2 - BRUSH HOLDER
BSD-1604336005.A2
1604336005
|
-
|
|
|
|
3 - SPIRAL SPRING
BSD-1604652001.A21
1604652001
|
-
|
|
|
|
4 - POLE SHOE 240V
BSD-1604220126.A0
1604220126
|
-
|
|
|
|
5 - AIR-DEFLECTOR RING
BSD-1600209002.A227
1600209002
|
£5.30
|
£6.36
|
|
|
6/00 - PARALLEL KEY DIN 6885-A4x4x10-ST
BSD-1902300041.A9
1902300041
|
-
|
|
|
|
6/01 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A331
2916650003
|
£1.75
|
£2.10
|
|
|
6/02 - GROOVE BALL BEARING 12x32x10
BSD-1900905225.A33
1900905225
|
£10.10
|
£12.12
|
|
|
6/03 - CONNECTING ROD
BSD-1609220004.A4
1609220004
|
-
|
|
|
|
6/04 - NEEDLE-ROLLER CAGE
BSD-1609209000.A2
1609209000
|
-
|
|
|
|
6/05 - CLAMP RING
BSD-1609202003.A7
1609202003
|
-
|
|
|
|
6/06 - GROOVE BALL BEARING 6200-Z DIN 625
BSD-1900905200.A21
1900905200
|
-
|
|
|
|
6/07 - ECCENTRIC SHAFT
BSD-1609261002.A0
1609261002
|
-
|
|
|
|
6/08 - CONROD PIN
BSD-1609231002.A0
1609231002
|
-
|
|
|
|
6/09 - BALL BEARING 9x26x8
BSD-1900905025.A116
1900905025
|
£21.52
|
£25.83
|
|
|
6/10 - SPRING RETAINING RING DIN 471-8x0.8 FSt
BSD-2916640005.A77
2916640005
|
£1.75
|
£2.10
|
|
|
6/11 - TAPPET
BSD-1609231003.A4
1609231003
|
-
|
|
|
|
6/12 - LUBRICATING NIPPLE
BSD-1609274002.A20
1609274002
|
-
|
|
|
|
6/13 - GEAR HOUSING
BSD-1609251017.A4
1609251017
|
-
|
|
|
|
6/14 - PISTON RING DIN 24910-28x25.4x2
BSD-1609202005.A2
1609202005
|
-
|
|
|
|
6/15 - ADJUSTING SCREW
BSD-1609234013.A0
1609234013
|
-
|
|
|
|
6/16 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x18-8.8
BSD-2910141199.A64
2910141199
|
£3.72
|
£4.47
|
|
|
6/17 - PLAIN WASHER
BSD-1609201000.A7
1609201000
|
-
|
|
|
|
6/18 - CUTTER PLATE
BSD-1608635015.A2
1608635015
|
-
|
|
|
|
6/19 - CUTTER PLATE
BSD-1608635014.A9
1608635014
|
-
|
|
|
|
6/20 - SET SCREW M 6x10-DIN 913-45H
BSD-2912041191.A2
2912041191
|
-
|
|
|
|
6/21 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x16-8.8
BSD-2910141197.A138
2910141197
|
£1.84
|
£2.21
|
|
|
6/23 - GUIDE BUSHING
BSD-1609204000.A2
1609204000
|
-
|
|
|
|
6/24 - CUTTING TABLE
BSD-1609280025.A0
1609280025
|
-
|
|
|
|
6/27 - STRAIGHT PIN 4 M 6x14 DIN 7-9S20K
BSD-2917510096.A9
2917510096
|
-
|
|
|
|
6/28 - STRAIGHT PIN 5 M 6x36 DIN 7
BSD-2917510130.A2
2917510130
|
-
|
|
|
|
6/29 - HEX SOCKET HEAD CAP SCREW DIN 912-M 14x35-8.8
BSD-2910145392.A4
2910145392
|
-
|
|
|
|
6/30 - SPRING LOCK WASHER M6
BSD-2916690005.A39
2916690005
|
-
|
|
|
|
6/31 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A145
2916660013
|
£2.16
|
£2.59
|
|
|
7 - ARMATURE WITH FAN 240V
BSD-1604010117.A1
1604010117
|
-
|
|
|
|
8 - SPINDLE WITH GEAR Z=18
BSD-1606328098.A2
1606328098
|
-
|
|
|
|
9 - CYLINDRICAL GEAR Z=35
BSD-1606317072.A4
1606317072
|
-
|
|
|
|
10 - SHIM 0.5 MM
BSD-1600100631.A229
1600100631
|
£1.75
|
£2.10
|
|
|
12 - SEALING CAP
BSD-3605500057.A268
3605500057
|
-
|
|
|
|
14 - HANDLE
BSD-1605133029.A43
1605133029
|
-
|
|
|
|
15 - SWITCH
BSD-1607200065.A20
1607200065
|
-
|
|
|
|
16 - POWER SUPPLY CORD
BSD-3607030489.A89
3607030489
|
£31.64
|
£37.97
|
