6 - FLANGE DW475
BDE-930927.A114
930927
|
-
|
|
|
|
7 - FLANGE DW475
BDE-931771.A97
931771
|
£10.85
|
£13.02
|
|
|
7 - NO LONGER AVAILABLE DW474
BDE-000000-00.A113054
000000-00
|
-
|
|
|
|
8 - SCREW
BDE-933058-00.A19
933058-00
|
£1.42
|
£1.70
|
|
|
9 - WASHER
BDE-930248-00.A11
930248-00
|
£1.50
|
£1.80
|
|
|
10 - NUT
BDE-860083-03.A62
860083-03
|
£1.50
|
£1.80
|
|
|
11 - WASHER
BDE-930925.A7
930925
|
-
|
|
|
|
12 - NO LONGER AVAILABLE
BDE-000000-00.A113055
000000-00
|
-
|
|
|
|
13 - SCREW
BDE-949892-07.A78
949892-07
|
£1.42
|
£1.70
|
|
|
14 - NO LONGER AVAILABLE
BDE-000000-00.A113056
000000-00
|
-
|
|
|
|
15 - SCREW
BDE-949887-01.A7
949887-01
|
£1.42
|
£1.70
|
|
|
16 - GEARCASE COVER
BDE-947962-00.A61
947962-00
|
-
|
|
|
|
17 - NO LONGER AVAILABLE DW474
BDE-000000-00.A113057
000000-00
|
-
|
|
|
|
17 - SPINDLE DW475
BDE-578243-00.A65
578243-00
|
£19.40
|
£23.28
|
|
|
18 - NO LONGER AVAILABLE
BDE-000000-00.A113058
000000-00
|
-
|
|
|
|
19 - FLANGE
BDE-930924.A92
930924
|
-
|
|
|
|
20 - SEAL
BDE-930923.A7
930923
|
-
|
|
|
|
21 - SPACER
BDE-930922.A113
930922
|
£1.42
|
£1.70
|
|
|
22 - GEAR & PINION SA
BDE-932522.A58
932522
|
-
|
|
|
|
23 - NO LONGER AVAILABLE
BDE-000000-00.A113059
000000-00
|
-
|
|
|
|
24 - NO LONGER AVAILABLE
BDE-000000-00.A113060
000000-00
|
-
|
|
|
|
26 - NO LONGER AVAILABLE
BDE-000000-00.A113061
000000-00
|
-
|
|
|
|
28 - CLIP SA
BDE-937098-49.A64
937098-49
|
-
|
|
|
|
29 - SEAL SA
BDE-930909.A8
930909
|
-
|
|
|
|
30 - BEARING
BDE-330003-14.A13
330003-14
|
£7.85
|
£9.42
|
|
|
31 - SEAL SA
BDE-931067-00.A126
931067-00
|
£1.50
|
£1.80
|
|
|
32 - SPACER
BDE-931062.A28
931062
|
£1.50
|
£1.80
|
|
|
33 - O RING
BDE-930028-00.A36
930028-00
|
£1.50
|
£1.80
|
|
|
34 - FLANGE
BDE-931066-00.A30
931066-00
|
£1.82
|
£2.19
|
|
|
35 - SCREW
BDE-N412453.A39
N412453
|
£1.50
|
£1.80
|
|
|
36 - SPACER
BDE-N174055.A25
N174055
|
£1.50
|
£1.80
|
|
|
37 - BEARING
BDE-577745-00.A225
577745-00
|
£7.85
|
£9.42
|
|
|
38 - SLEEVE
BDE-938332-00.A137
938332-00
|
£1.50
|
£1.80
|
|
|
39 - BAFFLE
BDE-931073-00.A85
931073-00
|
£1.42
|
£1.70
|
|
|
41 - SPRING
BDE-931076-00.A20
931076-00
|
£1.42
|
£1.70
|
|
|
42 - NO LONGER AVAILABLE
BDE-000000-00.A113062
000000-00
|
-
|
|
|
|
43 - SHOCK ABSORBER
BDE-930934-00.A6
930934-00
|
£1.50
|
£1.80
|
|
|
44 - SCREW
BDE-931297-00.A35
931297-00
|
£1.50
|
£1.80
|
|
|
46 - HANDLE & COVER
BDE-N097875.A20
N097875
|
-
|
|
|
|
48 - SCREW
BDE-930284-01.A185
930284-01
|
£1.50
|
£1.80
|
|
|
51 - WRENCH PIN
BDE-938733.A156
938733
|
£7.18
|
£8.62
|
|
|
52 - WRENCH
BDE-807043.A39
807043
|
£1.50
|
£1.80
|
|
|
53 - COVER
BDE-933364-02.A68
933364-02
|
£1.50
|
£1.80
|
|
|
54 - SCREW
BDE-931469-02.A51
931469-02
|
£1.50
|
£1.80
|
|
