1 - GEAR HOUSING
BSD-2605806259.A2
2605806259
|
-
|
|
|
|
2 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A279
2600914010
|
£2.94
|
£3.53
|
|
|
3 - SPINDLE WITH GEAR Z= 41
BSD-2606100055.A6
2606100055
|
-
|
|
|
|
4 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A260
1903230004
|
£2.27
|
£2.72
|
|
|
5 - COUPLING HALF
BSD-2606445000.A30
2606445000
|
-
|
|
|
|
6 - COMPRESSION SPRING
BSD-1604616010.A11
1604616010
|
-
|
|
|
|
7 - COMPRESSION SPRING
BSD-1604619005.A27
1604619005
|
-
|
|
|
|
8 - SHIM
BSD-2600100608.A4
2600100608
|
-
|
|
|
|
9 - BUSHING
BSD-1600309004.A74
1600309004
|
-
|
|
|
|
10 - ROUND NUT
BSD-1603341000.A27
1603341000
|
-
|
|
|
|
12 - GUIDE SLEEVE
BSD-2600460001.A2
2600460001
|
-
|
|
|
|
14 - CARRIER 6 KT.. 6.3 MM
BSD-2606455002.A0
2606455002
|
-
|
|
|
|
15 - O-RING 8.0x1.5 MM
BSD-1900210103.A101
1900210103
|
£2.94
|
£3.53
|
|
|
16 - PRESSURE SPINDLE
BSD-1603120022.A24
1603120022
|
-
|
|
|
|
17 - COMPRESSION SPRING
BSD-1604626002.A24
1604626002
|
-
|
|
|
|
19 - SPRING LOCK WASHER
BSD-1600224011.A35
1600224011
|
-
|
|
|
|
20 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A262
1903230003
|
£2.74
|
£3.29
|
|
|
22 - SPINDLE WITH GEAR Z= 11/41
BSD-2606100056.A0
2606100056
|
-
|
|
|
|
23 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A226
1903201042
|
£2.27
|
£2.72
|
|
|
24 - SHIM 0.3 MM
BSD-2600100607.A406
2600100607
|
£1.75
|
£2.10
|
|
|
26 - INTERMEDIATE FLANGE
BSD-2605700159.A6
2605700159
|
-
|
|
|
|
27 - FELT DISC
BSD-2600108000.A36
2600108000
|
-
|
|
|
|
28 - CUPPED WASHER
BSD-2600500030.A116
2600500030
|
-
|
|
|
|
29 - SEAL BUSHING
BSD-2600300049.A102
2600300049
|
-
|
|
|
|
30 - BALL BEARING 8x22x7
BSD-1900905029.A73
1900905029
|
£22.60
|
£27.12
|
|
|
31 - ARMATURE 220V
BSD-2604010367.A1
2604010367
|
-
|
|
|
|
32 - GROOVE BALL BEARING 6x19x6
BSD-1900905019.A160
1900905019
|
£14.91
|
£17.89
|
|
|
33 - SHIM
BSD-2600150003.A126
2600150003
|
£2.16
|
£2.59
|
|
|
34 - FAN
BSD-2606610013.A146
2606610013
|
-
|
|
|
|
35 - SHIM 0.2 MM
BSD-2600101655.A150
2600101655
|
-
|
|
|
|
35 - SHIM 0.3 MM
BSD-2600101656.A24
2600101656
|
-
|
|
|
|
35 - SHIM 0.5 MM
BSD-2600101657.A150
2600101657
|
-
|
|
|
|
37 - MOTOR HOUSING
BSD-2605104911.A21
2605104911
|
-
|
|
|
|
38 - POLE SHOE 220V
BSD-2604222254.A5
2604222254
|
-
|
|
|
|
39 - COVER DISC
BSD-2601328015.A16
2601328015
|
-
|
|
|
|
40 - COMPRESSION SPRING
BSD-2604611026.A151
2604611026
|
-
|
|
|
|
42 - SOCKET HEAD CAP SCREW DIN 84-AM4x25-8.8
BSD-2910021132.A61
2910021132
|
£1.84
|
£2.21
|
|
|
43 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A686
2916690003
|
£1.75
|
£2.10
|
|
|
46 - CARBON-BRUSH SET
BSD-2604320902.A53
2604320902
|
-
|
|
|
|
48 - SPIRAL SPRING
BSD-2604652002.A104
2604652002
|
-
|
|
|
|
49 - TAPPING SCREW DIN 7971-BZ2.9x6.5
BSD-2910211004.A50
2910211004
|
-
|
|
|
|
51 - SOCKET HEAD CAP SCREW
BSD-2603410010.A251
2603410010
|
-
|
|
|
|
53 - ON-OFF SWITCH
BSD-2607200043.A35
2607200043
|
-
|
|
|
|
54 - SUPPRESSION FILTER
BSD-2607329051.A26
2607329051
|
-
|
|
|
|
55 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A470
1607000227
|
£23.86
|
£28.63
|
|
|
56 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A540
2600703011
|
£2.94
|
£3.53
|
|
|
56 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A681
2600703012
|
£2.94
|
£3.53
|
|
|
56 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A545
2600703013
|
£2.74
|
£3.29
|
|
|
57 - CABLE CLIP
BSD-2601035001.A2379
2601035001
|
£1.84
|
£2.21
|
|
|
58 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A57
2603410023
|
-
|
|
|
|
59 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A223
2910211019
|
£1.84
|
£2.21
|
|
|
60 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A523
2910211020
|
£2.16
|
£2.59
|
|
|
61 - HOUSING COVER
BSD-2605132005.A24
2605132005
|
-
|
|
|
|
62 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A79
2910211021
|
£1.75
|
£2.10
|
|
|
63 - ROUND-HEAD GROOVED PIN 2x3 DIN 1476 ST
BSD-2917724031.A20
2917724031
|
-
|
|
|
|
64 - NAMEPLATE
BSD-160111A3H3.A3741
160111A3H3
|
£2.74
|
£3.29
|
|
|
65 - MANUFACTURER'S NAMEPLATE
BSD-2601007003.A216
2601007003
|
-
|
|
|
|
66 - ON-OFF SWITCH
BSD-2607200049.A3
2607200049
|
-
|
|
|
|
68 - CABLE
BSD-2604411524.A6
2604411524
|
-
|
|
|
|
69 - SUPPRESSOR BOX
BSD-2604465026.A58
2604465026
|
-
|
|
|
|
70 - SUPPRESSOR BOX
BSD-2604465027.A7
2604465027
|
-
|
|
|
|
651 - STRAIGHT PIN 4x60 MM
BSD-2603101035.A48
2603101035
|
£2.94
|
£3.53
|
|
|
654 - SUSPENSION LOOP
BSD-3604720004.A74
3604720004
|
£2.94
|
£3.53
|
|
