.A1
2910141054
|
-
|
|
|
|
52 - REFERENCE PLATE
BSD-3601119236.A699
3601119236
|
£3.91
|
£4.69
|
|
|
55 - SPACER RING
BSD-1600202035.A4
1600202035
|
-
|
|
|
|
75 - SET SCREW DIN 915-M4x6-45H
BSD-2912081116.A237
2912081116
|
£2.61
|
£3.13
|
|
|
95 - NAMEPLATE
BSD-3601106054.A28
3601106054
|
£5.30
|
£6.36
|
|
|
650 - AUXILIARY HANDLE
BSD-3602025008.A11
3602025008
|
£81.81
|
£98.17
|
|
|
650/10 - CLAMPING BAND
BSD-3601038003.A13
3601038003
|
£57.14
|
£68.57
|
|
|
650/10/2 - CLAMPING PLATE
BSD-3602305009.A9
3602305009
|
-
|
|
|
|
650/10/3 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A99
2910021050
|
£1.75
|
£2.10
|
|
|
650/20 - HANDLE
BSD-3602025001.A26
3602025001
|
£63.50
|
£76.20
|
|
|
650/30 - SUPPORT CLAMP
BSD-3600390012.A2
3600390012
|
-
|
|
|
|
650/40 - SOCKET HEAD CAP SCREW DIN 84-BM5x70-4.8
BSD-2910000180.A2
2910000180
|
£1.75
|
£2.10
|
|
|
651 - SINGLE-HEAD ENG. WRENCH DIN 894 SW 9
BSD-1907950503.A10
1907950503
|
£5.57
|
£6.68
|
|
|
652 - SINGLE-HEAD ENG. WRENCH DIN 894 SW11
BSD-1907950505.A3
1907950505
|
£12.04
|
£14.45
|
|
