1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084620.A5
084620
|
£181.70
|
£218.04
|
|
|
1.1 - INDUCTOR WITH COIL 230 V
MAF-084618.A2
084618
|
£106.72
|
£128.07
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-204506.A0
204506
|
£56.42
|
£67.71
|
|
|
2 - ARMATURE
MAF-088224.A0
088224
|
-
|
|
|
|
3.1 - BRUSH HOLDER
MAF-063160.A2
063160
|
£10.07
|
£12.08
|
|
|
3.2 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063164.A1
063164
|
£11.43
|
£13.72
|
|
|
4 - DEPTH STOP
MAF-205801.A1
205801
|
-
|
|
|
|
4.1 - DEPTH SETTING
MAF-206027.A0
206027
|
-
|
|
|
|
4.2 - INDICATOR
MAF-204497.A4
204497
|
£12.29
|
£14.75
|
|
|
4.3 - SLIDING COVER
MAF-204511.A0
204511
|
£2.27
|
£2.72
|
|
|
4.4 - INDICATOR
MAF-204520.A1
204520
|
£9.00
|
£10.80
|
|
|
4.5 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A29
055233
|
£1.71
|
£2.05
|
|
|
4.6 - WASHER
MAF-061015.A19
061015
|
-
|
|
|
|
4.7 - PRESSURE SPRING
MAF-066043.A6
066043
|
£3.04
|
£3.65
|
|
|
4.8 - PRESSURE SPRING
MAF-006691.A3
006691
|
-
|
|
|
|
5 - LOCK
MAF-204488.A2
204488
|
£32.18
|
£38.61
|
|
|
6 - PROTECTIVE COVER
MAF-205822.A4
205822
|
-
|
|
|
|
7 - GEAR CASING
MAF-205825.A2
205825
|
-
|
|
|
|
8 - GLIDER
MAF-205817.A1
205817
|
-
|
|
|
|
9 - FRAME
MAF-205819.A2
205819
|
-
|
|
|
|
12 - HOSE CONNECTOR
MAF-206069.A4
206069
|
-
|
|
|
|
13 - BASE PLATE
MAF-206070.A2
206070
|
-
|
|
|
|
15 - HANDLE SHELL
MAF-204486.A5
204486
|
£28.81
|
£34.57
|
|
|
16 - INSULATING DISK
MAF-204492.A3
204492
|
£8.58
|
£10.30
|
|
|
17 - MOTOR COVER
MAF-204493.A5
204493
|
£23.70
|
£28.44
|
|
|
18 - SWITCH TRIGGER
MAF-204494.A4
204494
|
£12.29
|
£14.75
|
|
|
19 - HANDLE
MAF-205308.A1
205308
|
£14.92
|
£17.91
|
|
|
20 - PROTECTIVE COVER
MAF-205807.A3
205807
|
-
|
|
|
|
22 - LOCKING LEVER
MAF-204507.A3
204507
|
£10.30
|
£12.36
|
|
|
23 - LOCKING LEVER
MAF-204509.A2
204509
|
£8.07
|
£9.68
|
|
|
24 - LOCK-OFF BUTTON
MAF-204510.A2
204510
|
£11.48
|
£13.77
|
|
|
25 - FAN
MAF-204517.A1
204517
|
£12.33
|
£14.80
|
|
|
26 - AIR CONDUCTING RING
MAF-204518.A4
204518
|
£16.33
|
£19.60
|
|
|
27 - SPRING GUIDE
MAF-204519.A0
204519
|
£10.72
|
£12.87
|
|
|
28 - INSERT
MAF-205818.A3
205818
|
-
|
|
|
|
34 - STOP CLIP
MAF-204868.A3
204868
|
-
|
|
|
|
35 - HANDLE SHELL
MAF-204490.A0
204490
|
-
|
|
|
|
36 - SETTING WHEEL
MAF-203729.A2
203729
|
-
|
|
|
|
