2 - BRUSH HOLDER
BSD-1604336005.A75
1604336005
|
-
|
|
|
|
3 - SPIRAL SPRING
BSD-1604652011.A7
1604652011
|
-
|
|
|
|
4 - FIELD 110V
BSD-1604220033.A1
1604220033
|
-
|
|
|
|
5 - AIR-DEFLECTOR RING
BSD-1600209002.A329
1600209002
|
£5.30
|
£6.36
|
|
|
6 - BEARING HOUSING
BSD-3605805017.A18
3605805017
|
-
|
|
|
|
7 - ARMATURE 110V
BSD-1604010042.A1
1604010042
|
-
|
|
|
|
8 - BEARING COVER
BSD-1600501062.A17
1600501062
|
-
|
|
|
|
9 - GROOVE BALL BEARING 15x35x11
BSD-1900900303.A132
1900900303
|
-
|
|
|
|
10 - SPRING LOCK WASHER B 4 DIN 127
BSD-2916681005.A56
2916681005
|
£1.75
|
£2.10
|
|
|
12 - SEALING CAP
BSD-3605500057.A38
3605500057
|
-
|
|
|
|
13 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A543
2910021125
|
£1.75
|
£2.10
|
|
|
15 - SWITCH
BSD-1607200025.A6
1607200025
|
-
|
|
|
|
17 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A98
3600703011
|
£2.80
|
£3.36
|
|
|
17 - GROMMET
BSD-1600703008.A15
1600703008
|
-
|
|
|
|
18 - CYLINDRICAL GEAR Z=34
BSD-1606317048.A5
1606317048
|
-
|
|
|
|
21 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A52
1602381001
|
-
|
|
|
|
22 - SEALING DISK
BSD-1600108029.A17
1600108029
|
£1.32
|
£1.58
|
|
|
23 - BACKUP RING
BSD-1600220015.A15
1600220015
|
£102.57
|
£123.08
|
|
|
25 - MANUFACTURER'S NAMEPLATE
BSD-1601110004.A29
1601110004
|
-
|
|
|
|
26 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A691
1903230007
|
£1.75
|
£2.10
|
|
|
27 - O-RING 74.0x3.0 MM
BSD-1600210006.A166
1600210006
|
£1.75
|
£2.10
|
|
|
28 - FASTENING CLAMP
BSD-1601302014.A596
1601302014
|
£2.61
|
£3.13
|
|
|
29 - COMPRESSION SPRING
BSD-1604624004.A4
1604624004
|
-
|
|
|
|
30 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1000
2910211019
|
£1.75
|
£2.10
|
|
|
31 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-8.8
BSD-2910021154.A196
2910021154
|
£1.75
|
£2.10
|
|
|
32 - STRIKER
BSD-1608710018.A21
1608710018
|
£251.67
|
£302.00
|
|
|
33 - BALL DIN 5401-8 MM III-ST
BSD-1903230014.A29
1903230014
|
£1.75
|
£2.10
|
|
|
34 - SOCKET HEAD CAP SCREW DIN 84-BM5x55-8.8
BSD-2910021176.A9
2910021176
|
-
|
|
|
|
35 - HEX SOCKET HEAD CAP SCREW
BSD-3603414028.A92
3603414028
|
£1.75
|
£2.10
|
|
|
36 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A542
2910021125
|
£1.75
|
£2.10
|
|
|
37 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A912
2910021118
|
£1.75
|
£2.10
|
|
|
38 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A466
2910021116
|
£2.16
|
£2.59
|
|
|
39 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A503
2910211021
|
£1.75
|
£2.10
|
|
|
39 - SOCKET HEAD CAP SCREW DIN 84-AM4x18-5.8
BSD-2910011128.A195
2910011128
|
£1.75
|
£2.10
|
|
|
40 - DRIVE SHAFT
BSD-1603124077.A12
1603124077
|
£156.22
|
£187.46
|
|
|
41 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A193
2916680006
|
-
|
|
|
|