|
|
17 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1359
3600703011
|
£2.94
|
£3.53
|
|
|
19 - SUPPRESSION CAPACITOR
BSD-1607328012.A63
1607328012
|
-
|
|
|
|
21 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A576
1602381001
|
-
|
|
|
|
25 - MANUFACTURER'S NAMEPLATE
BSD-1601110004.A96
1601110004
|
-
|
|
|
|
27 - FASTENING CLAMP
BSD-1601302014.A933
1601302014
|
£2.74
|
£3.29
|
|
|
29 - TAPPING SCREW DIN 7971-BZ3.9x25
BSD-2910211022.A6
2910211022
|
£1.84
|
£2.21
|
|
|
30 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2521
2910211019
|
£1.84
|
£2.21
|
|
|
31 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A42
2910011162
|
£1.84
|
£2.21
|
|
|
32 - TAPPING SCREW DIN 7971-3.9x38
BSD-2910215093.A61
2910215093
|
-
|
|
|
|
33 - HEX SOCKET HEAD CAP SCREW M 5x65 DIN 912-8.8
BSD-2910141179.A12
2910141179
|
£5.57
|
£6.68
|
|
|
34 - SOCKET HEAD CAP SCREW DIN 84-BM5x55-8.8
BSD-2910021176.A65
2910021176
|
-
|
|
|
|
36 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A22
2910021125
|
£1.75
|
£2.10
|
|
|
37 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1509
2910021118
|
£1.84
|
£2.21
|
|
|
38 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A265
2910021116
|
£2.27
|
£2.72
|
|
|
41 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A449
2916680006
|
-
|
|
|
|
42 - SPRING WASHER DIN 137-A4
BSD-1600150006.A153
1600150006
|
-
|
|
|
|
44 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A170
2910110116
|
£1.84
|
£2.21
|
|
|
46 - PLAIN WASHER A 4.3 DIN 125-ST
BSD-2916010410.A198
2916010410
|
-
|
|
|
|
50 - END SPLICE
BSD-3604477009.A233
3604477009
|
£2.61
|
£3.13
|
|
|
51 - SEAL
BSD-1601015009.A6
1601015009
|
-
|
|
|
|
52 - FELT DISC
BSD-1600108003.A159
1600108003
|
£1.38
|
£1.66
|
|
|
53 - BEARING COVER
BSD-1600501019.A347
1600501019
|
£25.05
|
£30.06
|
|
|
54 - GROOVE BALL BEARING 17x35x10
BSD-1600900001.A137
1600900001
|
-
|
|
|
|
55 - BEARING FLANGE
BSD-1605820183.A6
1605820183
|
-
|
|
|
|
56 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A21
2910021125
|
£1.75
|
£2.10
|
|
|
57 - SHIM 0.10 MM
BSD-1420100023.A118
1420100023
|
-
|
|
|
|
57 - SHIM 0.2 MM
BSD-1600100632.A148
1600100632
|
£1.84
|
£2.21
|
|
|
58 - BALL BEARING 7x22x7
BSD-1900905018.A1206
1900905018
|
£19.91
|
£23.89
|
|
|
78 - NEEDLE BEARING
BSD-1600910013.A255
1600910013
|
£5.58
|
£6.70
|
|
|
650 - OFFSET SCREWDRIVER DIN 911. SW3
BSD-1907950004.A138
1907950004
|
£5.87
|
£7.04
|
|
|
651 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A87
1907950006
|
£4.48
|
£5.37
|
|
|
652 - HOLDING PIN dia 3x104 MM
BSD-1604682009.A1
1604682009
|
-
|
|
|
|
653 - GRINDING GAUGE
BSD-1607970010.A4
1607970010
|
-
|
|
|
|
654 - GREASE GUN
BSD-1615437502.A12
1615437502
|
-
|
|
|
|
801 - MOTOR HOUSING
BSD-1607000139.A19
1607000139
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A1787
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014101.A104
1607014101
|
£11.87
|
£14.24
|
|
|
824 - ROUND-HEAD GROOVED PIN
BSD-1603133000.A9
1603133000
|
-
|
|
|
