1 - MOTOR HOUSING
BSD-1605108124.A54
1605108124
|
-
|
|
|
|
2 - FIELD 230V
BSD-1604220245.A1
1604220245
|
-
|
|
|
|
2/8 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A121
1901350003
|
£1.75
|
£2.10
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A425
3600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302013.A568
1601302013
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A215
1601110003
|
-
|
|
|
|
11 - SUPPRESSION FILTER
BSD-1607328034.A141
1607328034
|
£4.26
|
£5.11
|
|
|
15 - SEAL
BSD-1600113002.A11
1600113002
|
£1.75
|
£2.10
|
|
|
16 - BRUSH HOLDER
BSD-1604336008.A182
1604336008
|
£21.52
|
£25.83
|
|
|
17 - COVER PLATE
BSD-1601037009.A15
1601037009
|
-
|
|
|
|
18 - PROFILE STRIP 3.4x7x240 MM
BSD-1601014005.A26
1601014005
|
-
|
|
|
|
19 - CONTROL LEVER
BSD-1602026058.A57
1602026058
|
-
|
|
|
|
19/8 - FELT WASHER
BSD-1600205019.A101
1600205019
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A257
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A234
1600102012
|
-
|
|
|
|
22 - GRINDING SPINDLE M14. L=101 MM
BSD-1603523090.A96
1603523090
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A128
1600108055
|
£1.75
|
£2.10
|
|
|
25 - GROMMET
BSD-1600306001.A117
1600306001
|
£2.61
|
£3.13
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A233
2600910001
|
£4.26
|
£5.11
|
|
|
28 - RUBBER RING
BSD-1600206022.A4
1600206022
|
£2.16
|
£2.59
|
|
|
29 - GUIDE PULLEY
BSD-1600502013.A52
1600502013
|
-
|
|
|
|
30 - SPRING RETAINING RING
BSD-1600119004.A95
1600119004
|
£2.80
|
£3.36
|
|
|
31 - SPIRAL SPRING
BSD-1604652015.A407
1604652015
|
£2.80
|
£3.36
|
|
|
32 - ROTARY SHAFT LIP SEAL
BSD-1600290008.A70
1600290008
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A81
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A202
1600190005
|
£1.32
|
£1.58
|
|
|
35 - TAB WASHER
BSD-1601030022.A435
1601030022
|
£1.75
|
£2.10
|
|
|
36 - RUBBER RING
BSD-1600206015.A86
1600206015
|
£2.16
|
£2.59
|
|
|
40 - SPRING WASHER dia32.3xdia43.5x0.6 MM
BSD-1600150009.A53
1600150009
|
£2.80
|
£3.36
|
|
|
41 - SEALING CAP
BSD-1605500089.A44
1605500089
|
-
|
|
|
|
42 - HANDLE
BSD-1605132093.A67
1605132093
|
-
|
|
|
|
44 - FACEPLATE
BSD-1600120070.A46
1600120070
|
-
|
|
|
|
45 - HOLDING BRACKET
BSD-1601331032.A123
1601331032
|
-
|
|
|
|
50 - GROOVE BALL BEARING 6203-2 Z DIN 625
BSD-1900905227.A24
1900905227
|
-
|
|
|
|
52 - GROOVE BALL BEARING 6203-TH/C3 DIN 625
BSD-1900900413.A40
1900900413
|
-
|
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A17
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A265
2910021118
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A35
2910211006
|
£1.75
|
£2.10
|
|
|
56 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A151
2916011005
|
£1.75
|
£2.10
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A310
2910011157
|
-
|
|
|
|
58 - TAPPING SCREW DIN 7971-B 3.9x19
BSD-2910211220.A206
2910211220
|
-
|
|
|
|
59 - SCREW B 4.8x45 MM
BSD-3603415560.A196
3603415560
|
£1.75
|
£2.10
|
|
|
60 - TAPPING SCREW DIN 7971-ST4.8x25-F
BSD-2910211036.A7
2910211036
|
£1.75
|
£2.10
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A378
2910011162
|
£1.75
|
£2.10
|