37 - HANDLE INSERT
MAF-203877.A4
203877
|
£19.14
|
£22.97
|
|
|
38 - HANDLE SHELL COVER
MAF-204513.A0
204513
|
£11.76
|
£14.11
|
|
|
41 - CLICK-IN METAL SHEET
MAF-205814.A0
205814
|
-
|
|
|
|
42 - BRAKE DRUM
MAF-201452.A2
201452
|
£13.66
|
£16.39
|
|
|
43 - BRAKE LEVER
MAF-202347.A2
202347
|
£6.25
|
£7.50
|
|
|
44 - COVER
MAF-206061.A3
206061
|
-
|
|
|
|
45 - FLANGE
MAF-204388.A5
204388
|
£16.58
|
£19.90
|
|
|
46 - SAW SHAFT
MAF-205804.A1
205804
|
-
|
|
|
|
47 - BEARING COVER
MAF-205831.A0
205831
|
-
|
|
|
|
48 - PUSH-BUTTON
MAF-204516.A1
204516
|
£30.69
|
£36.83
|
|
|
49 - BOLT
MAF-204528.A4
204528
|
-
|
|
|
|
50 - BOLT
MAF-205823.A4
205823
|
-
|
|
|
|
51 - FLANGE
MAF-205827.A3
205827
|
-
|
|
|
|
52 - SPACER SLEEVE
MAF-206065.A3
206065
|
-
|
|
|
|
56 - OVAL-HEAD SCREW
MAF-055069.A3
055069
|
£2.16
|
£2.59
|
|
|
57 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055246.A1
055246
|
-
|
|
|
|
58 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A20
055061
|
£1.71
|
£2.05
|
|
|
59 - SELF-TAPPING SCREW
MAF-055230.A9
055230
|
-
|
|
|
|
60 - OVAL-HEAD SCREW
MAF-055257.A2
055257
|
-
|
|
|
|
61 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055188.A0
055188
|
-
|
|
|
|
62 - CYLINDER-HEAD SCREW
MAF-055096.A4
055096
|
£2.11
|
£2.53
|
|
|
63 - CYLINDER-HEAD SCREW
MAF-055263.A3
055263
|
-
|
|
|
|
64 - CYLINDER-HEAD SCREW
MAF-055203.A2
055203
|
-
|
|
|
|
65 - CYLINDER-HEAD SCREW
MAF-055113.A4
055113
|
£2.64
|
£3.17
|
|
|
66 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055162.A0
055162
|
-
|
|
|
|
67 - WING SCREW
MAF-079091.A4
079091
|
-
|
|
|
|
69 - PRESSURE BIT
MAF-005293.A2
005293
|
-
|
|
|
|
70 - THREADED PIN
MAF-052016.A4
052016
|
-
|
|
|
|
71 - THREADED PIN
MAF-005284.A15
005284
|
-
|
|
|
|
72 - SPIRAL DOWEL SLEEVE
MAF-058191.A5
058191
|
-
|
|
|
|
73 - RIBBED PIN
MAF-058219.A0
058219
|
-
|
|
|
|
74 - SPIRAL DOWEL SLEEVE
MAF-058186.A5
058186
|
-
|
|
|
|
75 - FLAT-HEAD SCREW
MAF-053031.A3
053031
|
£1.72
|
£2.07
|
|
|
76 - FLAT-HEAD SCREW
MAF-005383.A13
005383
|
£2.68
|
£3.22
|
|
|
77 - THREADED PIN
MAF-052010.A8
052010
|
£3.38
|
£4.05
|
|
|
89 - WASHER
MAF-006101.A11
006101
|
-
|
|
|
|
90 - LOCKING WASHER
MAF-061069.A3
061069
|
£1.49
|
£1.79
|
|
|
91 - RETAINING RING
MAF-007163.A2
007163
|
-
|
|
|
|
92 - RETAINING RING
MAF-061021.A2
061021
|
-
|
|
|
|
