2 - FIELD 220-240V
BSD-2604220456.A49
2604220456
|
£18.96
|
£22.75
|
|
|
3/60 - FAN
BSD-2606610024.A18
2606610024
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200365.A38
2607200365
|
-
|
|
|
|
5 - POWER SUPPLY CORD I/BR 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460277.A6
2604460277
|
£12.04
|
£14.45
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A131
2600703007
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A546
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601119324.A0
2601119324
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A699
1607328028
|
£5.30
|
£6.36
|
|
|
13 - NEEDLE BEARING
BSD-2600910005.A83
2600910005
|
-
|
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-1610905011.A15
1610905011
|
£14.91
|
£17.89
|
|
|
16 - CARB BRUSH HOLD W-SUPR
BSD-2604465085.A15
2604465085
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A504
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1339
2603490022
|
£1.75
|
£2.10
|
|
|
25 - TOOTHED BELT WHEEL Z=27
BSD-1606625030.A6
1606625030
|
-
|
|
|
|
26 - TOOTHED BELT Z=59
BSD-1604736006.A10
1604736006
|
£10.10
|
£12.12
|
|
|
27 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A1229
2915011007
|
-
|
|
|
|
28 - ROLLER
BSD-1606625032.A7
1606625032
|
-
|
|
|
|
29 - SQUARE NUT M6
BSD-2603320004.A16
2603320004
|
£1.75
|
£2.10
|
|
|
30 - PLAIN WASHER 8-ST
BSD-2916021013.A7
2916021013
|
£1.75
|
£2.10
|
|
|
34 - COVERING HOOD
BSD-1605510159.A14
1605510159
|
-
|
|
|
|
35 - FELT STRIP
BSD-1601005005.A16
1601005005
|
-
|
|
|
|
36 - SLIDE PLATE
BSD-1601098007.A4
1601098007
|
-
|
|
|
|
37 - ROLLER
BSD-1606625031.A13
1606625031
|
-
|
|
|
|
37/20 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A549
2600917003
|
£2.80
|
£3.36
|
|
|
38 - AXLE
BSD-1603521028.A10
1603521028
|
-
|
|
|
|
39 - BEARING BRACKET
BSD-1605807014.A6
1605807014
|
-
|
|
|
|
40 - TENSIONING LEVER
BSD-1602098007.A15
1602098007
|
-
|
|
|
|
41 - BASE
BSD-1608005005.A11
1608005005
|
-
|
|
|
|
42 - WING NUT
BSD-2603339005.A55
2603339005
|
£2.80
|
£3.36
|
|
|
43 - COMPRESSION SPRING
BSD-1604619018.A10
1604619018
|
-
|
|
|
|
44 - COMPRESSION SPRING
BSD-1604612006.A11
1604612006
|
-
|
|
|
|
45 - BUTTON-HEAD RIVET DIN 660-5x10-Ms
BSD-2917030709.A7
2917030709
|
-
|
|
|
|
46 - LOCKING WASHER
BSD-1600146001.A65
1600146001
|
£1.75
|
£2.10
|
|
|
48 - TORX OVAL-HEAD SCREW 3x8
BSD-2603490016.A11
2603490016
|
£1.75
|
£2.10
|
|
|
52 - CERAMIC PLATE
BSD-2601010059.A23
2601010059
|
£5.58
|
£6.70
|
|
|
54 - SPRING WASHER DIN 137-A6-FST
BSD-2916061007.A19
2916061007
|
-
|
|
|
|
55 - RUBBER BUFFER
BSD-1603100036.A78
1603100036
|
£1.75
|
£2.10
|
|
|
56 - CONNECTING CABLE L = 298 MM
BSD-2604448032.A26
2604448032
|
-
|
|
|
|
60 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A899
2600910001
|
£4.26
|
£5.11
|
|
|
