1 - HOUSING
BSD-2607001031.A6
2607001031
|
-
|
|
|
|
2 - POLE SHOE 110-115V
BSD-2604220256.A3
2604220256
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200001.A0
2607200001
|
-
|
|
|
|
5 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A490
1607000227
|
£23.86
|
£28.63
|
|
|
5 - CABLE
BSD-2604460089.A1
2604460089
|
-
|
|
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A594
2600703011
|
£2.94
|
£3.53
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A616
2600703012
|
£2.94
|
£3.53
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A597
2600703013
|
£2.74
|
£3.29
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2351
2601035001
|
£1.84
|
£2.21
|
|
|
8 - NAMEPLATE
BSD-160111A3H3.A4004
160111A3H3
|
£2.74
|
£3.29
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601007003.A168
2601007003
|
-
|
|
|
|
10 - CARBON-BRUSH SET
BSD-2604320902.A6
2604320902
|
-
|
|
|
|
15 - HOUSING COVER
BSD-2605500012.A0
2605500012
|
-
|
|
|
|
16 - TAPPING SCREW DIN 7971-BZ3.9x9.5
BSD-2910211017.A30
2910211017
|
-
|
|
|
|
17 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A305
2910211019
|
£1.84
|
£2.21
|
|
|
18 - SOCKET HEAD CAP SCREW
BSD-2603410010.A210
2603410010
|
-
|
|
|
|
19 - SPIRAL SPRING
BSD-2604652003.A60
2604652003
|
-
|
|
|
|
20 - HOUSING COVER
BSD-2605500004.A6
2605500004
|
-
|
|
|
|
21 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A125
2910211021
|
£1.75
|
£2.10
|
|
|
22 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A306
2910211019
|
£1.84
|
£2.21
|
|
|
23 - CHANGE-OVER SWITCH
BSD-2607200002.A6
2607200002
|
-
|
|
|
|
24 - CONNECTING CABLE
BSD-2604411505.A42
2604411505
|
-
|
|
|
|
25 - SCREENED ELECTRIC CABLE
BSD-2604465002.A0
2604465002
|
-
|
|
|
|
25 - CABLE
BSD-2604411064.A6
2604411064
|
-
|
|
|
|
26 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A84
2603410023
|
-
|
|
|
|
27 - GROOVE BALL BEARING 6x19x6
BSD-1900905019.A122
1900905019
|
£14.91
|
£17.89
|
|
|
28 - FAN
BSD-2606610013.A112
2606610013
|
-
|
|
|
|
29 - CONNECTING CABLE
BSD-2604503002.A6
2604503002
|
-
|
|
|
|
29 - CABLE
BSD-2604411063.A1
2604411063
|
-
|
|
|
|
30 - BEARING SLEEVE
BSD-2600300043.A18
2600300043
|
-
|
|
|
|
31 - COVER DISC
BSD-2600522011.A0
2600522011
|
-
|
|
|
|
32 - COMPRESSION SPRING
BSD-2604611024.A79
2604611024
|
£2.27
|
£2.72
|
|
|
33 - COVER DISC
BSD-2600190001.A0
2600190001
|
-
|
|
|
|
34 - SPRING RETAINING RING DIN 472-26x1.2 MM
BSD-2916660010.A45
2916660010
|
£1.75
|
£2.10
|
|
|
35 - GROOVE BALL BEARING 10 MM DIN 625
BSD-2600905007.A99
2600905007
|
-
|
|
|
|
36 - CUPPED WASHER
BSD-2600500008.A32
2600500008
|
-
|
|
|
|
37 - FELT DISC
BSD-2600108017.A0
2600108017
|
-
|
|
|
|
38 - INTERMEDIATE BEARING
BSD-2605820022.A2
2605820022
|
-
|
|
|
|
39 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A313
2600914010
|
£2.94
|
£3.53
|
|
|
40 - STRAIGHT PIN 4 H 8x12 DIN 7
BSD-2917500095.A95
2917500095
|
£1.75
|
£2.10
|
|
|
41 - SHIM 0.3 MM
BSD-2600101656.A29
2600101656
|
-
|
|
|
|
42 - SHIM
BSD-2600150003.A108
2600150003
|
£2.16
|
£2.59
|
|
|
43 - SHIM 0.2 MM
BSD-2600101655.A146
2600101655
|
-
|
|
|
|
43 - SHIM 0.3 MM
BSD-2600101656.A28
2600101656
|
-
|
|
|
|
43 - SHIM 0.5 MM
BSD-2600101657.A146
2600101657
|
-
|
|
|
|
50 - SHIM 1.0 MM
BSD-2600100569.A190
2600100569
|
£1.84
|
£2.21
|
|
|
51 - TOOTHED SHAFT
BSD-3606309058.A13
3606309058
|
£63.50
|
£76.20
|
|
|
52 - CYLINDRICAL GEAR Z=31
BSD-2606317001.A14
2606317001
|
£31.64
|
£37.97
|
|
|
54 - INTERMEDIATE FLANGE
BSD-3605700120.A2
3605700120
|
£37.27
|
£44.72
|
|
|
55 - STRAIGHT PIN 4 H 8x24 DIN 7
BSD-2917500101.A4
2917500101
|
£1.75
|
£2.10
|
|
|
56 - GROOVE BALL BEARING 6001 Y DIN 625 FD150
BSD-1900900271.A15
1900900271
|
-
|
|
|
|
57 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A543
1903230007
|
£1.84
|
£2.21
|
|
|
58 - DRIVE SHAFT
BSD-2603124002.A0
2603124002
|
£72.18
|
£86.62
|
|
|
59 - BUSHING
BSD-1605801018.A11
1605801018
|
£47.95
|
£57.54
|
|
|
60 - COMPRESSION SPRING
BSD-1604619010.A15
1604619010
|
£6.85
|
£8.22
|
|
|
61 - STRIKER
BSD-1608710024.A12
1608710024
|
-
|
|
|
|
62 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A819
1903230013
|
£2.27
|
£2.72
|
|
|
63 - TOOL HOLDING FIXTURE
BSD-3607030424.A25
3607030424
|
£142.02
|
£170.42
|
|
|
64 - O-RING 7.65x1.78 MM
BSD-2600210001.A14
2600210001
|
£2.16
|
£2.59
|
|
|
65 - RETAINING RING
BSD-2600224007.A0
2600224007
|
£6.85
|
£8.22
|
|
|
67 - SPINDLE BEARING
BSD-2605806014.A14
2605806014
|
-
|
|
|
|
69 - PROTECTIVE RING
BSD-2600250005.A14
2600250005
|
£4.26
|
£5.11
|
|
|
70 - SOCKET HEAD CAP SCREW DIN 84 AM5x30-8.8
BSD-2910021166.A3
2910021166
|
-
|
|
|
|
71 - SPRING LOCK WASHER DIN 128-A5-FST
BSD-2916690004.A111
2916690004
|
£1.75
|
£2.10
|
|
|
653 - SUSPENSION LOOP
BSD-2604682001.A12
2604682001
|
£6.94
|
£8.33
|
|