|
|
63 - TAPPING SCREW B4.8x85 MM
BSD-1603429001.A45
1603429001
|
-
|
|
|
|
66 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A568
2910211018
|
£1.75
|
£2.10
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A441
2910211011
|
£1.75
|
£2.10
|
|
|
100 - GROOVED RING
BSD-1600390011.A45
1600390011
|
-
|
|
|
|
651/10 - OFFSET SCREWDRIVER DIN 911 SW10
BSD-1907950009.A83
1907950009
|
£21.68
|
£26.01
|
|
|
651/11 - CLAMPING-FLANGE
BSD-1605703137.A14
1605703137
|
-
|
|
|
|
651/12 - ROUND NUT WITH 2 HOLES
BSD-1619P09976.A23
1619P09976
|
£2.16
|
£2.59
|
|
|
651/13 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A284
1907950007
|
£5.30
|
£6.36
|
|
|
651/15 - CONICAL SPRING WASHER
BSD-2605703022.A6
2605703022
|
£54.42
|
£65.30
|
|
|
651/16 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A488
2607950004
|
£1.75
|
£2.10
|
|
|
652 - PROTECTIVE COVER dia 300 MM
BSD-2605510079.A13
2605510079
|
-
|
|
|
|
652/20 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x18-8.8
BSD-2910141240.A86
2910141240
|
£1.32
|
£1.58
|
|
|
653 - GUIDE BLOCK
BSD-1608190002.A8
1608190002
|
-
|
|
|
|
653/1 - ROUND-HEAD BOLT DIN 603-M 8x25
BSD-2910281244.A38
2910281244
|
-
|
|
|
|
653/2 - WING NUT DIN 315-M8-GT-C
BSD-2915191007.A206
2915191007
|
£3.72
|
£4.47
|
|
|
653/3 - PLAIN WASHER DIN 315-M8-GT-C
BSD-2600100041.A221
2600100041
|
£1.75
|
£2.10
|
|
|
653/4 - COMPRESSION SPRING
BSD-1604643003.A31
1604643003
|
£6.52
|
£7.83
|
|
|
700 - PARTS SET
BSD-1607000149.A1
1607000149
|
-
|
|
|
|
702 - SUCTION HOOD dia 300 MM (12)
BSD-1605510215.A3
1605510215
|
£87.49
|
£104.99
|
|
|
702 - UNION dia32.3xdia34.9x75 MM
BSD-1600309009.A10
1600309009
|
-
|
|
|
|
702/10 - WING NUT DIN 315-M8-GT-C
BSD-2915191007.A207
2915191007
|
£3.72
|
£4.47
|
|
|
702/11 - PLAIN WASHER DIN 125-A 8.4-ST
BSD-2916011016.A66
2916011016
|
£1.75
|
£2.10
|
|
|
702/20 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x18-8.8
BSD-2910141240.A78
2910141240
|
£1.32
|
£1.58
|
|
|
703 - PARTS SET
BSD-1607000140.A110
1607000140
|
-
|
|
|
|
703/11 - HEX SCREW M14x16x1.5 MM
BSD-2603450007.A409
2603450007
|
£5.58
|
£6.70
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A123
1607014103
|
£14.91
|
£17.89
|
|
|
801 - CONNECTING CABLE
BSD-1604440004.A53
1604440004
|
-
|
|
|
|
801/2 - TERMINAL LUG
BSD-1601353003.A18
1601353003
|
-
|
|
|
|
802 - CROWN GEAR Z=62. M8
BSD-1606333206.A19
1606333206
|
-
|
|
|
|
803 - BEVEL GEAR Z=13. M12
BSD-1606333185.A8
1606333185
|
-
|
|
|
|
806 - ARMATURE 220V
BSD-1604012054.A17
1604012054
|
-
|
|
|
|
807 - PARTS SET
BSD-1607000913.A5
1607000913
|
-
|
|
|
|
813 - PARTS SET
BSD-1607000161.A48
1607000161
|
-
|
|
|
|
817 - BEARING FLANGE
BSD-1607000229.A137
1607000229
|
-
|
|
|
|
817/029 - O-RING 79.0x1.78 MM
BSD-1600210033.A702
1600210033
|
£1.75
|
£2.10
|
|
|
818 - PROFILE STRIP 3.4x7x240 MM
BSD-1601014005.A14
1601014005
|
-
|
|
|
|
831 - ON-OFF SWITCH
BSD-1607200097.A2
1607200097
|
-
|
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A259
1607000228
|
£23.86
|
£28.63
|
|
|
835/020 - END SPLICE
BSD-3604477009.A45
3604477009
|
£2.61
|
£3.13
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3787
160111A3H3
|
£2.61
|
£3.13
|
|
