1 - MOTOR HOUSING
BSD-3605102077.A32
3605102077
|
£179.37
|
£215.24
|
|
|
2 - STATOR
BSD-3604229126.A4
3604229126
|
£410.78
|
£492.94
|
|
|
3 - ROTOR WITHOUT WINDING
BSD-3604080058.A10
3604080058
|
£218.41
|
£262.09
|
|
|
3/30 - FAN
BSD-3606610010.A63
3606610010
|
£4.26
|
£5.11
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600209003.A72
1600209003
|
£8.13
|
£9.76
|
|
|
6 - GROOVE BALL BEARING
BSD-3600905015.A107
3600905015
|
£16.41
|
£19.69
|
|
|
8 - GROOVE BALL BEARING 7x22x7
BSD-3600905147.A89
3600905147
|
£13.12
|
£15.75
|
|
|
9 - THREAD-FORMING TAP. SCREW
BSD-2914461403.A13
2914461403
|
£2.16
|
£2.59
|
|
|
10 - SPRING WASHER dia4.2 MM
BSD-3600150006.A880
3600150006
|
£2.61
|
£3.13
|
|
|
11 - CLAMPING SADDLE
BSD-3601321001.A480
3601321001
|
£3.72
|
£4.47
|
|
|
13 - O-RING 22.0x1.5 MM
BSD-3600210016.A59
3600210016
|
£1.75
|
£2.10
|
|
|
14 - SEAL RING
BSD-1600209006.A35
1600209006
|
£2.80
|
£3.36
|
|
|
15 - SET SCREW
BSD-1603402002.A134
1603402002
|
£1.75
|
£2.10
|
|
|
16 - O-RING 28x2 MM
BSD-1900210127.A41
1900210127
|
£5.30
|
£6.36
|
|
|
17 - DISC SPRING
BSD-3600550003.A2
3600550003
|
£7.36
|
£8.83
|
|
|
18 - SHIM WASHER
BSD-3600101026.A11
3600101026
|
£13.12
|
£15.75
|
|
|
19 - SPRING RETAINING RING DIN 472-28x1.2 MM
BSD-2916660011.A23
2916660011
|
£1.75
|
£2.10
|
|
|
20 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x18-8.8
BSD-2910141160.A53
2910141160
|
£2.16
|
£2.59
|
|
|
30 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x18-8.8
BSD-2910141160.A54
2910141160
|
£2.16
|
£2.59
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1309
2910021118
|
£1.75
|
£2.10
|
|
|
61 - HANDLE
BSD-3605132078.A9
3605132078
|
£40.80
|
£48.96
|
|
|
62 - SCREW 4x16
BSD-2603490022.A1170
2603490022
|
£1.75
|
£2.10
|
|
|
63 - SEALING PLATE
BSD-3600054005.A11
3600054005
|
£2.61
|
£3.13
|
|
|
67 - STRIP TERMINAL
BSD-1901091110.A32
1901091110
|
£1.75
|
£2.10
|
|
|
75 - SWITCH
BSD-3607200055.A31
3607200055
|
£93.88
|
£112.65
|
|
|
80 - GROMMET dia12.8xdia13.5x100 MM
BSD-3600703003.A32
3600703003
|
£5.30
|
£6.36
|
|
|
81 - FASTENING CLAMP
BSD-3601303004.A177
3601303004
|
£5.58
|
£6.70
|
|
|
82 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2007
2910211019
|
£1.75
|
£2.10
|
|
|
83 - ELEC. CABLE W/CONNECTION
BSD-3604462017.A36
3604462017
|
£54.42
|
£65.30
|
|
|
95 - NAMEPLATE
BSD-3601106053.A483
3601106053
|
£5.30
|
£6.36
|
|
|
97 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A485
3603133001
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1190
3601119236
|
£3.72
|
£4.47
|
|
|
100 - GEAR HOUSING
BSD-3605106070.A11
3605106070
|
£251.67
|
£302.00
|
|
|
101 - BEARING FLANGE
BSD-3605805019.A18
3605805019
|
£120.11
|
£144.13
|
|
|
102 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A1012
2600910001
|
£4.26
|
£5.11
|
|
|
103 - GROOVE BALL BEARING
BSD-3600905035.A17
3600905035
|
£21.52
|
£25.83
|
|
|
104 - GRINDING SPINDLE M14
BSD-3603523003.A1
3603523003
|
£102.57
|
£123.08
|
|
|
107 - THREADED RING
BSD-3603344022.A12
3603344022
|
£23.86
|
£28.63
|
|
|
108 - SHIM
BSD-3601015008.A21
3601015008
|
£5.58
|
£6.70
|
|
|
109 - O-RING 57.0x1.5 MM
BSD-1600210031.A13
1600210031
|
£1.75
|
£2.10
|
|
|
111 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x12-8.8
BSD-2910141122.A108
2910141122
|
£2.16
|
£2.59
|
|
|
115 - CROWN GEAR Z=44
BSD-3606334029.A6
3606334029
|
£48.38
|
£58.06
|
|
|
116 - BEVEL GEAR Z=15
BSD-3606333039.A1
3606333039
|
£48.38
|
£58.06
|
|
|
117 - SHIM WASHER
BSD-3600220013.A10
3600220013
|
£18.96
|
£22.75
|
|
|
118 - HEX NUT
BSD-3603300003.A12
3603300003
|
£11.30
|
£13.56
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A685
2607950511
|
£4.26
|
£5.11
|
|
|
652 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A77
1607950061
|
£5.42
|
£6.50
|
|
|
653 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A593
1602025030
|
£18.96
|
£22.75
|
|
|
751 - BACKING PAD
BSD-1608601032.A1
1608601032
|
-
|
|
|
|
752 - ROUND NUT M14
BSD-1603345004.A12
1603345004
|
£7.87
|
£9.44
|
|
|
753 - PROTECTIVE COVER dia 125 MM
BSD-1605510200.A13
1605510200
|
-
|
|
|
|
754 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A467
1907950007
|
£5.30
|
£6.36
|
|
|
801 - SWITCH KIT
BSD-3607031298.A20
3607031298
|
£81.81
|
£98.17
|
|