61 - GROOVE BALL BEARING 8x22x7
BSD-1900905041.A27
1900905041
|
£13.12
|
£15.75
|
|
|
62 - TAB WASHER
BSD-1600190016.A10
1600190016
|
-
|
|
|
|
63 - TOOTHED BELT WHEEL Z=19
BSD-1606625026.A63
1606625026
|
-
|
|
|
|
65 - DAMPING PLATE
BSD-2601022000.A527
2601022000
|
£1.75
|
£2.10
|
|
|
67 - SHIM 0.2 MM
BSD-2600100621.A13
2600100621
|
£1.75
|
£2.10
|
|
|
69 - FELT DISC
BSD-2600108008.A13
2600108008
|
£1.32
|
£1.58
|
|
|
70 - HEX NUT M 6
BSD-2603300003.A17
2603300003
|
-
|
|
|
|
71 - CONNECTING CABLE
BSD-2604448150.A11
2604448150
|
-
|
|
|
|
654 - DUST CHAMBER
BSD-2605411129.A23
2605411129
|
£13.12
|
£15.75
|
|
|
655 - FITTING
BSD-2605702038.A21
2605702038
|
£5.30
|
£6.36
|
|
|
700 - FITTING dia 25x35 MM
BSD-1600499005.A94
1600499005
|
£3.49
|
£4.19
|
|
|
701 - WIDTH STOP 45°
BSD-2607001079.A14
2607001079
|
£21.87
|
£26.24
|
|
|
701/10 - O-RING 4.0x1.5 MM
BSD-1610210043.A165
1610210043
|
£1.75
|
£2.10
|
|
|
701/20 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A96
2916011014
|
£1.75
|
£2.10
|
|
|
701/30 - WING SCREW M 6x16 MM
BSD-2603480003.A113
2603480003
|
£2.61
|
£3.13
|
|
|
701/40 - STOP BRACKET
BSD-1601332018.A59
1601332018
|
£3.72
|
£4.47
|
|
|
701/50 - ROUND-HEAD BOLT DIN 603-M6x25
BSD-2910281203.A30
2910281203
|
£2.61
|
£3.13
|
|
|
701/60 - WING NUT M6
BSD-1603339006.A101
1603339006
|
£2.52
|
£3.02
|
|
|
701/70 - ROUND-HEAD BOLT M6x15 DIN 603
BSD-2910281196.A228
2910281196
|
-
|
|
|
|
701/80 - STOP PLATE
BSD-1608000092.A14
1608000092
|
-
|
|
|
|
701/90 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A84
2916011010
|
£1.75
|
£2.10
|
|
|
701/100 - TUBULAR RIVET B 4x0.5x15 DIN 734
BSD-2917190492.A14
2917190492
|
-
|
|
|
|
701/110 - STOP BRACKET
BSD-1608000093.A35
1608000093
|
-
|
|
|
|
702 - PARALLEL-GUIDE
BSD-2607000102.A19
2607000102
|
£20.99
|
£25.19
|
|
|
702/10 - STOP BRACKET
BSD-2608005015.A25
2608005015
|
£11.30
|
£13.56
|
|
|
702/20 - STOP BRACKET
BSD-1601332018.A60
1601332018
|
£3.72
|
£4.47
|
|
|
702/30 - WING NUT M6
BSD-1603339006.A100
1603339006
|
£2.52
|
£3.02
|
|
|
702/40 - WING SCREW M 6x16 MM
BSD-2603480003.A114
2603480003
|
£2.61
|
£3.13
|
|
|
702/50 - ROUND-HEAD BOLT M6x15 DIN 603
BSD-2910281196.A227
2910281196
|
-
|
|
|
|
702/60 - O-RING 4.0x1.5 MM
BSD-1610210043.A164
1610210043
|
£1.75
|
£2.10
|
|
|
702/70 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A97
2916011014
|
£1.75
|
£2.10
|
|
|
731 - HANDLE M6x15 MM
BSD-2602026046.A11
2602026046
|
-
|
|
|
|
801 - MOTOR HOUSING
BSD-2605104804.A10
2605104804
|
-
|
|
|
|
810 - CARBON BRUSH
BSD-1607014117.A45
1607014117
|
£10.10
|
£12.12
|
|
|
830 - ARMATURE 220-230V
BSD-1604010306.A8
1604010306
|
-
|
|
|
|
858 - CROWN GEAR Z=45
BSD-2606333900.A4
2606333900
|
£21.52
|
£25.83
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1360
160111A3H3
|
£2.61
|
£3.13
|
|
