2 - FIELD 220-240V
BSD-2604220456.A41
2604220456
|
£18.96
|
£22.75
|
|
|
3/60 - FAN
BSD-2606610024.A7
2606610024
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200358.A19
2607200358
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460417.A4
1604460417
|
£9.97
|
£11.96
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A141
2600703007
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A556
2601035001
|
£1.84
|
£2.21
|
|
|
9 - STICKER
BSD-2601119325.A2
2601119325
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A694
1607328028
|
£5.57
|
£6.68
|
|
|
13 - NEEDLE BEARING
BSD-2600910005.A92
2600910005
|
-
|
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-1610905011.A24
1610905011
|
£14.91
|
£17.89
|
|
|
16 - CARB BRUSH HOLD W-SUPR
BSD-2604465085.A28
2604465085
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A499
2603410001
|
£1.84
|
£2.21
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1329
2603490022
|
£1.84
|
£2.21
|
|
|
25 - TOOTHED BELT WHEEL Z=27
BSD-1606625030.A19
1606625030
|
-
|
|
|
|
26 - TOOTHED BELT Z=59
BSD-1604736006.A4
1604736006
|
£10.61
|
£12.73
|
|
|
27 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A1218
2915011007
|
-
|
|
|
|
28 - ROLLER
BSD-1606625032.A19
1606625032
|
-
|
|
|
|
29 - SQUARE NUT M6
BSD-2603320004.A11
2603320004
|
£1.84
|
£2.21
|
|
|
30 - PLAIN WASHER DIN 433-6.4-ST 50
BSD-2916011013.A68
2916011013
|
£1.75
|
£2.10
|
|
|
34 - COVERING HOOD
BSD-1605510159.A1
1605510159
|
-
|
|
|
|
35 - FELT STRIP
BSD-1601005005.A9
1601005005
|
-
|
|
|
|
36 - SLIDE PLATE
BSD-1601098007.A11
1601098007
|
-
|
|
|
|
37 - ROLLER
BSD-1606625031.A1
1606625031
|
-
|
|
|
|
37/20 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A540
2600917003
|
£2.94
|
£3.53
|
|
|
38 - AXLE
BSD-1603521028.A18
1603521028
|
-
|
|
|
|
39 - BEARING BRACKET
BSD-1605807014.A19
1605807014
|
-
|
|
|
|
40 - TENSIONING LEVER
BSD-1602098007.A8
1602098007
|
-
|
|
|
|
41 - BASE
BSD-1608005005.A2
1608005005
|
-
|
|
|
|
42 - WING NUT
BSD-2603339005.A60
2603339005
|
£2.94
|
£3.53
|
|
|
43 - COMPRESSION SPRING
BSD-1604619018.A16
1604619018
|
-
|
|
|
|
44 - COMPRESSION SPRING
BSD-1604612006.A5
1604612006
|
-
|
|
|
|
45 - BUTTON-HEAD RIVET DIN 660-5x10-Ms
BSD-2917030709.A13
2917030709
|
-
|
|
|
|
46 - LOCKING WASHER
BSD-1600146001.A72
1600146001
|
£1.75
|
£2.10
|
|
|
48 - TORX OVAL-HEAD SCREW 3x8
BSD-2603490016.A5
2603490016
|
£1.75
|
£2.10
|
|
|
49 - TAPPING SCREW DIN 7971-BZ3.9x9.5
BSD-2910211017.A304
2910211017
|
-
|
|
|
|
52 - CERAMIC PLATE
BSD-2601010059.A32
2601010059
|
£5.87
|
£7.04
|
|
|
54 - SPRING WASHER DIN 137-A6-FST
BSD-2916061007.A13
2916061007
|
-
|
|
|
|
55 - RUBBER BUFFER
BSD-1603100036.A85
1603100036
|
£1.84
|
£2.21
|
|
|
56 - CONNECTING CABLE L = 298 MM
BSD-2604448032.A18
2604448032
|
-
|
|
|
|
60 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A890
2600910001
|
£4.48
|
£5.37
|
|
|
61 - GROOVE BALL BEARING 8x22x7
BSD-1900905041.A17