42 - SPRING WASHER DIN 137-A4
BSD-1600150006.A548
1600150006
|
-
|
|
|
|
43 - SHIM WASHER
BSD-3600114013.A6
3600114013
|
£21.68
|
£26.01
|
|
|
44 - SWITCH HOUSING
BSD-3605130029.A4
3605130029
|
-
|
|
|
|
45 - CHANGE-OVER SWITCH
BSD-1607200032.A4
1607200032
|
-
|
|
|
|
48 - INSULATING PLATE 20x20x50 MM
BSD-1602381006.A151
1602381006
|
£1.75
|
£2.10
|
|
|
50 - MULTIPLATE CLUTCH
BSD-1606401006.A16
1606401006
|
-
|
|
|
|
52 - SHIM 0.2 MM
BSD-1600100609.A33
1600100609
|
-
|
|
|
|
55 - O-RING 28x3 MM
BSD-1900210129.A74
1900210129
|
£2.61
|
£3.13
|
|
|
56 - SOCKET HEAD CAP SCREW DIN 84-BM5x40-5.8
BSD-2910011170.A48
2910011170
|
£1.75
|
£2.10
|
|
|
56 - TAPPING SCREW B4.8x50 MM
BSD-1603435012.A76
1603435012
|
£1.75
|
£2.10
|
|
|
57 - SPINDLE BEARING
BSD-3605806115.A13
3605806115
|
-
|
|
|
|
58 - COUPLING HALF 3/4
BSD-1606455031.A21
1606455031
|
£156.22
|
£187.46
|
|
|
59 - SOCKET HEAD CAP SCREW DIN 84-BM5x82
BSD-1603410001.A204
1603410001
|
-
|
|
|
|
59 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A186
1603435006
|
-
|
|
|
|
60 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A376
2910110116
|
£1.75
|
£2.10
|
|
|
61 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A1128
2916690003
|
£1.75
|
£2.10
|
|
|
62 - PLAIN WASHER A 4.3 DIN 125-ST
BSD-2916010410.A263
2916010410
|
-
|
|
|
|
63 - SOCKET HEAD CAP SCREW DIN 84-AM3x4-5.8
BSD-2910011046.A16
2910011046
|
-
|
|
|
|
64 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A172
2916060003
|
£1.32
|
£1.58
|
|
|
65 - END SPLICE
BSD-3604477009.A191
3604477009
|
£2.61
|
£3.13
|
|
|
72 - SHIM 0.5 MM
BSD-1600100631.A123
1600100631
|
£1.75
|
£2.10
|
|
|
96 - FELT DISC
BSD-1600108003.A272
1600108003
|
£1.32
|
£1.58
|
|
|
97 - BEARING COVER
BSD-1600501019.A158
1600501019
|
£23.86
|
£28.63
|
|
|
98 - GROOVE BALL BEARING 17x35x10
BSD-1600900001.A65
1600900001
|
-
|
|
|
|
99 - BEARING FLANGE
BSD-1605820163.A22
1605820163
|
-
|
|
|
|
100 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A540
2910021125
|
£1.75
|
£2.10
|
|
|
101 - SHIM 0.10 MM
BSD-1420100023.A272
1420100023
|
-
|
|
|
|
101 - SHIM 0.2 MM
BSD-1600100632.A205
1600100632
|
£1.75
|
£2.10
|
|
|
102 - BALL BEARING 7x22x7
BSD-1900905018.A136
1900905018
|
£18.96
|
£22.75
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A1248
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1074
1602025030
|
£18.96
|
£22.75
|
|
|
700 - THREADED FITTING M14. L=70 MM
BSD-1603527017.A19
1603527017
|
-
|
|
|
|
800 - HANDLE
BSD-3605133009.A17
3605133009
|
£30.28
|
£36.33
|
|
|
801 - BEARING FLANGE
BSD-1605820038.A24
1605820038
|
-
|
|
|
|
802 - CARBON-BRUSH SET
BSD-1607014101.A6
1607014101
|
£11.30
|
£13.56
|
|
|
805 - MOTOR HOUSING
BSD-1607000139.A12
1607000139
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A5426
160111A3H3
|
£2.61
|
£3.13
|
|
