2 - FIELD 100-110V
BSD-1604220136.A6
1604220136
|
-
|
|
|
|
2/10 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A94
1901350003
|
£1.84
|
£2.21
|
|
|
3 - ARMATURE 100-110V
BSD-1604010163.A0
1604010163
|
-
|
|
|
|
4/10 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A75
2910091118
|
£1.84
|
£2.21
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A418
3600703011
|
£2.94
|
£3.53
|
|
|
6 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A13
1600703009
|
£5.87
|
£7.04
|
|
|
7 - FASTENING CLAMP
BSD-1601302013.A582
1601302013
|
£1.84
|
£2.21
|
|
|
9 - STICKER
BSD-1601110046.A148
1601110046
|
£1.75
|
£2.10
|
|
|
11 - SUPPRESSION FILTER
BSD-1607328034.A112
1607328034
|
£4.48
|
£5.37
|
|
|
15 - GEAR HOUSING
BSD-1605806360.A4
1605806360
|
-
|
|
|
|
17 - BEARING FLANGE
BSD-1605805054.A35
1605805054
|
-
|
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1600502012.A6
1600502012
|
-
|
|
|
|
19 - SEALING CAP
BSD-1605500127.A3
1605500127
|
-
|
|
|
|
20 - COVER PLATE
BSD-1601037007.A5
1601037007
|
-
|
|
|
|
21 - GROMMET
BSD-1600306001.A107
1600306001
|
£2.61
|
£3.13
|
|
|
22 - INTERMEDIATE RING
BSD-1600502018.A1
1600502018
|
-
|
|
|
|
23 - CONTROL LEVER
BSD-1602026030.A355
1602026030
|
£10.10
|
£12.12
|
|
|
23/8 - FELT WASHER
BSD-1600205008.A265
1600205008
|
£1.75
|
£2.10
|
|
|
25 - TAB WASHER
BSD-1601030022.A468
1601030022
|
£1.84
|
£2.21
|
|
|
27 - INTERMEDIATE RING
BSD-1600206018.A48
1600206018
|
-
|
|
|
|
28 - SEALING CORD
BSD-1601014000.A295
1601014000
|
£2.80
|
£3.36
|
|
|
30 - SPACER BUSHING
BSD-1600500022.A5
1600500022
|
-
|
|
|
|
31 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A672
2916660013
|
£2.16
|
£2.59
|
|
|
32 - GRINDING SPINDLE M14
BSD-1603523086.A32
1603523086
|
-
|
|
|
|
35 - SHIM 0.1 MM
BSD-2600136002.A57
2600136002
|
-
|
|
|
|
35 - SHIM 0.2 MM
BSD-2600136003.A8
2600136003
|
-
|
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290011.A4
1600290011
|
-
|
|
|
|
38 - CROWN GEAR Z=33
BSD-1606333182.A2
1606333182
|
-
|
|
|
|
39 - SPIRAL SPRING
BSD-1604652006.A270
1604652006
|
£1.84
|
£2.21
|
|
|
40 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A196
2600910001
|
£4.48
|
£5.37
|
|
|
41 - CONNECTING CABLE L=260 MM
BSD-1604440008.A37
1604440008
|
-
|
|
|
|
41/10 - TERMINAL LUG
BSD-1601353003.A7
1601353003
|
-
|
|
|
|
43 - SEAL
BSD-1600113013.A2
1600113013
|
£1.32
|
£1.58
|
|
|
45 - GROOVE BALL BEARING 15x32x9
BSD-1600905004.A24
1600905004
|
-
|
|
|
|
46 - BALL BEARING 7x19x6
BSD-2600905032.A1464
2600905032
|
£5.57
|
£6.68
|
|
|
47 - GROOVE BALL BEARING 12x32x10
BSD-1600905006.A162
1600905006
|
£12.64
|
£15.17
|
|
|
50 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A21
2910211006
|
£1.75
|
£2.10
|
|
|
52 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A194
2910021122
|
£2.27
|
£2.72
|
|
|
53 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A226
2910021118
|
£1.84
|
£2.21
|
|
|
54 - COUNTERSUNK-HEAD SCREW M 4x16 DIN 963-5.8
BSD-2910771126.A24
2910771126
|
-
|
|
|
|
55 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A483
2910211011
|
£1.84
|
£2.21
|
|
|
56 - TAPPING SCREW B4.8x65 MM
BSD-1603435005.A6
1603435005
|
-
|
|
|
|
57 - TAPPING SCREW DIN 7971-ST4.8x38-F
BSD-2910211038.A85
2910211038
|
£1.84
|
£2.21
|
|
|
58 - SCREW B 4.8x45 MM
BSD-3603415560.A187
3603415560
|
£1.84
|
£2.21
|
|
|
59 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A98
2915011005
|
£1.84
|
£2.21
|
|
|
60 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A147
2916011005
|
£1.84
|
£2.21
|
|
|
62 - RETAINING RING
BSD-1600116006.A5
1600116006
|
-
|
|
|
|
150/1 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A6
1900452012
|
£1.75
|
£2.10
|
|
|
650/10 - AUXILIARY HANDLE M14
BSD-1602025022.A1535
1602025022
|
£13.41
|
£16.09
|
|
|
650/10 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1246
1602025030
|
£19.91
|
£23.89
|
|
|
650/11 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A321
2607950511
|
£4.48
|
£5.37
|
|
|
650/12 - ROUND NUT M14
BSD-1603340015.A10
1603340015
|
£4.06
|
£4.87
|
|
|
650/13 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A569
1607950052
|
£3.91
|
£4.69
|
|
|
650/13/1 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A481
2607950004
|
£1.84
|
£2.21
|
|
|
652 - PROTECTIVE COVER dia 150 MM
BSD-1605510105.A2
1605510105
|
-
|
|
|
|
652/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A103
2910022197
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014126.A145
1607014126
|
£17.22
|
£20.67
|
|
|
801 - PARTS SET
BSD-1607000145.A1
1607000145
|
-
|
|
|
|
802 - SWITCH KIT
BSD-1607000034.A256
1607000034
|
-
|
|
|
|
803 - HANDLE
BSD-3605132048.A244
3605132048
|
£66.68
|
£80.01
|
|
|
822 - INTERMEDIATE RING
BSD-1600502011.A547
1600502011
|
£2.74
|
£3.29
|
|
|
824 - BRUSH HOLDER
BSD-1604336017.A84
1604336017
|
£7.36
|
£8.83
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A249
1607000228
|
£23.86
|
£28.63
|
|
|
840 - NEEDLE-ROLLER BEARING dia 17 MM
BSD-1600910009.A20
1600910009
|
-
|
|
|
|
861 - RETAINING RING dia18.4 MM
BSD-1604601022.A1
1604601022
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3775
160111A3H3
|
£2.74
|
£3.29
|
|