1900905041
|
£13.78
|
£16.54
|
|
|
62 - TAB WASHER
BSD-1600190016.A3
1600190016
|
-
|
|
|
|
63 - TOOTHED BELT WHEEL Z=19
BSD-1606625026.A50
1606625026
|
-
|
|
|
|
65 - DAMPING PLATE
BSD-2601022000.A518
2601022000
|
£1.75
|
£2.10
|
|
|
67 - SHIM 0.2 MM
BSD-2600100621.A23
2600100621
|
£1.84
|
£2.21
|
|
|
69 - FELT DISC
BSD-2600108008.A3
2600108008
|
-
|
|
|
|
70 - HEX NUT M 6
BSD-2603300003.A23
2603300003
|
-
|
|
|
|
71 - CONNECTING CABLE
BSD-2604448150.A17
2604448150
|
-
|
|
|
|
655 - FITTING
BSD-2605702012.A38
2605702012
|
-
|
|
|
|
700 - FITTING dia 25x35 MM
BSD-1600499005.A101
1600499005
|
£6.99
|
£8.39
|
|
|
701 - WIDTH STOP 45°
BSD-2607001079.A19
2607001079
|
£22.96
|
£27.55
|
|
|
701/10 - O-RING 4.0x1.5 MM
BSD-1610210043.A147
1610210043
|
£1.84
|
£2.21
|
|
|
701/20 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A77
2916011014
|
£1.84
|
£2.21
|
|
|
701/30 - WING SCREW M 6x16 MM
BSD-2603480003.A127
2603480003
|
£2.74
|
£3.29
|
|
|
701/40 - STOP BRACKET
BSD-1601332018.A73
1601332018
|
£3.91
|
£4.69
|
|
|
701/50 - ROUND-HEAD BOLT DIN 603-M6x25
BSD-2910281203.A40
2910281203
|
£2.74
|
£3.29
|
|
|
701/60 - WING NUT M6
BSD-1603339006.A89
1603339006
|
£2.64
|
£3.17
|
|
|
701/70 - ROUND-HEAD BOLT M6x15 DIN 603
BSD-2910281196.A208
2910281196
|
-
|
|
|
|
701/80 - STOP PLATE
BSD-1608000092.A2
1608000092
|
-
|
|
|
|
701/90 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A94
2916011010
|
£1.84
|
£2.21
|
|
|
701/100 - TUBULAR RIVET B 4x0.5x15 DIN 734
BSD-2917190492.A6
2917190492
|
-
|
|
|
|
701/110 - STOP BRACKET
BSD-1608000093.A47
1608000093
|
-
|
|
|
|
702 - PARALLEL-GUIDE
BSD-2607000102.A14
2607000102
|
£22.04
|
£26.45
|
|
|
702/10 - STOP BRACKET
BSD-2608005015.A16
2608005015
|
£11.30
|
£13.56
|
|
|
702/20 - STOP BRACKET
BSD-1601332018.A74
1601332018
|
£3.91
|
£4.69
|
|
|
702/30 - WING NUT M6
BSD-1603339006.A88
1603339006
|
£2.64
|
£3.17
|
|
|
702/40 - WING SCREW M 6x16 MM
BSD-2603480003.A128
2603480003
|
£2.74
|
£3.29
|
|
|
702/50 - ROUND-HEAD BOLT M6x15 DIN 603
BSD-2910281196.A207
2910281196
|
-
|
|
|
|
702/60 - O-RING 4.0x1.5 MM
BSD-1610210043.A146
1610210043
|
£1.84
|
£2.21
|
|
|
702/70 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A78
2916011014
|
£1.84
|
£2.21
|
|
|
703 - SANDING BELT SET KORN 40
BSD-1608604198.A9
1608604198
|
-
|
|
|
|
709 - ADJUSTABLE SCREW CLAMP
BSD-1607960006.A2
1607960006
|
-
|
|
|
|
731 - HANDLE M6x15 MM
BSD-2602026046.A4
2602026046
|
-
|
|
|
|
754 - DUST BAG
BSD-1605411026.A9
1605411026
|
£16.52
|
£19.83
|
|
|
754/1 - DUST BAG
BSD-2605411009.A14
2605411009
|
£12.24
|
£14.69
|
|
|
801 - MOTOR HOUSING
BSD-2605104804.A2
2605104804
|
-
|
|
|
|
810 - CARBON BRUSH
BSD-1607014117.A52
1607014117
|
£10.61
|
£12.73
|
|
|
830 - ARMATURE 220-230V
BSD-1604010306.A3
1604010306
|
-
|
|
|
|
858 - CROWN GEAR Z=45
BSD-2606333900.A13
2606333900
|
£21.52
|
£25.83
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1353
160111A3H3
|
£2.74
|
£3.29
|
|
