101 - NO LONGER AVAILABLE GB 115V XW
BDE-000000-00.A14309
000000-00
|
-
|
|
|
|
101 - NO LONGER AVAILABLE GB
BDE-000000-00.A14310
000000-00
|
-
|
|
|
|
102 - NO LONGER AVAILABLE GB
BDE-000000-00.A14311
000000-00
|
-
|
|
|
|
102 - NO LONGER AVAILABLE GB 115V XW
BDE-000000-00.A14312
000000-00
|
-
|
|
|
|
103 - SWITCH
BDE-945614-00.A19
945614-00
|
-
|
|
|
|
104 - BRUSH CUT OFF 230V GB
BDE-949646-02.A4
949646-02
|
£8.08
|
£9.70
|
|
|
104 - BRUSH CUT OFF 115V GB 115V XW
BDE-949646-01.A12
949646-01
|
£25.05
|
£30.06
|
|
|
105 - CABLE GB 115V XW
BDE-562226-07.A4
562226-07
|
£57.22
|
£68.66
|
|
|
105 - CABLE GB 240V GB
BDE-562226-09.A18
562226-09
|
-
|
|
|
|
106 - OUTER FLANGE
BDE-622613-02.A131
622613-02
|
£4.83
|
£5.80
|
|
|
107 - NO LONGER AVAILABLE <9930
BDE-000000-00.A14313
000000-00
|
-
|
|
|
|
107 - INNER FLANGE >9930
BDE-391969-00.A41
391969-00
|
£2.49
|
£2.99
|
|
|
108 - NO LONGER AVAILABLE
BDE-000000-00.A14314
000000-00
|
-
|
|
|
|
109 - RETAINING PLATE
BDE-605415-00.A56
605415-00
|
-
|
|
|
|
110 - GUARD
BDE-944586-00.A0
944586-00
|
£3.39
|
£4.07
|
|
|
111 - RING
BDE-393576-00.A139
393576-00
|
£1.66
|
£1.99
|
|
|
112 - SCREW
BDE-562160-01.A77
562160-01
|
£1.66
|
£1.99
|
|
|
113 - GEARCASE COVER
BDE-390521-00.A4
390521-00
|
-
|
|
|
|
114 - NO LONGER AVAILABLE <9930
BDE-000000-00.A14315
000000-00
|
-
|
|
|
|
114 - SPINDLE >9930
BDE-391971-00.A31
391971-00
|
-
|
|
|
|
116 - CORD PROTECTOR GB 115V XW
BDE-401088-03.A17
401088-03
|
£1.66
|
£1.99
|
|
|
116 - CORD PROTECTOR GB
BDE-N542553.A135
N542553
|
£3.92
|
£4.70
|
|
|
117 - GEAR & PINION
BDE-945295-02.A32
945295-02
|
£19.90
|
£23.88
|
|
|
118 - SCREW
BDE-562097-01.A104
562097-01
|
£1.66
|
£1.99
|
|
|
120 - SPACER <9930
BDE-945287-00.A0
945287-00
|
£1.78
|
£2.13
|
|
|
121 - SIDE HANDLE
BDE-573115-00.A92
573115-00
|
£2.87
|
£3.44
|
|
|
122 - NO LONGER AVAILABLE
BDE-000000-00.A14316
000000-00
|
-
|
|
|
|
123 - NUT
BDE-945292-00.A180
945292-00
|
£1.66
|
£1.99
|
|
|
124 - BUTTON
BDE-944574-00.A6
944574-00
|
£1.66
|
£1.99
|
|
|
125 - SPRING
BDE-562210-00.A185
562210-00
|
£1.66
|
£1.99
|
|
|
126 - SPINDLE LOCK
BDE-944571-00.A160
944571-00
|
-
|
|
|
|
127 - BEARING
BDE-605040-22.A34
605040-22
|
£4.83
|
£5.80
|
|
|
128 - SLEEVE <9930
BDE-949721-02.A24
949721-02
|
£1.66
|
£1.99
|
|
|
128 - SLEEVE >9930
BDE-930275-00.A100
930275-00
|
£2.32
|
£2.78
|
|
|
130 - BUFFER
BDE-949638-01.A38
949638-01
|
£1.66
|
£1.99
|
|
|
131 - BAFFLE SA
BDE-401635-00.A11
401635-00
|
-
|
|
|
|
132 - BRUSH HOLDER SA
BDE-569925-00.A5
569925-00
|
-
|
|
|
|
133 - SPRING
BDE-562204-00.A130
562204-00
|
£1.66
|
£1.99
|
|
|
134 - FIELDCASE SA
BDE-395243-06.A2
395243-06
|
-
|
|
|
|
135 - NO LONGER AVAILABLE <9930
BDE-000000-00.A14317
000000-00
|
-
|
|
|
|
135 - BEARING >9930
BDE-605040-02.A69
605040-02
|
£2.32
|
£2.78
|
|
|
136 - END CAP
BDE-394938-01.A8
394938-01
|
-
|
|
|
|
137 - SWITCH SUPPORT
BDE-5140000-13.A24
5140000-13
|
£1.82
|
£2.19
|
|
|
138 - WRENCH
BDE-401680-00.A124
401680-00
|
£4.83
|
£5.80
|
|
|
139 - SCREW
BDE-562097-05.A95
562097-05
|
£1.66
|
£1.99
|
|
|
140 - FLANGE
BDE-401622-01.A129
401622-01
|
£1.66
|
£1.99
|
|
|
145 - SCREW
BDE-562097-00.A78
562097-00
|
£1.66
|
£1.99
|
|
|
147 - NO LONGER AVAILABLE
BDE-000000-00.A14318
000000-00
|
-
|
|
|
|
149 - PAD
BDE-402489-00.A26
402489-00
|
£1.66
|
£1.99
|
|
|
150 - NO LONGER AVAILABLE XW
BDE-000000-00.A14319
000000-00
|
-
|
|
|
|
150 - BRUSH 220V GB
BDE-930151-00.A14
930151-00
|
£4.83
|
£5.80
|
|
|
160 - BEARING
BDE-N110359.A194
N110359
|
£3.75
|
£4.50
|
|
|
162 - LINK
BDE-611737-00.A15
611737-00
|
£1.66
|
£1.99
|
|
|
163 - BUTTON
BDE-569624-01.A59
569624-01
|
£1.66
|
£1.99
|
|
|
164 - SCREW
BDE-562097-13.A71
562097-13
|
£1.66
|
£1.99
|
|
|
165 - SERVICE KIT
BDE-610704-00.A25
610704-00
|
£17.48
|
£20.97
|
|
|
800 - GREASE
BDE-286436-00.A57
286436-00
|
£130.43
|
£156.52
|
|
