101 - NO LONGER AVAILABLE GB 115V
BDE-000000-00.A14320
000000-00
|
-
|
|
|
|
101 - NO LONGER AVAILABLE QS
BDE-000000-00.A14321
000000-00
|
-
|
|
|
|
101 - NO LONGER AVAILABLE GB 240V
BDE-000000-00.A14322
000000-00
|
-
|
|
|
|
102 - NO LONGER AVAILABLE QS
BDE-000000-00.A14323
000000-00
|
-
|
|
|
|
102 - NO LONGER AVAILABLE GB 115V
BDE-000000-00.A14324
000000-00
|
-
|
|
|
|
102 - NO LONGER AVAILABLE GB 240V
BDE-000000-00.A14325
000000-00
|
-
|
|
|
|
103 - SWITCH
BDE-945614-00.A20
945614-00
|
-
|
|
|
|
104 - BRUSH CUT OFF 115V GB 115V
BDE-949646-01.A13
949646-01
|
£25.05
|
£30.06
|
|
|
104 - BRUSH CUT OFF 230V QS
BDE-949646-02.A2
949646-02
|
£7.85
|
£9.42
|
|
|
104 - BRUSH CUT OFF 230V GB 240V
BDE-949646-02.A3
949646-02
|
£7.85
|
£9.42
|
|
|
105 - CABLE GB 115V
BDE-562226-07.A5
562226-07
|
£57.22
|
£68.66
|
|
|
105 - CABLE GB 240V
BDE-562226-09.A17
562226-09
|
-
|
|
|
|
106 - OUTER FLANGE
BDE-622613-02.A133
622613-02
|
£4.69
|
£5.63
|
|
|
107 - INNER FLANGE
BDE-391969-00.A40
391969-00
|
£1.82
|
£2.19
|
|
|
108 - NO LONGER AVAILABLE
BDE-000000-00.A14326
000000-00
|
-
|
|
|
|
109 - RETAINING PLATE
BDE-605415-00.A53
605415-00
|
-
|
|
|
|
110 - GUARD
BDE-944586-00.A3
944586-00
|
£3.30
|
£3.96
|
|
|
111 - RING
BDE-393576-00.A138
393576-00
|
£1.50
|
£1.80
|
|
|
112 - SCREW
BDE-562160-01.A76
562160-01
|
£1.50
|
£1.80
|
|
|
113 - GEARCASE COVER
BDE-390521-00.A3
390521-00
|
-
|
|
|
|
114 - SPINDLE
BDE-391971-00.A32
391971-00
|
-
|
|
|
|
116 - CORD PROTECTOR GB 240V
BDE-N542553.A133
N542553
|
£3.80
|
£4.56
|
|
|
116 - CORD PROTECTOR QS
BDE-N542553.A134
N542553
|
£3.80
|
£4.56
|
|
|
116 - CORD PROTECTOR GB 115V
BDE-401088-03.A16
401088-03
|
£1.50
|
£1.80
|
|
|
117 - GEAR & PINION
BDE-945295-02.A33
945295-02
|
£19.90
|
£23.88
|
|
|
118 - SCREW
BDE-562097-01.A105
562097-01
|
£1.50
|
£1.80
|
|
|
121 - SIDE HANDLE
BDE-573115-00.A93
573115-00
|
£2.78
|
£3.34
|
|
|
122 - NO LONGER AVAILABLE
BDE-000000-00.A14327
000000-00
|
-
|
|
|
|
123 - NUT
BDE-945292-00.A181
945292-00
|
£1.50
|
£1.80
|
|
|
124 - BUTTON
BDE-944574-00.A7
944574-00
|
£1.50
|
£1.80
|
|
|
125 - SPRING
BDE-562210-00.A183
562210-00
|
£1.50
|
£1.80
|
|
|
126 - SPINDLE LOCK
BDE-944571-00.A159
944571-00
|
-
|
|
|
|
127 - BEARING
BDE-605040-22.A35
605040-22
|
£4.69
|
£5.63
|
|
|
128 - SLEEVE
BDE-930275-00.A101
930275-00
|
£2.26
|
£2.71
|
|
|
130 - BUFFER
BDE-949638-01.A37
949638-01
|
£1.50
|
£1.80
|
|
|
131 - BAFFLE SA
BDE-401635-00.A10
401635-00
|
-
|
|
|
|
132 - BRUSH HOLDER SA
BDE-569925-00.A4
569925-00
|
-
|
|
|
|
133 - SPRING
BDE-562204-00.A131
562204-00
|
£1.50
|
£1.80
|
|
|
134 - FIELDCASE SA
BDE-395243-06.A3
395243-06
|
-
|
|
|
|
135 - BEARING
BDE-605040-02.A68
605040-02
|
£2.26
|
£2.71
|
|
|
136 - NO LONGER AVAILABLE
BDE-000000-00.A14328
000000-00
|
-
|
|
|
|
137 - SWITCH SUPPORT
BDE-5140000-13.A23
5140000-13
|
£1.82
|
£2.19
|
|
|
138 - WRENCH
BDE-401680-00.A125
401680-00
|
£4.69
|
£5.63
|
|
|
139 - SCREW
BDE-562097-05.A96
562097-05
|
£1.50
|
£1.80
|
|
|
140 - FLANGE
BDE-401622-01.A130
401622-01
|
£1.50
|
£1.80
|
|
|
145 - SCREW
BDE-562097-00.A79
562097-00
|
£1.50
|
£1.80
|
|
|
147 - NO LONGER AVAILABLE
BDE-000000-00.A14329
000000-00
|
-
|
|
|
|
149 - PAD
BDE-402489-00.A25
402489-00
|
£1.50
|
£1.80
|
|
|
160 - BEARING
BDE-N110359.A193
N110359
|
£3.75
|
£4.50
|
|
|
162 - LINK
BDE-611737-00.A14
611737-00
|
£1.42
|
£1.70
|
|
|
163 - BUTTON
BDE-569624-01.A60
569624-01
|
£1.50
|
£1.80
|
|
|
164 - SCREW
BDE-562097-13.A70
562097-13
|
£1.50
|
£1.80
|
|
|
165 - SERVICE KIT
BDE-610704-00.A26
610704-00
|
£17.48
|
£20.97
|
|
|
175 - PICK UP
BDE-945893-00.A11
945893-00
|
-
|
|
|
|
800 - GREASE
BDE-286436-00.A56
286436-00
|
£126.63
|
£151.96
|
|