93 - SEALING RING
MAF-065057.A1
065057
|
-
|
|
|
|
94 - SEALING RING
MAF-065004.A14
065004
|
-
|
|
|
|
95 - LOCKING WASHER
MAF-061135.A2
061135
|
-
|
|
|
|
96 - PRESSURE SPRING
MAF-066043.A45
066043
|
£3.04
|
£3.65
|
|
|
97 - PRESSURE SPRING
MAF-066166.A1
066166
|
£3.58
|
£4.30
|
|
|
98 - PRESSURE SPRING
MAF-066154.A2
066154
|
-
|
|
|
|
100 - PRESSURE SPRING
MAF-066096.A11
066096
|
£4.25
|
£5.10
|
|
|
101 - RETAINING RING
MAF-006192.A1
006192
|
-
|
|
|
|
102 - SHIM RING
MAF-061141.A4
061141
|
-
|
|
|
|
103 - RETRACTING SPRING
MAF-066092.A6
066092
|
-
|
|
|
|
104 - CUP SPRING
MAF-006693.A4
006693
|
-
|
|
|
|
105 - FEDERSCHEIBE
MAF-061132.A7
061132
|
-
|
|
|
|
106 - SHIM RING
MAF-006160.A21
006160
|
£1.65
|
£1.98
|
|
|
107 - WASHER
MAF-061167.A2
061167
|
£51.32
|
£61.59
|
|
|
108 - GROOVED BALL BEARING
MAF-006282.A3
006282
|
£14.68
|
£17.62
|
|
|
110 - GROOVED BALL BEARING
MAF-006280.A3
006280
|
£13.65
|
£16.38
|
|
|
111 - CONTROL MODULE
MAF-077671.A4
077671
|
£70.80
|
£84.96
|
|
|
112 - CABLE PROTECTING SLEEVE
MAF-086064.A6
086064
|
£3.37
|
£4.04
|
|
|
113 - CABLE CLAMP
MAF-205830.A1
205830
|
-
|
|
|
|
114 - 2-POLE SWITCH
MAF-087851.A2
087851
|
£18.18
|
£21.82
|
|
|
115 - MAINS CABLE 4 M (13.1 FT)
MAF-087323.A10
087323
|
£39.41
|
£47.29
|
|
|
116 - BRAKE LINING
MAF-202429.A0
202429
|
-
|
|
|
|
117 - PRESSURE BIT
MAF-202378.A8
202378
|
-
|
|
|
|
118 - STOP BUFFER
MAF-204009.A4
204009
|
-
|
|
|
|
119 - PRESSURE BIT
MAF-206122.A0
206122
|
-
|
|
|
|
122 - STEEL BALL
MAF-062104.A3
062104
|
-
|
|
|
|
123 - HOOK-AND-LOOP FASTENER BELT
MAF-205049.A2
205049
|
£5.39
|
£6.47
|
|
|
500 - COMBINATION SCREW DRIVER
MAF-093005.A1
093005
|
-
|
|
|
|
501 - POSITION INDICATO
MAF-206012.A3
206012
|
-
|
|
|
|
502 - PARALLEL GUIDE FENCE
MAF-206038.A4
206038
|
-
|
|
|
|
503 - ALUMINUM COMPOSITE CUTTER MF-AF 90
MAF-206076.A1
206076
|
£400.58
|
£480.69
|
|
|
504 - SCREW DRIVER
MAF-093293.A1
093293
|
-
|
|
|
|
509 - INLAY
MAF-206045.A4
206045
|
-
|
|
|
|
510 - MK-PACK OUTER PART
MAF-170367.A0
170367
|
-
|
|
|
|
512 - CARRYING CASE T-MAX GR. IV
MAF-095181.A1
095181
|
£79.74
|
£95.69
|
|
|
513 - PLASTIC TRAY FOR T-MAX
MAF-095186.A
095186
|
-
|
|
|
|
516.1 - LATCH T-MAX
MAF-095183.A2
095183
|
-
|
|
|
|
516.2 - PIVOT
MAF-095201.A2
095201
|
-
|
|
|
|
519 - CHIP DEFLECTOR
MAF-206060.A0
206060
|
-
|
|
|
