2 - BRUSH HOLDER
BSD-1604336008.A43
1604336008
|
£21.52
|
£25.83
|
|
|
3 - FIELD 115V
BSD-1604220099.A3
1604220099
|
-
|
|
|
|
6 - SPIRAL SPRING
BSD-1604652015.A274
1604652015
|
£2.80
|
£3.36
|
|
|
8 - SEALING CAP
BSD-1605500089.A274
1605500089
|
-
|
|
|
|
9 - HANDLE
BSD-1605132083.A1
1605132083
|
-
|
|
|
|
11 - INSULATING PLATE 20x20x50 MM
BSD-1602381006.A54
1602381006
|
£1.75
|
£2.10
|
|
|
12 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A501
1600703009
|
£5.58
|
£6.70
|
|
|
13 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.5mm H07RN-F
BSD-1604460203.A9
1604460203
|
£33.74
|
£40.49
|
|
|
14 - SUPPRESSION FILTER
BSD-1607328034.A438
1607328034
|
£4.26
|
£5.11
|
|
|
15 - FASTENING CLAMP
BSD-1601302013.A182
1601302013
|
£1.75
|
£2.10
|
|
|
17 - COVER PLATE
BSD-1601037006.A62
1601037006
|
-
|
|
|
|
19/00/08 - FELT WASHER
BSD-1600205019.A185
1600205019
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A151
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A94
1600102012
|
-
|
|
|
|
22 - GRINDING SPINDLE M14x1.5 MM
BSD-1603523032.A234
1603523032
|
£37.27
|
£44.72
|
|
|
23 - SEALING DISK
BSD-1600108055.A158
1600108055
|
£1.75
|
£2.10
|
|
|
24 - BEARING FLANGE
BSD-1607000229.A4
1607000229
|
-
|
|
|
|
25 - GROMMET
BSD-1600306001.A368
1600306001
|
£2.61
|
£3.13
|
|
|
26 - MOTOR HOUSING
BSD-1605806324.A1
1605806324
|
-
|
|
|
|
27 - NEEDLE BEARING dia22x11.3 MM
BSD-1600910010.A117
1600910010
|
£45.67
|
£54.80
|
|
|
28 - RUBBER RING 10 MM
BSD-1600206014.A91
1600206014
|
£1.75
|
£2.10
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600502007.A75
1600502007
|
-
|
|
|
|
30 - RETAINING RING
BSD-1600116002.A22
1600116002
|
-
|
|
|
|
31 - NAMEPLATE
BSD-160111A3H3.A880
160111A3H3
|
£2.61
|
£3.13
|
|
|
32 - ROTARY SHAFT LIP SEAL
BSD-1600290008.A165
1600290008
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A240
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A43
1600190005
|
£1.32
|
£1.58
|
|
|
35 - TAB WASHER
BSD-1601030022.A227
1601030022
|
£1.75
|
£2.10
|
|
|
36 - RUBBER BUSHING
BSD-1600502006.A74
1600502006
|
£1.75
|
£2.10
|
|
|
38 - MANUFACTURER'S NAMEPLATE
BSD-1601110062.A0
1601110062
|
-
|
|
|
|
39 - REFERENCE PLATE
BSD-1601110358.A7
1601110358
|
-
|
|
|
|
43 - REFERENCE PLATE
BSD-1601110058.A272
1601110058
|
£1.75
|
£2.10
|
|
|
44 - THREADED RING
BSD-1603344051.A7
1603344051
|
-
|
|
|
|
45 - RETAINING RING
BSD-1600116004.A23
1600116004
|
-
|
|
|
|
48 - STORAGE LEDGE
BSD-1608039008.A8
1608039008
|
-
|
|
|
|
50 - GROOVE BALL BEARING 6203-2 Z DIN 625
BSD-1900905227.A175
1900905227
|
-
|
|
|
|
51 - RETAINING RING dia22 MM
BSD-2916620011.A375
2916620011
|
£1.75
|
£2.10
|
|
|
52 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A58
1900905234
|
£31.64
|
£37.97
|
|
|
52 - GROOVE BALL BEARING 17x35x10
BSD-1600900020.A123
1600900020
|
-
|
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A188
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1075
2910021118
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A702
2910211006
|
£1.75
|
£2.10
|
|
|
55 - SOCKET HEAD CAP SCREW DIN 84-AM3x8-8.8
BSD-2910021050.A257
2910021050
|
£1.75
|
£2.10
|
|
|
56 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A396
2916060003
|
£1.32
|
£1.58
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-8.8
BSD-2910021157.A48
2910021157
|
£1.32
|
£1.58
|
|
|
58 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A574
2915011005
|
£1.75
|
£2.10
|
|
|
59 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A313
1613435009
|
£1.75
|
£2.10
|
|
|
60 - TAPPING SCREW DIN 7971-ST4.8x25-F
BSD-2910211036.A185
2910211036
|
£1.75
|
£2.10
|
|
|
60/01 - SOCKET HEAD CAP SCREW DIN 84-AM5x16-8.8
BSD-2910021158.A22
2910021158
|
£1.32
|
£1.58
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-8.8
BSD-2910021162.A47
2910021162
|
-
|
|
|
|
63 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A92
1603435006
|
-
|
|
|
|
63 - SOCKET HEAD CAP SCREW DIN 84-BM5x82
BSD-1603410001.A87
1603410001
|
-
|
|
|
|
64 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A322
2916680006
|
-
|
|
|
|
65 - SPRING WASHER DIN 137-A4
BSD-1600150006.A300
1600150006
|
-
|
|
|
|
65/01 - TAB WASHER
BSD-1611331007.A17
1611331007
|
£1.32
|
£1.58
|
|
|
66 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A633
2910021122
|
£2.16
|
£2.59
|
|
|
68 - SOCKET HEAD CAP SCREW DIN 84-AM6x15-8.8
BSD-2910021196.A6
2910021196
|
-
|
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A199
2910211011
|
£1.75
|
£2.10
|
|
|
71 - SHIM 0.05 MM
BSD-1600101650.A82
1600101650
|
£2.61
|
£3.13
|
|
|
72 - SHIM 0.1 MM
BSD-1600101648.A82
1600101648
|
£1.75
|
£2.10
|
|
|
73 - SHIM 0.15 MM
BSD-1600101649.A7
1600101649
|
-
|
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A152
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A543
1602025030
|
£18.96
|
£22.75
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW19
BSD-1907950511.A42
1907950511
|
£11.78
|
£14.13
|
|
|
652 - PROTECTIVE COVER dia230 MM (9)
BSD-1605510082.A19
1605510082
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A143
1607014103
|
£14.91
|
£17.89
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-1605108902.A92
1605108902
|
-
|
|
|
|
804 - BEVEL GEAR Z=61
BSD-1606333158.A5
1606333158
|
-
|
|
|
|
808 - ARMATURE 115V
BSD-1604011242.A0
1604011242
|
-
|
|
|
|
809 - SWITCH
BSD-1607200064.A38
1607200064
|
£40.80
|
£48.96
|
|
|
809/00/04 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A471
2910091118
|
£1.75
|
£2.10
|
|
